REMOVAL & INSTALLATION
| WARNING | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Disconnect inside mirror harness connector. Rotate inside mirror counterclockwise until top of mirror is facing driver door. Twist mirror horizontally toward passenger door until mirror bottoms out and retaining clip releases. Remove inside mirror. To install, slide inside mirror assembly onto mount until spring clip snaps in place.
Remove door panel. Remove mirror mounting hole cover. (Scheme 3) Disconnect mirror wiring harness connector. Remove mirror attaching nuts. Remove mirror assembly while guiding wiring and connector through hole in door. To install, reverse removal procedure. Tighten nuts to approximately 53-70 INCH lbs. (6-8 N.m).
Scheme 3
Point mirror glass as far downward as possible to allow clearance between glass and mirror housing at outer edge of mirror. Insert fingers into clearance, and pull mirror glass. If fingers will not fit between glass and housing, use a screwdriver and cloth to pry mirror glass out. Glass will snap out without being damaged. Disconnect heater wires (if equipped). Remove motor attaching screws. Unplug motor connector, and remove motor. To install, reverse removal procedure. Ensure mirror glass locking tabs align before snapping in glass.
Remove inside door handle bezel. Remove window switch bezel. Depress retaining clips on switch housing. Push base of switch out of switch bezel. Unplug harness connector. Remove switch. To install, reverse removal procedure.
