Charging System - Generator: Specifications Ford Windstar I

Charging System 1 illustration

GENERATOR SPECIFICATIONS

ItemSpecifications
Generator (10346)F0DU-B
Rating (gen. crank/rev)130 Amp
Ratio (gen. crank/rev.)2.76:1
Regulator Type (10316)Electronic Integral with Generator

GENERATOR SPECIFICATIONS TABLE

TORQUE SPECIFICATIONS

DescriptionNm
Voltage Regulator Screws2.3-3.4
Generator Mounting Brace Bolt20-30
Generator Mounting Bolt Brace Nut20-30
Output Terminal Nut9-11
Generator Pivot Bolt40-55

TORQUE SPECIFICATIONS TABLE

Charging System Wiring Diagram. Scheme 1

Scheme 1: Charging System Wiring Diagram
Scheme 1: Charging System Wiring Diagram
