Warning Devices: Diagnosis Ford Thunderbird XI

Warning System 14 illustrations ~366 words

Inspection and Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Door ajar switches Key-in-ignition switch Headlamp switch Central junction box (CJB) fuses: 204 (5A) 213 (5A) 217 (5A) 219 (20A) 220 (10A) Battery junction box (BJB) fuses: 429 (20A) Circuitry Instrument cluster
  3. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
  4. If the diagnostic tool does not power up, refer to the diagnostic tool manual.
  5. Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-204591) . NO RESP/NOT EQUIP for instrument cluster (IC), refer to «INSTRUMENT CLUSTER»(ref-204577) . NO RESP/NOT EQUIP for restraint control module (RCM), refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150664) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the IC and RCM.
  6. If the DTCs retrieved from the RCM are related to the concern, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150664) . If the DTCs retrieved from the IC are related to the concern, go to the Instrument Cluster Diagnostic Trouble Code (DTC) Index to continue diagnostics.
  7. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart to continue diagnostics.

Instrument Cluster Diagnostic Trouble Code (DTC) Index

DTCDescriptionSourceAction
B1352Ignition Key-In Circuit FailureICMGO to PINPOINT TEST D: THE HEADLAMP ON REMINDER CHIME DOES NOT OPERATE CORRECTLY .

INSTRUMENT CLUSTER DIAGNOSTIC TROUBLE CODE INDEX

Note. For a complete master list of all instrument cluster DTCs, refer to MULTIFUNCTION ELECTRONIC MODULE .

Symptom Chart

ConditionPossible SourcesAction
No communication with the instrument clusterBattery junction box (BJB) fuses: 429 (20A). Central junction box (CJB) fuses: 204 (5A). 213 (5A). 217 (5A). 219 (20A). 220 (10A). Circuitry. Instrument cluster.REFER to INSTRUMENT CLUSTER .
All the chimes are inoperativeInstrument cluster.INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test.
The chime sounds when the driver door is ajar (no key in ignition and headlamps OFF)Instrument cluster. Key-in-ignition switch. Circuitry. Headlamp switch.Go To PINPOINT TEST A: THE CHIME SOUNDS WHEN THE DRIVER DOOR IS AJAR (NO KEY IN IGNITION AND HEADLAMPS OFF) .
The safety belt warning chime does not operate correctlyDriver safety belt switch. Instrument cluster. Circuitry.Go To PINPOINT TEST B: THE SAFETY BELT WARNING CHIME DOES NOT OPERATE CORRECTLY .
The belt minder feature does not operate correctlyDriver safety belt switch. Instrument cluster. Circuitry.Go To PINPOINT TEST B: THE SAFETY BELT WARNING CHIME DOES NOT OPERATE CORRECTLY .
The key-in-ignition chime does not operate correctlyKey-in-ignition switch. Driver door ajar switch. Circuitry. Instrument cluster.Go To PINPOINT TEST C: THE KEY-IN-IGNITION CHIME DOES NOT OPERATE CORRECTLY .
The headlamp on reminder chime does not operate correctlyInstrument cluster. Headlamp switch. Circuitry. Driver door ajar switch.Go To PINPOINT TEST D: THE HEADLAMP ON REMINDER CHIME DOES NOT OPERATE CORRECTLY .
A chime does not operate correctly - air bag warning chimeInstrument cluster. Circuitry. Restraint control module (RCM).Go To PINPOINT TEST E: A CHIME DOES NOT OPERATE CORRECTLY - AIR BAG WARNING CHIME .
A chime does not operate correctly - fail safe cooling chimeInstrument cluster. Circuitry.Go To PINPOINT TEST F: A CHIME DOES NOT OPERATE CORRECTLY - FAIL SAFE COOLING CHIME IS INOPERATIVE .
A chime does not operate correctly - turn signal warning toneInstrument cluster. Circuitry.Go To PINPOINT TEST G: A CHIME DOES NOT OPERATE CORRECTLY - TURN SIGNAL WARNING TONE .

SYMPTOM CHART

Scheme 2

Scheme 2: PINPOINT TEST A: THE CHIME SOUNDS WHEN THE DRIVER DOOR IS AJAR (NO KEY IN IGNITION AND HEADLAMPS OFF

PINPOINT TEST B: THE SAFETY BELT WARNING CHIME DOES NOT OPERATE CORRECTLY

Note. Verify the belt minder is activated before diagnosing the belt minder.

Scheme 3

Scheme 3: PINPOINT TEST B: THE SAFETY BELT WARNING CHIME DOES NOT OPERATE CORRECTLY

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6: PINPOINT TEST C: THE KEY-IN-IGNITION CHIME DOES NOT OPERATE CORRECTLY

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9: PINPOINT TEST D: THE HEADLAMP ON REMINDER CHIME DOES NOT OPERATE CORRECTLY

Scheme 10

Scheme 10

Scheme 11

Scheme 11: PINPOINT TEST E: A CHIME DOES NOT OPERATE CORRECTLY - AIR BAG WARNING CHIME

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14: PINPOINT TEST F: A CHIME DOES NOT OPERATE CORRECTLY - FAIL SAFE COOLING CHIME IS INOPERATIVE

Scheme 15

Scheme 15: PINPOINT TEST G: A CHIME DOES NOT OPERATE CORRECTLY - TURN SIGNAL WARNING TONE
