AUXILIARY JUNCTION BOX, INTERIOR
Note. Auxiliary junction box, interior is located under left side of dash. See .
AUXILIARY JUNCTION BOX, UNDERHOOD
Note. Auxiliary junction box, underhood is located in the right front of engine compartment. (Scheme 1)
Scheme 1
Scheme 2
Scheme 3
AUXILIARY RELAY BOX 1
Auxiliary relay box 1 is located in the passenger compartment, behind seat. (Scheme 4)
Scheme 4
BATTERY JUNCTION BOX
Note. Battery junction box may also be referred to as power distribution box.
Note. Battery junction box is located in right side of trunk. (Scheme 5)
Scheme 5
Scheme 6
Scheme 7
CENTRAL JUNCTION BOX
Note. Central junction box is located under passenger's side of dash panel. (Scheme 8)
Scheme 8
Scheme 9
Scheme 10
Note. Circuit breaker is located in right side of luggage compartment. (Scheme 11)
Right Side Of Luggage Compartment. Scheme 11
MEGA FUSE
Note. MEGA fuse is located in luggage compartment, near battery junction box. (Scheme 11)
