Engine Cooling: Diagnosis Ford Thunderbird XI

Cooling System (Mechanical) 5 illustrations ~832 words

Inspection & Verification

WARNINGTo avoid personal injury, do not unscrew the coolant pressure relief cap while the engine is operating or hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly.
CAUTIONCheck the coolant level, engine oil and transmission fluid, top off the coolant if needed. If there is engine coolant in the engine oil or transmission fluid, the cause must be corrected and oil/fluid changed or major component damage may occur.
CAUTIONSome vehicle cooling systems are filled with Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10 or equivalent) meeting Ford specification ESE-M97B44-A (Green color). Others are filled with Motorcraft Premium Gold Engine Coolant VC-7-A meeting Ford specification WSS-M97B51-A1 (Yellow color). Do not mix coolant types.
  1. Verify the customer concern by operating the engine to duplicate the condition.
  2. Inspect to determine if any of the following mechanical or electrical concerns apply. VISUAL INSPECTION CHART Mechanical Electrical Leaks Restricted Airflow Through The Condenser/Radiator Damaged Hoses Loose/Damaged Hose Clamps Damaged Water Gasket Damaged Head Gaskets Damaged Water Pump Damaged Radiator Damaged Degas Bottle Damaged Heater Core Hydraulic Cooling Fan System Fluid Level Hydraulic Line Or Joint Leaks Kinked Hydraulic Lines Damaged Cylinder Head Temperature Sensor Damaged Wiring Hydraulic Cooling Fan Pump Solenoid/Solenoid Wiring CAUTION: The cylinder head temperature sensor is not reusable after removal on 3.9L engines. For electrical concern testing refer to «SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV»(ref-132995) .
  3. If the inspection reveals an obvious concern that can be readily identified, repair it as necessary.
  4. Inspect the coolant condition: Inspect the coolant color. If Motorcraft Premium Engine Coolant (Green-color) VC-4-A or equivalent meeting Ford specification ESE-M97B44-A has a clear, Light Green or blue color, this indicates higher water content than required. If Motorcraft Premium Gold Engine Coolant (yellow-color) VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 has a Clear or Pale Yellow color, this indicates higher water content than required. Dark Brown could indicate unauthorized stop leak may have been used. Use Motorcraft System Stop Leak Powder, part number E6AZ-19558-A (and RA-2) or equivalent meeting Ford specification ESEM99B170-A except as noted in ES-F6SE-19A511-AA. A Light or Reddish Brown color indicates that rust may be present in the cooling system. Flush the system and refill with the correct mixture of water and Premium Engine Coolant or Premium Engine Gold Coolant. An iridescent sheen on the surface of the coolant could indicate a trace of oil is entering the system. For additional information on engine diagnosis, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-204558) . A Milky Brown color may indicate that either engine oil or transmission fluid is entering the cooling system. If transmission fluid is suspected, the cause may be a leaky radiator. Pressure test the cooling system. Refer to «COMPONENT TESTS»(ref-204560-S20073138972005111300000) . If engine oil is suspected, the cause of the leak may be internal to the engine. For additional information on engine diagnosis, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-204558) . If transmission fluid is contaminated with engine coolant, the cause may be a leaky radiator, pressure test the system. Refer to «COMPONENT TESTS»(ref-204560-S20073138972005111300000) . If the engine coolant appearance is acceptable, test the engine coolant freezing point range with the Battery/Antifreeze tester. The freezing point should be in the range -50°F to -10°F. If the vehicle is driven in cold climates less than -34°F, it may be necessary to increase the coolant concentration to get adequate freeze protection. Maximum coolant concentration is 60/40. Minimum coolant concentration is 40/60. Adjust coolant range and level if necessary: If the coolant is low, add specified coolant mixture only. If the coolant tests weak, add straight engine coolant until the readings are within acceptable levels. If the coolant tests strong, remove some of the engine coolant and add water until the readings are within acceptable levels.
  5. If the concern remains after the inspection, determine the symptom(s). GO to «SYMPTOM CHART»(ref-204560-S24180862262005111300000) .
  6. Verify the cooling system is correctly filled and bled. Refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING»(ref-204560-S28277462832005111300000) .

Symptom Chart

ConditionPossible SourcesAction
Loss Of Engine CoolantRadiator Thermostat Housing Assembly Auxiliary Water Pump Heater Control Valve Oil Cooler PCV Heater System Throttle Body Adapter Heating Water Pump Seal Radiator Hoses Heater Hoses Heater Core Engine Gaskets Degas BottleGo To PINPOINT TEST A: LOSS OF COOLANT
The Engine OverheatsWater Thermostat Airlock In The System Water Pump Internal Engine Coolant Leak Radiator Radiator Airflow Obstruction Heater Core Cooling Fan Pressure Relief CapGo To PINPOINT TEST B: THE ENGINE OVERHEATS
The Engine Does Not Reach Normal Operating TemperatureWater ThermostatGo To PINPOINT TEST C: THE ENGINE DOES NOT REACH NORMAL OPERATING TEMPERATURE
The Block Heater Does Not Operate CorrectlyBlock Heater Power Cable Block heaterDISCONNECT The Power Cable From The Heater CHECK The Resistance In All Three Power Cable Circuits. If The Resistance Is Greater Than 5 Ohms In Any Circuit, INSTALL A New Power Cable. If The Resistance Is Less Than 5 Ohms In All Three Circuits, INSTALL A New Block Heater.
Noisy Cooling Fan OperationIncorrect Fluid Level Kinked Or Leaking Line Blocked Reservoir Screen Hydraulic Motor Hydraulic PumpREFILL Fluid To Specified Level. REFER To HYDRAULIC COOLING FAN SYSTEM FILLING & BLEEDING. CHECK For Leaks And Retest. INSTALL A New Line. RETEST And CHECK For Leaks. REFER To COMPONENT TESTS .

SYMPTOM

Scheme 3

Scheme 3: Pinpoint Test A: Loss Of Coolant

Scheme 4

Scheme 4

Scheme 5

Scheme 5: Pinpoint Test B: The Engine Overheats

Scheme 6

Scheme 6

Scheme 7

Scheme 7: Pinpoint Test C: The Engine Does Not Reach Normal Operating Temperature

Pressure Test

  1. Turn the engine OFF.
  2. Remove the cowl vent screen. Refer to «FRONT END BODY PANELS - THUNDERBIRD»(ref-204605) .
  3. Check the engine coolant level. Refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING»(ref-204560-S28277462832005111300000) .
  4. Connect the Radiator/Heater Core Pressure Tester to the degas bottle nipple and overflow hose. Install a pressure test pump to the quick-connect fitting of the test adapter.
  5. Slowly depress the plunger of the pressure test pump until the pressure gauge reading stops increasing and note the highest pressure reading obtained.
  6. If the pressure relief cap does not hold pressure, remove and wash the pressure relief cap in clean water to dislodge all foreign particles from the gaskets. Check the sealing surface in the filler neck.
  7. If 8-9 kPa (13 psi) cannot be reached, install a new pressure relief cap. If more than 12 kPa (18 psi) shows on the gauge, install a new pressure relief cap.
  8. Pressurize the engine cooling system as described in 4 (using a pressure relief cap that operates within the specified upper and lower pressure limits). Observe the gauge reading for approximately two minutes; refer to «GENERAL SPECIFICATIONS»(ref-204560-S17287513302005111300000) . Pressure should not drop during this time.
  9. Release the system pressure by loosening the pressure relief cap. Check the engine coolant level and replenish, if necessary, with the correct engine coolant mixture. Refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING»(ref-204560-S28277462832005111300000) .

Radiator Leak Test, Removed From The Vehicle

CAUTIONNever leak test an aluminum radiator in the same water that copper/brass radiators are tested in. Flux and caustic cleaners may be present in the cleaning tank and they will damage aluminum radiators.

Note. Always install plugs in the oil cooler fittings before leak testing or cleaning any radiator.

Note. Clean the radiator before leak testing to avoid contamination of tank.

  1. Leak test the radiator in clean water with 138 kPa (20 psi) air pressure.
