Starting/charging 4.6l — Starting circuit Ford Thunderbird X
All systems — 36 systems
- Air conditioning 3.8l 4
- Air conditioning 4.6l 2
- Anti-lock brakes
- Computer data lines 3.8l 2
- Computer data lines 4.6l
- Cooling fan 3.8l 2
- Cooling fan 4.6l
- Cruise control
- Defoggers
- Electronic power steering 2
- Electronic suspension 3.8l
- Engine performance 3.8l 2
- Engine performance 4.6l
- Exterior lights
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster
- Interior lights 2
- Power antenna
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlocks
- Starting/charging 3.8l 3
- Starting/charging 4.6l 2
- Supplemental restraints
- Transmission 3.8l
- Transmission 4.6l
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams 9
Click a component to highlight it on every diagram it appears on.
