Power lumbar seat circuit for Ford Thunderbird X (1988-1997)
Power lumbar seat circuit
BLK WIRE
BLK/WHT WIRE
DRIVER'S POWER BOLSTER SWITCH
DRIVER'S POWER LUMBAR SWITCH
DRIVER'S POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR
HOT AT ALL TIMES
NCA WIRE
PASSENGER'S POWER BOLSTER SWITCH
PASSENGER'S POWER LUMBAR SWITCH
PASSENGER'S POWER LUMBAR/ BOLSTER COMPRESSOR MOTOR
PRIMARY JUNCTION BLOCK
RED WIRE
SEAT/LOCK CIRCUIT BREAKER
