DESCRIPTION & OPERATION
| WARNING | Vehicles are equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article. |
DESCRIPTION
The keyless entry system has two main components
- The electronic control module, located under LH luggage compartment trim panels.
- The five-button keypad on the driver's door. (Scheme 15)
The electronic control module performs the following functions
- Unlocking driver's door
- Unlocking passenger door
- Unlocking luggage compartment
- Locking all doors
- Automatic locking of all doors when the ignition switch is in the RUN position, someone is seated in the driver's seat, and the transmission is shifted through the REVERSE position.
- Turning on courtesy lights and keypad and keyhole illumination after any button on the keypad is pushed or either front door handle is lifted.
The control module will also accept and store an owner's alternate entry code. Either code will then operate the system. The system entry code is located on the owner's warranty card, on a label on the inside of the luggage compartment deck lid, on an owner's code card, and the code is printed on the control module. The control module is programmed at the factory with a five digit code. Replacement modules include replacement labels and a new owner's code card. (Scheme 16)
Scheme 15
Scheme 16
The keyless entry system receives inputs from the following
- Door handles
- Driver's seat sensor
- Transmission backup light switch
- Ignition switch
- Electric door lock/unlock switches
- Keypad
- Courtesy light switch
- Door ajar switch
The system distributes output to the following
- Keypad illumination
- Door lock illumination
- Door lock actuating solenoid
- Luggage compartment deck lid release solenoid
- Interior courtesy lights
To unlock the driver's door, enter the factory code or the owner's alternate code. To unlock the passenger door, press the 3/4 button within five seconds of unlocking the driver's door or luggage compartment. To unlock the luggage compartment, press the 5/6 button within five seconds of unlocking driver's or passenger door(s). To turn on the interior lights, lift either front door handle or press any button on the keypad. All illuminated components will light. To lock all doors, press the 7/8 and 9/0 buttons at the same time.
