BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| Cooling Fan Relay | Near cooling fan motor, mounted on radiator core support, left side. |
| Dual Warning Buzzer | Behind center of dash, near radio. (Scheme 1) |
| EEC Power Relay | Under right side of dash, behind glove box. |
| Fuel Pump Relay | Under right side of dash, behind glove box. |
| Hazard Flasher Relay | On back of fuse block. (Scheme 2) |
| Horn Relay (Vehicles With A/C and Cruise Control Only) | On back of fuse block. (Scheme 2) |
| Horn/Power Window Relay | On back of fuse block. (Scheme 2) |
| Shift Indicator Dimmer Relay | Behind left side of dash. |
| Starter Relay | On left front fender panel, near battery. |
| Turn Signal Flasher Relay | On front of fuse block. (Scheme 3) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location | |
|---|---|---|
| Circuit Breakers | ||
| Power Door Lock/Seat/Window | In cavity No 12 of fuse block. (Scheme 3) | |
| Windshield Wiper/Washer | In cavity No 2 of fuse block. (Scheme 3) | |
| Fuse Block | Under dash, to left of steering column. (Scheme 2)& (Scheme 3). | |
| Fusible Links | ||
| A (Black/16 ga) Lights | Near starter relay. | |
| B (Black/16 ga) Ignition Switch | Near starter relay. | |
| D (Green/14 ga) Charging Sys | Near starter relay. | |
| E (Brown/18 ga) Rear Defroster | Near starter relay. | |
| G (Blue/20 ga) Cooling Fan | Near starter relay. | |
| J (Brown/18 ga) Cooling Fan | Near starter relay. | |
| P (Blue/20 ga) ECA | Near starter relay. | |
| R (Green/14 ga) Cooling Fan | Near starter relay. | |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| A/C Cooling Fan Control Module | Under right side of dash, above glove box. (Scheme 4) |
| Cooling Fan Controller | Under left side of dash. |
| Electronic Control Assembly (ECA) | Under left side of dash. |
| Illuminated Entry Module | On crossmember, behind rear seat. (Scheme 5) |
| Low Fuel Warning Module | On front of center console. |
| Passive Restraint Module | Behind right side of dash, above glove box. |
| Seatbelt Warning Module | Behind right side of dash, above glove box. |
| TFI Module | Attached to distributor. |
CONTROL UNITS LOCATION
SENDING UNITS & SENSORS
| Component | Location |
|---|---|
| Air Charge Temp Sensor | On intake manifold. |
| Coolant Temp Sending Unit/Switch | On rear of cylinder head. (Scheme 6)& (Scheme 7). |
| Coolant Temp Sensor | In intake manifold water jacket. |
| EGR Valve Position Sensor | On EGR valve, at right rear of engine. (Scheme 6)& (Scheme 7). |
| Fuel Gauge Sending Unit | In fuel tank. |
| MAP Sensor | On center of cowl. |
| Oil Pressure Sending Unit/Switch | On left side of engine, above oil filter. (Scheme 6)& (Scheme 7). |
| Oxygen Sensor | In exhaust manifold. |
| Speed Sensor | On left rear side of transaxle. |
| Throttle Position Sensor | On fuel charging assembly. |
SENDING UNITS & SENSORS LOCATION
MOTORS
| Component | Location |
|---|---|
| A/C-Heater Blower Motor | Under right side of dash, on evaporator/heater housing. |
| Cooling Fan | Behind radiator. |
| Electric Fuel Pump | In fuel tank. |
| Idle Speed Control Motor | On fuel charging assembly. |
| Power Door Lock Motors | One in each door, below handle switch. |
| Power Mirror Motors | Two in each outside mirror. |
| Power Seat Motor | Below front seats. |
| Power Window Motor | One in each door. |
| Windshield Washer Pump | Inside washer fluid reservoir. |
| Windshield Wiper Motor | On right side of cowl. |
MOTORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| Canister Purge Solenoid | On left rear of engine. |
| EGR Vacuum Regulator Solenoid Valve | On left side of cowl. |
| Fuel Filler Door Release Solenoid | Near fuel tank line inlet. |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| A/C Clutch Cycling Switch | On A/C accumulator. |
| Back-Up/Neutral Switch | On transaxle. (Scheme 6)& (Scheme 7). |
| Brake/Stop Light Switch | Attached to brake pedal arm. |
| Clutch/Start Interrupt Switch | Above clutch pedal. |
| Dual Brake Warning Switch | Attached to master cylinder. |
| Fuel Filler Door Release Switch | In upper left corner of glove box. |
| Inertia Switch (Fuel Cut-Off) | Above left rear wheelwell. |
| Key Reminder Switch | Integral with ignition switch. |
| Power Steering Press Switch | In power steering pressure line, above steering gear. |
| Seat Belt Switch | In driver's seat belt buckle. |
| Speed Control Switch | In steering wheel. |
| Top Gear Switch (M/T) | Mounted to transaxle. (Scheme 7) |
| Trunk Release Switch | In lower left corner of glove box. |
| Washer Fluid Level Switch | Inside washer fluid reservoir. |
SWITCHES LOCATION
MISCELLANEOUS COMPONENTS
| Component | Location |
|---|---|
| A/C-Heater Blower Motor Resistors | Under right side of dash, on evaporator/heater housing. (Scheme 8) |
| Door Ajar Light Diodes | On warning light bar, under instrument cluster. |
| Horns | On radiator support. |
| Radio Amplifier | In trunk, in rear package tray. |
| Speed Control Amplifier | On left side of dash. (Scheme 9) |
| Speed Control Servo | On left front strut tower. |
| Voltage Regulator | On back of alternator. |
| Windshield Wiper Interval Governor | Attached to center dash support brace. |
MISCELLANEOUS COMPONENTS LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
