Rear View Mirror: Component Locations Ford Taurus VI

Special Tool(s)

SPECIAL TOOLS DESCRIPTION CHART Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent diagnostic tool

Scheme 66

Scheme 67

SPECIAL TOOLS DESCRIPTION CHART Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent

The auto-dimming feature is disabled when the vehicle is in REVERSE. Power is supplied to the interior auto-dimming mirror when the ignition is in the RUN or ACC position.

The interior auto-dimming rear view mirror has 2 photoelectric sensors that detect forward and rearward light conditions, and based on those inputs, adjusts the reflectance level of the interior auto-dimming rear view mirror and LH exterior auto-dimming mirror (if equipped) to eliminate unwanted glare.

When the forward sensor detects daytime conditions, the rearward sensor is inactive, and the mirror glass stays in a high reflectance mode. When the forward sensor detects nighttime conditions, the rearward sensor is active and detects glare from the headlights of vehicles approaching from the rear, or other glare producing light sources.

If the forward or rearward sensors are blocked, the interior auto-dimming rear view mirror and LH exterior auto-dimming mirror (if equipped) might not work correctly.

SPECIAL TOOLS DESCRIPTION CHART Installer, Rear Mirror 501-025 (T94P-17700-AH) Mirror Remover 501-D118

Scheme 68

Scheme 69

1. NOTE: Twisting the interior rear view mirror base from right to left may cause a stress fracture to the windshield. Insert the Mirror Remover between the mirror mount and windshield bracket from the bottom.
2. Release the mirror mount from windshield bracket by pulling the Mirror Remover away from the windshield.

Scheme 70

Scheme 71

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
2. Using the Rear View Mirror Installer, press the mirror assembly downward along the windshield until the mount is seated on the windshield bracket.

SPECIAL TOOLS DESCRIPTION CHART Mirror Remover 501-D118

Scheme 72

PARTS DESCRIPTION CHART

Scheme 73

1. Remove the wire cover.
2. Disconnect the electrical connector.
3. NOTE: High level mirror shown in illustration, others similar. Insert the Mirror Remover between the mirror mount and windshield bracket from the top.
4. NOTE: Twisting the interior rear view mirror base from right to left may cause a stress fracture to the windshield. Release the mirror mount from the windshield bracket by pulling the Mirror Remover and mirror down and away from the windshield.

Scheme 74

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
2. Quickly press the mirror assembly downward along the windshield until a click is felt. The click indicates the base is engaged to the windshield bracket.
3. Connect the electrical connector and wire cover.
4. Check the compass zone and calibration. For additional information, refer to «ELECTRONIC COMPASS»(ref-355762) .
