VIN - Identification Codes Ford Taurus VI

Scheme 1

The Vehicle Identification Number (VIN) is a 17-digit combination of letters and numbers. The VIN is stamped on a metal tab riveted to the instrument panel top, upper left of the dash. The VIN is also found on the Vehicle Certification (VC) label. If the VIN plate requires replacement, authorized dealers must contact their respective regional office.

Scheme 2

VEHICLE IDENTIFICATION NUMBER CODE DESCRIPTION CHART

Scheme 3

The first 3 VIN positions are the World Manufacturer Identifier (WMI) code.

1. 1FA - Ford Motor Company, USA, passenger car

Scheme 4

The fourth VIN position is the vehicle restraint-type code.

1. H - Active safety belts - all positions, driver and front passenger air bags with driver and front passenger side impact protection

Scheme 5

Positions 5 through 7 indicate vehicle line and series.

1. P2D - Taurus, Front Wheel Drive (FWD), SE
2. P2E - Taurus, FWD , SEL
3. P2F - Taurus, FWD , Limited
4. P2H - Taurus, All-Wheel Drive (AWD), SEL
5. P2J - Taurus, AWD , Limited
6. P2K - Taurus, AWD , SHO

Scheme 6

The eighth VIN position is the engine displacement and number of cylinders.

1. T - 3.5L, DOHC, turbo-charged, 4 valve, V6
2. W - 3.5L, DOHC, 4 valve, Variable Camshaft Timing (VCT), V6

Additional engine information can be obtained from the engine tag. Refer to ENGINE - 3.5L or ENGINE - 3.5L GTDI .

Scheme 7

The ninth VIN position is a government-assigned, computer-generated check digit.

Scheme 8

The tenth VIN position is the model year code.

1. A - 2010

Scheme 9

The eleventh VIN position is the assembly plant code.

1. G - Chicago (Chicago, Illinois)

Scheme 10

The last 6 VIN positions are a numeric code for the vehicle build sequence. This is also the vehicle serial and warranty number. The serial number can also be found on the engine block, transmission and frame.

1. 100001-599999

Scheme 11

The Vehicle Certification (VC) label contains the manufacturer name, the month and year of manufacture, the certification statement and the Vehicle Identification Number (VIN). It also includes Gross Vehicle Weight Rating (GVWR).

If a vehicle requires replacement of the VC label and is 4 years old or less, an authorized dealer must submit the VIN to their respective regional office. The regional office will submit a web form to the assembly plant for the replacement label. Once the label has been printed, a representative from the regional office will deliver the label to the dealer and witness installation on the vehicle. If a vehicle is more than 4 years old and requires a replacement label, the dealer must submit a request to the Department of Motor Vehicles.

Scheme 12

VEHICLE CERTIFICATION (VC) LABEL CODE DESCRIPTION CHART

Scheme 13

Vehicle paint codes may be listed as a 2-part code. The first set of paint code numbers/letters listed indicate the vehicle primary body color. The second set of numbers/letters listed (if applicable) indicate a 2-tone or accent body color. All colors are base coat/clear coat.

1. HT - Cinnamon
2. U6 - Red Candy Tint
3. UG - White Platinum (tri-coat)
4. UH - Tuxedo Black Metallic
5. UL - Atlantis Green Metallic
6. UN - Steel Blue
7. UP - Gold Leaf
8. UX - Ingot Silver Metallic
9. WS - White Suede

Scheme 14

The interior trim codes are listed below. The first digit listed indicates the seat and fabric style. The second digit listed indicates the interior trim color.

Trim Codes

1. 7 - Speck cloth seating
2. M - Kensington cloth seating
3. N - SOHO leather seating
4. P - SOHO mini-perforated leather seating
5. Q - Leather with perforated suede seating Interior Trim Color Code
6. N - Charcoal Black/Umber
7. S - Light Stone
8. W - Charcoal Black

Scheme 15

Tape and paint pinstripe codes do not apply.

Scheme 16

1. 2 - Premium electronic AM/FM stereo with CD player and clock
2. 6 - Premium electronic AM/FM stereo with 6-disc CD changer (MP3 capable) and clock
3. N - AM/FM stereo with CD player, clock and navigation system

Scheme 17

The following lists the rear axle ratio.

1. 1 - 2.77 ratio
2. 2 - 3.16 ratio
3. 3 - 3.39 ratio

Additional axle information can be obtained from the axle tag. Refer to DRIVELINE SYSTEM - GENERAL INFORMATION .

Scheme 18

1. C - 6-speed automatic (6F55)
2. J - 6-speed automatic (6F50)

Additional transmission information can be obtained from the transmission tag. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .

Scheme 19

Spring codes list both front and rear spring codes. The first set of characters identify the front springs. The second set of characters identify the rear springs.

Front Springs

1. AA - Front Wheel Drive (FWD) vehicles
2. BB - All-Wheel Drive (AWD) vehicles
3. CC - AWD , GTDI performance package Rear Springs
4. CC - FWD vehicles
5. AA - AWD vehicles
6. GG - AWD , GTDI performance package

Scheme 20

Note. Powertrain calibration information is limited to a maximum of 5 characters per line on the Vehicle Certification (VC) Label. Because of this, calibration identification consisting of more than 5 characters will wrap to the second line on the VC label.

Powertrain calibration information is printed in the lower right corner of the VC . Only the base calibration information is printed. Revision levels will not appear, however, they can be obtained through a scan tool using the most current software revision.

Scheme 21

POWERTRAIN CALIBRATION INFORMATION LEVEL CODE DESCRIPTION CHART

Model Year

Model year code indicates the year in which the calibration code was introduced.

1. 0 - 2000
2. 1 - 2001
3. 2 - 2002
4. 3 - 2003
5. 4 - 2004
6. 5 - 2005
7. 6 - 2006
8. 7 - 2007
9. 8 - 2008
10. 9 - 2009
11. A - 2010

Vehicle Code

The vehicle code indicates the vehicle line to which the code applies.

1. PH - Ford Taurus

Transmission Code

The transmission code identifies the type of transmission used.

1. 1 - Automatic transmission

Unique Calibration

The Emissions/Corporate Average Fuel Economy/CO2 Compliance Department is responsible for assigning these calibration numbers. Unique identifications are assigned to cover similar vehicles to differentiate between tires, drive configurations, final drive ratios and other calibration-significant factors.

These 2 characters are chosen by the analyst to provide identifiable information unique to each calibration. For example, using the number 2 to denote a 2-valve engine versus using the number 4 to identify a 4-valve engine provides an easily identifiable difference.

Fleet Coding

Identifies the fleet to which the vehicle belongs.

1. 0 - Certification (US 4K, final sale in export markets)
2. 1 - Heavy duty gasoline engines/Dyno
3. 2 - Fast Automobile Manufacturer's Association - U. S.
4. 3 - Alternative durability protocol - U. S.
5. 4 - Not assigned
6. 5 - Not assigned
7. 6 - Evaporative Emission (EVAP)
8. 7 - Mileage accumulation aging endurance durability
9. 8 - On-Board Diagnostic (OBD)
10. 9 - Not assigned

Certification Region

When instances where multiple regions are included in one calibration, the lead region will be listed.

1. 5 - US 50 states
2. A - US federal, including altitude, may include Canada and/or Mexico
3. B - US California standard, includes US green states
4. C - Canada
5. D - China
6. E - European Community (Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom)
7. F - European Extended Community (E plus Croatia, Czech Republic, Estonia, Hungary, Norway, Poland, Romania, Russian Federation, Slovakia, Slovenia, Switzerland and Yugoslavia)
8. G - Gulf Cooperative Council (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia and United Arab Emirate)
9. H - Hong Kong
10. J - Japan
11. K - Korea
12. L - Malaysia
13. M - Mexico
14. N - New Zealand
15. P - Australia
16. Q - South America (Brazil)
17. S - Singapore
18. T - Taiwan
19. U - South America (unleaded fuel regions)
20. V - Vietnam
21. X - Rest Of World (ROW)
22. Y - Military
23. Z - Israel Revision Level (not printed on label)
24. 91-99 - Hardware and certification levels
25. 01-04 - Preliminary levels
26. 00 - Job 1 production (initial certification)
27. 05-09 - Pre-job 1 revisions to calibrations
28. 10-89 - Post-job 1 revisions to calibrations
29. 0B - Durability test level
30. BD - OBD intermediate level (pre-05)
