Bumper System: Specifications Ford Taurus VI

Exterior Body Panels 5 illustrations ~221 words

TORQUE SPECIFICATIONS

DescriptionNm
Front bumper bolts23
Rear bumper double-ended studs12
Rear bumper nuts23

TORQUE SPECIFICATIONS

Scheme 9

Scheme 9: Bumper - Exploded View, Front
ItemPart NumberDescription
1W705436Front bumper cover pin-type retainer (2 required)
2W711685Front bumper cover bolt (4 required)
3W706805Fender splash shield screws (6 required)
417D957Front bumper cover
5W707050Front bumper bolt (8 required)
617750Front bumper
7W705436Front bumper cover-to-front bumper cover mounting bracket scrivets
8W714628Front bumper cover mounting bracket bolt
917D958-A RH/17D959-A LHFront bumper cover mounting bracket
108B407Lower air deflector
11W706092Rear lower air deflector pin-type retainer (3 required)
12W505416Lower air deflector bolt (7 required)
13Fender splash shield-to-lower air deflector bolt (2 required)

ITEM DESCRIPTION CHART

  1. For additional information, refer to the appropriate procedures .

Scheme 10

Scheme 10: Removal and Installation
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/taurus/vi-2009-2012/remont/hoistjack/#jacking-lifting) .
  2. Remove the 2 front bumper cover pin-type retainers.
  3. Remove the 4 front bumper cover bolts.
  4. Remove the 6 fender splash shield screws.
  5. Remove the 7 lower air deflector bolts.
  6. If equipped, disconnect the auxiliary park lamps electrical connector.
  7. Remove the front bumper cover.
  8. Reposition the fender splash and remove the 2 bumper cover-to-bumper cover bracket scrivets.
  9. Inspect the bumper cover mounting brackets for damage at the attachment points. If necessary, install new bumper cover mounting brackets.
  10. To install, reverse the removal procedure.

Scheme 11

Scheme 11: Removal and Installation

Scheme 12

Scheme 12
  1. Remove the front bumper cover. For additional information, refer to «BUMPER COVER - FRONT»(ref-355751-S30971002702010012800000) .
  2. Remove the ambient air temperature sensor from the front bumper, if equipped.
  3. Remove the radiator air deflector lower pin-type retainer.
  4. If equipped, drill out the 2 tack welds on each side of the front bumper.
  5. Remove the front bumper bolts. To install, tighten to 23 Nm (17 lb-ft).
  6. Remove the front bumper.
  7. To install, reverse the removal procedure.

Scheme 13

Scheme 13: Bumper - Exploded View, Rear
ItemPart NumberDescription
1W706805Fender splash shield screw (8 required)
217775Rear bumper
3N621941Rear bumper nut (4 required)
417K835Rear bumper cover
5W709343Rear bumper cover pin-type retainer (4 required)
6W706805Rear bumper cover-to-bumper cover bracket screw (2 required)
7W700092Rear bumper cover mounting bracket bolt (4 required)
817D948 RH/17D949 LHRear bumper cover mounting bracket
9W711412Rear bumper cover mounting bracket insert
10N621906Rear bumper cover nut

ITEM DESCRIPTION CHART

  1. For additional information, refer to the appropriate procedures .
