Preliminary Checks

Confirm concern, operate all switches. Ensure battery is fully charged. Ensure windows are properly aligned. Check the following for possible cause of malfunction

  1. Faulty fuse.
  2. Open or shorted supply circuit.
  3. Loose or corroded connectors.
  4. Poor ground connections.
  5. Faulty master switch.

Confirm concern. Ensure battery is fully charged. Ensure window in question is properly aligned. Check the following for possible cause of malfunction

  1. Damaged guide or regulator mechanism.
  2. Malfunctioning window motor. See «POWER WINDOW MOTOR»(ref-29241-S32031769572001010800000) under COMPONENT TESTING.
  3. Open or shorted circuit.
  4. Faulty window switch.

LEFT POWER WINDOW INOPERATIVE

  1. Remove and disconnect master switch. See «WINDOW SWITCH»(ref-29241-S30660491642001010800000) under REMOVAL & INSTALLATION. Turn ignition on. Measure voltage between ground and Red/Light Blue wire at master switch connector. If voltage is 10 volts or greater, go to next step. If voltage is less than 10 volts, repair open in Red/Light Blue wire. See «WIRING DIAGRAM»(ref-29241-S16296639562001010800000) . Restore system to original configuration and retest.
  2. Turn ignition off. Measure resistance between ground and Black wires at master switch connector. If all resistance measurements are less than 5 ohms, go to next step. If any resistance measurements are greater than 5 ohms, repair open in Black wire(s). Restore system to original configuration and retest.
  3. Reconnect master switch connector. Disconnect left power window motor connector. Turn ignition on. Measure voltage at motor harness connector White/Black wire with left window switch (on master switch) held in UP position. Measure voltage at motor harness connector Yellow wire with left window switch (on master switch) held in DOWN position. If voltage is less than 10 volts at both circuits, go to next step. If voltage is 10 volts or greater at both circuits, replace left power windor motor.
  4. Check for open or short to ground in White/Black or Yellow wire between master switch and left power window motor. If wires are okay, replace left power window motor. Restore system to original configuration and retest.

RIGHT POWER WINDOW INOPERATIVE

  1. Remove and disconnect right power window switch. See «WINDOW SWITCH»(ref-29241-S30660491642001010800000) under REMOVAL & INSTALLATION. Turn ignition to on. Measure voltage between ground and Red/Light Blue wire at right window switch connector. If voltage is 10 volts or greater, turn ignition off and go to next step. If voltage is less than 10 volts, repair open in Red/Light Blue wire. See «WIRING DIAGRAM»(ref-29241-S16296639562001010800000) . Restore system to original configuration and retest.
  2. Remove and disconnect master switch. See «WINDOW SWITCH»(ref-29241-S30660491642001010800000) under REMOVAL & INSTALLATION. Turn ignition on. Measure voltage between ground and Red/Light Blue wire at master switch connector. If voltage is 10 volts or greater, turn ignition off and go to next step. If voltage is less than 10 volts, repair open in Red/Light Blue wire. See «WIRING DIAGRAM»(ref-29241-S16296639562001010800000) . Restore system to original configuration and retest.
  3. Measure resistance between ground and Black wires at master switch connector. If all resistance measurements are less than 5 ohms, go to next step. If any resistance measurements are greater than 5 ohms, repair open in Black wire(s). Restore system to original configuration and retest.
  4. Reconnect master switch connector and turn ignition on. Measure voltage at right window switch connector Tan/Light Blue wire with right window switch (on master switch) held in UP position. Measure voltage at right window switch connector White/Yellow wire with right window switch (on master switch) held in DOWN position. If voltage is less than 10 volts, go to next step. If voltage is greater than 10 volts, go to step 6).
  5. Check for open or short to ground in Tan/Light Blue or White/Yellow wire between master switch and right power window switch. If wires are okay, replace master switch. Restore system to original configuration and retest.
  6. Turn ignition off. Reconnect right window switch. Disconnect right power window motor connector. Turn ignition on. Measure voltage at motor harness connector Red/Yellow wire with right window switch in UP position. Measure voltage at motor harness connector Yellow/Red wire with right window switch in DOWN position. If voltage is less than 10 volts at both circuits, go to next step. If voltage is 10 volts or greater at both circuits, replace right power windor motor.
  7. Check for open or short to ground in Red/Yellow or Yellow/Red wire between right window switch and right power window motor. If wires are okay, replace right power window motor. Restore system to original configuration and retest.

POWER WINDOW MOTOR

Remove window motor from vehicle, see WINDOW MOTOR under REMOVAL & INSTALLATION. Using fused jumper wires, connect a fully charged battery to motor terminals. Observe motor. Motor should operate smoothly. Reverse leads. Motor should operate in reverse direction. Replace window motor if it does not operate as specified.

MASTER SWITCH

Remove master switch. See WINDOW SWITCH under REMOVAL & INSTALLATION. Check for continuity between terminals as specified while operating switch. See MASTER SWITCH TESTING TABLE. If continuity does not exist, replace switch. (Scheme 2)

Switch PositionContinuity Between Terminal No.
Neutral9 & 15; 8 & 14; 6 & 12; 7 & 13
Left
Up6 & 10; 7 & 13
Down10 & 13; 6 & 12
Right
Up8 & 11; 9 & 15
Down11 & 15; 8 & 14

MASTER SWITCH TESTING

Scheme 2

Scheme 2

SINGLE SWITCH

Remove single switch. See WINDOW SWITCH under REMOVAL & INSTALLATION. Check for continuity between terminals as specified while operating switch. See SINGLE SWITCH TESTING TABLE. If continuity does not exist, replace switch. (Scheme 3)

Switch PositionContinuity Between Terminal No.
Neutral1 & 4; 2 & 5
Up3 & 5; 1 & 4
Down1 & 3; 2 & 5

SINGLE SWITCH TESTING

Scheme 3

Scheme 3
