Identification Codes: Other Ford RV Cutaway E350 Super Duty

Identification 11 illustrations ~1047 words

Primary Body Color

  1. BY - School Bus Yellow
  2. C2 - Gold Ash Metallic
  3. CX - Dark Shadow Gray Metallic (clear coat)
  4. JL - Dark Toreador Red (clear coat)
  5. L2 - True Blue Pearl (clear coat)
  6. ST - Estate Green (clear coat)
  7. UA - Ebony (clear coat)
  8. YN - Silver Metallic #2 (clear coat)
  9. YZ - Oxford White (clear coat)
  10. P - PTO paint

Two-Tone/Accent Color

  1. CX - Dark Shadow Gray Metallic (clear coat)
  2. YN - Silver Metallic #2 (clear coat)

Scheme 15

Scheme 15
Scheme 15
  1. 138-138-inch (3,505-mm) wheelbase
  2. 158 - 158-inch (4,013-mm) wheelbase
  3. 176 - 176-inch (4,470-mm) wheelbase

Scheme 16

Scheme 16
Scheme 16

Interior trim is listed as a two-part code. The first character indicates the trim type. The second character indicates the interior trim color.

Trim Type

  1. A - Hampton vinyl, bucket seats
  2. C - Mortar cloth, bucket seats
  3. E - Camden cloth, captains chairs
  4. F - Camden cloth, premium captains chairs
  5. L - G-Grain leather, captains chairs
  6. X - No trim available, seats not included

Interior Trim Color

  1. E - Medium Flint
  2. W - Medium Pebble
  3. X - No trim/no color

Scheme 17

Scheme 17
Scheme 17
  1. A - Dark Toreador Red/Titanium
  2. B - Light Titanium/Sandalwood

Scheme 18

Scheme 18
Scheme 18
  1. Premium electronic AM/FM stereo with compact disc (CD)
  2. Electronic AM/FM stereo with clock
  3. Electronic AM/FM stereo with cassette and clock
  4. D - Radio prep package (no radio chassis), six speakers installed
  5. G - Radio prep package (no radio chassis), two speakers installed
  6. R - Radio prep package (no radio chassis), four speakers installed
  7. S - Electronic AM/FM stereo with six-disc compact disc (CD) changer
  8. Y - Radio delete

Scheme 19

Scheme 19
Scheme 19
  1. 19 - 3.55 ratio, non-limited slip (Visteon)
  2. 22 - 4.10 ratio, non-limited slip (Dana)
  3. 24 - 3.73 ratio, non-limited slip (Dana)
  4. 32 - 4.10 ratio, non-limited slip (Dana)
  5. 34 - 3.73 ratio, non-limited slip (Dana)
  6. 39 - 3.55 ratio, non-limited slip (Dana)
  7. 52 - 4.10 ratio, non-limited slip (Dana), dual rear wheels
  8. 56 - 4.10 ratio, non-limited slip (Dana)
  9. 82 - 4.10 ratio, non-limited slip (Dana)
  10. 83 - 4.56 ratio, non-limited slip (Dana)
  11. 84 - 4.88 ratio, non-limited slip (Dana)
  12. 85 - 5.38 ratio, non-limited slip (Dana)
  13. B2 - 4.10 ratio, limited slip (Dana)
  14. B4 - 3.73 ratio, limited slip (Dana)
  15. C2 - 4.10 ratio, limited slip (Dana)
  16. C4 - 3.73 ratio, limited slip (Dana)
  17. C9 - 3.55 ratio, limited slip (Dana)
  18. E2 - 4.10 ratio, limited slip (Dana), dual rear wheels
  19. E6 - 4.10 ratio, limited slip (Dana)
  20. F2 - 4.10 ratio, limited slip (Dana), dual rear wheels
  21. F3 - 4.56 ratio, limited slip (Dana), dual rear wheels
  22. G4 - 4.88 ratio, limited slip (Dana)
  23. G5 - 5.38 ratio, limited slip (Dana)
  24. H9 - 3.55 ratio, limited slip (Visteon)

Scheme 20

Scheme 20
Scheme 20
  1. A - Four-speed automatic overdrive (4R70E)
  2. B - Four-speed automatic, TorqShift, (4R75E), diesel
  3. F - Four-speed automatic overdrive (4R75E)
  4. T - Five-speed automatic overdrive (5R110W)

Scheme 21

Scheme 21
Scheme 21

Spring codes are identified as a two-part code. The first character listed identifies the front spring code. The second character listed identifies the rear spring code.

Front Springs

  1. A - F2UA-5310-AA (coil)
  2. B - F2UA-5310-BA (coil)
  3. C - F2UA-5310-CA (coil)
  4. D - F2UA-5310-DA (coil)
  5. E - F2UA-5310-EA (coil)
  6. F - F2UA-5310-FA (coil)
  7. G - F2UA-5310-GA (coil)
  8. H - F2UA-5310-HA (coil)
  9. J - F2UA-5310-JA (coil)
  10. K - F2UA-5310-KA (coil)
  11. L - F2UA-5310-LA (coil)
  12. M - F2UA-5310-MA (coil)
  13. N - F2UA-5310-NA (coil)
  14. P - F2UA-5310-PA (coil)
  15. R - FU2A-5310-RA (coil)
  16. S - FU2A-5310-SA (coil)
  17. T - FU2A-5310-TA (coil)
  18. U - FU2A-5310-UA (coil)
  19. V - FU2A-5310-VA (coil)
  20. Z - FU2A-5310-ZA (coil)

Rear Springs

  1. F5UA-5560-VA (leaf)
  2. F6US-5560-AA (leaf)
  3. C - F5UA-5560-XA (leaf)
  4. G - F7UA-5560-AGA (leaf)
  5. N - F5UA-5560-NA (leaf)
  6. P - F5UA-5560-PA (leaf)
  7. R - F5UA-5560-RA (leaf)
  8. S - F5UA-5560-SB (leaf)

Scheme 22

Scheme 22: Powertrain Calibration Information
Scheme 22: Powertrain Calibration Information

Note. Powertrain calibration information is limited to a maximum of five characters per line on the vehicle certification label. Because of this, calibration identification consisting of more than five characters will wrap to the second line on the VC label.

Powertrain calibration information is printed in the lower right corner of the vehicle certification label. Only the base calibration information is printed. Revision levels will not appear, however, they can be found in On Line Automotive Service Information System (OASIS). For the current model year, Ford Motor Company is using three different protocols which describe powertrain base calibration. These protocols are designed to provide worldwide standardization for vehicle calibration. If the electronic calibration strategy has been used since 1998 and carried into the current model year, Protocol 1 will be used. Refer to PROTOCOL 1 . If the electronic calibration strategy has been used since 1999 and is carried into the current model year, PROTOCOL 2 will be used. Refer to PROTOCOL 2 . For electronic calibration strategies introduced in 2000 or later model years, use PROTOCOL 3 .

Scheme 23

Scheme 23: Protocol 1
Scheme 23: Protocol 1

Scheme 24

Scheme 24: Protocol 2
Scheme 24: Protocol 2

Scheme 25

Scheme 25: Protocol 3
Scheme 25: Protocol 3

The following offers a more detailed explanation of Protocol 3.

Model Year

  1. 2000
  2. 2001
  3. 2002
  4. 2003
  5. 2004
  6. 2005

Vehicle Line

  1. E4 - E-Series

Transmission

  1. Automatic transmission

Fleet Code

  1. Certification (U.S. 4K, final sale in export markets)
  2. HDGE/Dyno
  3. Fast AMA, U.S.
  4. ADP U.S.
  5. Not assigned
  6. Not assigned
  7. Evaporative emissions
  8. MACAA
  9. On-board diagnostics (OBD)
  10. Not assigned

Certification Region

  1. Certification region - Lead code where multiple regions are included in one calibration
  2. U.S. fifty states
  3. A - U.S. Federal (including altitude, may include Canada or Mexico)
  4. B - U.S. California standard (includes U.S. green states)
  5. C - Canada
  6. D - China
  7. E - European Community (Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom)
  8. F - Extended European Community (E plus Croatia, Czech Republic, Estonia, Hungary, Norway, Poland, Romania, Russian Federation, Slovakia, Slovenia, Switzerland and Yugoslavia)
  9. G - Gulf Cooperative Council
  10. H - Hong Kong
  11. J - Japan
  12. K - Korea
  13. L - Malaysia
  14. M - Mexico
  15. N - New Zealand
  16. P - Australia
  17. Q - South America (Brazil)
  18. S - Singapore
  19. T - Taiwan
  20. U - South America (unleaded fuel)
  21. V - Vietnam
  22. X - ROW (rest of world)
  23. Y - Military
  24. Z - Israel

Revision Level (not printed on label)

  1. 91-99 - Hardware and certification level
  2. 01-04 - Preliminary levels
  3. 00 - Job 1 production (initial calibration)
  4. 05-09 - Pre-job 1 revisions to calibrations
  5. 10-89 - Post-job 1 revisions to calibrations
  6. 0B - Durability test level
  7. BD - On-board diagnostics (OBD) intermediate level (pre-05)
