Engine Controls - Electronic Engine Controls: Other Ford Ranger II facelift

Material

MATERIAL SPECIFICATION

Scheme 17

PART NUMBER REFERENCE

MATERIAL SPECIFICATION

Scheme 18

PART NUMBER REFERENCE

General Equipment

GENERAL EQUIPMENT REFERENCE

Scheme 19

PART NUMBER REFERENCE

Scheme 20

Scheme 21

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
2. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
3. Remove the engine plug bolt.
4. Install the Crankshaft Timing Peg and turn the crankshaft pulley bolt to position the No. 1 cylinder at Top Dead Center (TDC).
5. Remove the 2 bolts and the CKP sensor.
6. Install the 6 mm x 18 mm bolt in the position shown in illustration.

Scheme 22

Scheme 23

1. NOTE: Whenever the CKP sensor is removed, a new one must be installed using the Crankshaft Sensor Aligner. Position the CKP sensor and loosely install the 2 bolts.
2. Adjust the CKP sensor with the Crankshaft Sensor Aligner and tighten the 2 bolts. Tighten to 7 Nm (62 lb-in).
3. Connect the CKP sensor electrical connector.
4. Remove the 6 mm x 18 mm bolt.
5. Remove the Crankshaft Timing Peg.
6. Install the engine plug bolt. Tighten to 20 Nm (177 lb-in).

Scheme 24

PART NUMBER REFERENCE

MATERIAL SPECIFICATION

Scheme 25

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
2. Disconnect the Heated Oxygen Sensor (HO2S) electrical connector.
3. NOTE: If necessary, lubricate the HO2S with lock lubricant to assist in removal. Using the Exhaust Gas Oxygen Sensor Socket, remove the HO2S .

Scheme 26

1. Apply a light coat of nickel anti-seize lubricant to the threads of the HO2S .
2. Using the Exhaust Gas Oxygen Sensor Socket, install the HO2S . Calculate the correct torque wrench setting for the following torque. Using the Exhaust Gas Oxygen Sensor Socket, tighten to 48 Nm (35 lb-ft).
3. Connect the HO2S electrical connector.

MATERIAL SPECIFICATION

Scheme 27

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
2. Disconnect the Catalyst Monitor Sensor (CMS) electrical connector.
3. NOTE: If necessary, lubricate the CMS with lock lubricant to assist in removal. Using the Exhaust Gas Oxygen Sensor Socket, remove the CMS .

Throttle Body (TB) Cover

PART NUMBER REFERENCE

Scheme 28

PART NUMBER REFERENCE
