Special Tool(s)
SPECIAL TOOL SPECIFICATION Fluke 77-IV Digital Multimeter FLU77-4 or equivalent
Scheme 17
The movement of the LH and RH exterior mirror glass is controlled by the exterior mirror control switch and the LH and RH exterior mirror motors. Adjusting the exterior mirror switch to the LH or RH position determines which exterior mirror motor will be controlled. The exterior mirror control switch logic is the selected movement request from the exterior mirror control switch. When the exterior mirror control switch is adjusted to the left, right, up or down position, the exterior mirror control switch will supply voltage and ground to the selected exterior mirror motor to move the exterior mirror glass to the desired position.
The exterior mirrors use a jumper harness between the vehicle wire harness connector and the exterior mirror motor. The exterior mirror jumper harness is integral to the exterior mirror. Before replacing an exterior mirror or mirror motor, inspect the jumper harness for open and shorted circuits or damaged and pushed-out pins. If a concern with the exterior mirror jumper harness exists, attempt to repair the jumper harness.
SPECIAL TOOL SPECIFICATION Installer, Rear Mirror 501-025 (T94P-17700-AH) Mirror Remover 501-D118
Scheme 18
Scheme 19
- NOTE: Twisting the interior rear view mirror base from right to left may cause a stress fracture to the windshield. Insert the Mirror Remover between the mirror mount and windshield bracket from the bottom.
- Release the mirror mount from windshield bracket by pulling the Mirror Remover away from the windshield.
Scheme 20
Scheme 21
- Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
- Using the Rear View Mirror Installer, press the mirror assembly downward along the windshield until the mount is seated on the windshield bracket.
