Interior Trim Color
- F - Medium/Dark Flint
Scheme 16
Tape and paint stripe codes do not apply.
Scheme 17
- 7 - Electronic AM/FM stereo with clock
- B - Premium electronic AM/FM stereo with 6-disc CD changer and MP3 capability
- Z - AM/FM stereo with CD player and clock
Scheme 18
The following lists the gear ratios on axles.
- 86 - 3.73 non-limited slip (7.5 inch)
- 87 - 4.10 non-limited slip (7.5 inch)
- 95 - 3.55 non-limited slip (8.8 inch)
- 96 - 3.73 non-limited slip (8.8 inch)
- 97 - 4.10 non-limited slip (8.8 inch)
Additional axle information can be obtained from the axle tag. Refer to DRIVELINE SYSTEM - GENERAL INFORMATION .
Scheme 19
- D - 5-speed automatic (A5LDE/5R44E/5R55E)
- J - 5-speed manual (R1HD)
- R - 5-speed manual (M5R1)
Additional transmission information can be obtained from the transmission tag. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E or MANUAL TRANSAXLE/TRANSMISSION AND CLUTCH - GENERAL INFORMATION .
Scheme 20
Spring codes are listed as a 2-part code. The first character identifies the front spring/torsion bar code. The second character identifies the rear spring code.
Front Spring Codes
- 22 - 5L54-5310-BB (coil)
- 33 - 5L54-5310-LB (coil)
- 55 - 5L54-5310-KB (coil)
- AA - 5L54-5310-AB (coil)
- CC - 5L54-5310-MB (coil)
- DD - 5L54-5310-DB (coil)
- EE - 5L54-5310-EB (coil)
Front Torsion Bar Codes
- 1 - F67A-5B326-FB (RH)
- 1 - F67A-5B327-FB (LH)
- B - F57A-5B326-BC (RH)
- B - F57A-5B327-BC (LH)
- F - F57A-5B326-FC (RH)
- F - F57A-5B327-FC (LH)
Rear Spring Codes
- 33 - 9L54-5560-A (leaf)
- CC - 9L54-5560-C (leaf)
- KK - 9L54-5560-B (leaf)
Scheme 21
Note. Powertrain calibration information is limited to a maximum of 5 characters per line on the Vehicle Certification (VC) label. Because of this, calibration identification consisting of more than 5 characters will wrap to the second line on the VC label.
Powertrain calibration information is printed in the lower right corner of the VC label. Only the base calibration information is printed. Revision levels will not appear, however, this information can be obtained through a scan tool using the most current software revision.
Scheme 22
| Item | Description |
|---|---|
| 1 | Model year (model year in which calibration strategy was first introduced) |
| 2 | Vehicle code |
| 3 | Transmission code |
| 4 | Unique calibration (designates different hardware to similar vehicles), example: tires and drive ratios |
| 5 | Fleet code (describes fleet to which the vehicle belongs), example: 6 - Evaporative Emission (EVAP) |
| 6 | Certification region (lead region where multiple regions are included in one calibration), example: A - US federal |
| 7 | Revision level (will advance as revisions occur), obtained through scan tool |
DESCRIPTION CHART
Model Year
- 0 - 2000
- 1 - 2001
- 2 - 2002
- 3 - 2003
- 4 - 2004
- 5 - 2005
- 6 - 2006
- 7 - 2007
- 8 - 2008
- 9 - 2009
- A - 2010
Vehicle Line
- R3 - Ranger
Transmission
- 1 - Automatic transmission
- 2 - Manual transmission
