GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator, 2.3L | |
| Generator pulley ratio | 2.35:1 |
| Rating | 65/110 amps (max) @ 1,800-6,000 generator RPM, approximately 500-2,000 engine RPM |
| Voltage regulator type | Electronic internal with generator |
| Generator, 3.0L | |
| Generator pulley ratio | 2.41:1 |
| Rating | 70/115 amps (max) @ 1,800-6,000 generator RPM, approximately 500-2,000 engine RPM |
| Voltage regulator type | Electronic internal with generator |
| Generator, 4.0L | |
| Generator pulley ratio | 2.39:1 |
| Rating | 70/115 amps (max) @ 1,800-6,000 generator RPM, approximately 500-2,000 engine RPM |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ terminal nut | 8 |
| Generator bolts (2.3L) | 25 |
| Generator bolts (3.0L) | 48 |
| Generator bolts (4.0L) | 47 |
| Generator pulley nut | 109 |
| Generator voltage regulator screws | 3 |
TORQUE SPECIFICATIONS
The generator is belt-driven by the engine accessory drive system. The generator on the 2.3L engine has an internal voltage regulator that is not replaced separately. The 2.3L engine generator and voltage regulator are repaired as an assembly. The 3.0L engine and 4.0L engine also have an internal voltage regulator but the voltage regulator can be replaced separately from the generator.
Refer to CHARGING SYSTEM - GENERAL INFORMATION article.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 6B209 | Front end accessory drive (FEAD) belt tensioner |
| 2 | 8620 | FEAD belt |
| 3 | W701331-S439 | Generator bolts (2 required) |
| 4 | Generator electrical connector (part of 14300) | |
| 5 | W705790-S901 | Generator B+ terminal nut |
| 6 | Generator B+ terminal (part of 14300) | |
| 7 | 10346 | Generator |
