Maintenance Information: Overview Ford Probe II

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp RADIO - Remote Control Mirrors, Audio Power/Power Antenna, Up/Down Action When Radio is Turned Off)
2. 2 - 15 Amp CIGAR - Cigarette Lighter
3. 3 - 15 Amp ENGINE - Main Relay No. 1 No. 2, Fuel Pump Control Unit, Ignition Relay
4. 4 - 15 Amp METER - Back-Up Lights, Radio & Power Antenna, Sound Warning System, Rear Window Defroster, 4EAT Control System, Cruise Control, Cooling Fan Control System
5. 5 - 20 Amp COOLING FAN - Cooling Fan System
6. 6 - 7.5 Amp MONITOR - VMM Display
7. 7 - 10 Amp TURN - Power Steering Control, ABS System, Turn Signal & Hazard Flashers
8. 8 - 30 Amp POWER WIND - Power Windows
9. 9 - 10 Amp EIC - Instrument Cluster, VMM Display
10. 10 - 10 Amp REAR WIPER - Rear Wiper & Washer
11. 11 - 20 Amp WIPER - Front Wiper & Washer
12. 12 - 30 Amp POWER SEAT - Power Seats
13. 13 - 30 Amp DOOR LOCK
14. 14 - 20 Amp STOP - Brakelights, High Mount Brakelight, Horns
15. 15 - 15 Amp HAZARD - Turn Signals & Hazard Lights
16. 16 - 10 Amp ROOM - Sound Warning System, 4EAT Control System, Luggage Compartment Light, Audio Illumination, Power Antenna, Engine Control System, VMM Display
17. 17 - 15 Amp TAIL - Glove Compartment Light, Side Marker Lights, Taillights, License & Parking Lights, Illumination Lights
18. 18 - 15 Amp FOG - Front Foglights
19. 19 - 30 Amp DEFOG (Circuit Breaker) - Rear Window Defroster

Scheme 1

1. 1 - 15 Amp REAR WIPER - Rear Wiper & Washer
2. 2 - EMPTY
3. 3 - 15 Amp ENGINE 2 - Engine Control System, HEGO, Engine Control System
4. 4 - 10 Amp ROOM - Sound Warning System, 4EAT Control System, Luggage Compartment Light, Audio Illumination, Power Antenna, Engine Control System, VMM Display
5. 5 - 15 Amp TAIL - Headlights, Illumination Lights, Taillights & License Lights, Side Marker & Parking Lights
6. 6 - 30 Amp BELT - Passive Restraint System
7. 7 - 15 Amp RADIO - Remote Control Mirrors, Audio Power/Power Antenna, Up/Down Action When Radio is Turned Off)
8. 8 - 15 Amp COOLING FAN - Cooling Fan System
9. 9 - 15 Amp METER - Back-Up Lights, Radio & Power Antenna, Sound Warning System, Rear Window Defroster, 4EAT Control System, Cruise Control, Cooling Fan Control System
10. 10 - 20 Amp DOOR LOCK - Power Door Locks
11. 11 - 30 Amp POWER SEAT - Power Seats
12. 12 - 15 Amp CIGAR - Cigarette Lighter
13. 13 - 30 Amp POWER WIND - Power Windows
14. 14 - 15 Amp HAZARD - Turn Signals & Hazard Lights
15. 15 - 10 Amp TURN - Power Steering Control, ABS System, Turn Signal & Hazard Flashers
16. 16 - 20 Amp STOP - Brakelights, High Mount Brakelight, Horns
17. 17 - 15 Amp ENGINE - Fuel Pump Relay, Cooling Fan System, A/C & Heating, Meter/Warning, ECA
18. 18 - 7.5 Amp MONITOR - VMM Display
19. 19 - 30 Amp DEFOG (Circuit Breaker) - Rear Window Defroster

Scheme 2

Fuse Breaker Identification

1. 1 - 30 Amp FUEL INJ - Emission & Fuel Injection, Control System
2. 2 - 30 Amp RETRA - Headlight Retractor Motors
3. 3 - 30 Amp HEAD - Headlights
4. 4 - 80 Amp MAIN (2.2L) - 100 Amp (3.0L) - Charging System, Remote Control Mirrors, Audio System, Cigarette Lighter, A/C System, Programmed Ride Control System, Wipers & Washers, Back-Up Lights, Cruise Control, Warning Lights & Gauges, Electronic Power Steering, Emission & Fuel Control, Rear Window Defroster, Power Windows, Ignition System, VMM Control System
5. 5 - 60 Amp BTN - Foglights, Glove Compartment Light, Parking Lights, Taillights & Marker Lights, License Lights, Illumination Lights, Cargo Lights, Stoplights, High Mounted Stoplight, Horn, Power Antenna, Turn & Hazard Flasher Lights, Power Seat & Door Locks, 4EAT Control System, Sound Warning System, Heating & A/C System
6. 6 - 40 Amp COOLING FAN (2.2L) - 60 Amp (3.0L) - Cooling Fan Control System
7. 7 - 60 Amp ABS PUMP - ABS Control System
8. 8 - 40 Amp HEATER (1991-92) - 60 Amp (1989-90) - Heater Control System
9. 9 - EMPTY (1991-92) - 15 Amp AIR COND (1989-90) - A/C Compressor Clutch System
10. 10 - EMPTY (1991-92) - 10 Amp AUDIO (1989-90) - Audio System
11. 11 - 15 Amp ST SIGN (GL & LX) - ECA, Fuel Pump Relay
12. 12 - 15 Amp FOG (GT) - Foglights
13. 13 - 20 Amp - Front Washer & Wiper (1991)
14. 14 - 20 Amp AIR COND - Fuel Pump (1991-92), A/C Compressor Magnetic Clutch Control System
15. 15 - 15 Amp AUDIO (1991-92) - Audio System 10 Amp AUDIO (1989-90)

Scheme 3

Fuse Identification

1. 1 - 20 Amp (STOP) - Stoplights, High-Mount Brakelight, Horn, Shift Lock System
2. 2 - 15 Amp (ROOM) - Illuminated & Keyless Entry System, Key Reminder, Audio System, Engine & Luggage Compartment Lights, Foot Lights, Dome & Map Lights, Visor Mirror, Ignition & Door Key Lights
3. 3 - 30 Amp (DOOR LOCK) - Power Door Locks
4. 4 - 15 Amp (RADIO) - Audio System, Power Mirrors
5. 5 - 15 Amp (SUN ROOF) - Moon Roof
6. 6 - 15 Amp (TURN) - Turn Signals
7. 7 - 15 Amp (AUDIO) - Audio System, Cigarette Lighter
8. 8 - 15 Amp (METER) - Back-Up Lights, Instrument Cluster, Keyless Entry, Power Antenna, Anti-Theft Warning, Shift Lock, Rear Window Defroster Switch Indicator, Power Window & Power Door Lock, Switch Illumination
9. 9 - 15 Amp (HAZARD) - Hazard Warning Lights & Turn Signals
10. 10 - 15 Amp (ENGINE) - Rear Window Defroster, Air Bag System, Anti-Lock Brake System, Cooling Fan, Speed Control System, Emission & Fuel Control System
11. 11 - 30 Amp (POWER WINDOW) - Power Windows
12. 12 - 15 Amp (AIR COND) - Air Conditioning, Daytime Running Lights (Canada)
13. 13 - 20 Amp (WIPER) - Front Wiper/Washer
14. 14 - 15 Amp (REAR WIPER) - Rear Wipers/Washer
15. 15 - 15 Amp (SPARE)

Scheme 4

1. 1 - Relay - Foglights
2. 2 - Relay - Headlights
3. 3 - 30 Amp (F/P INJ) - Emission & Fuel Controls, Air Bag System
4. 4 - 40 Amp (DEFOG) - Rear Window Defroster
5. 5 - 30 Amp (HEAD) - Headlights, Foglights, Daytime Running Lights (Canada)
6. 6 - 100 Amp (MAIN) - Main Fuse: All Circuits
7. 7 - Relay - Air Conditioning
8. 8 - 40 Amp (AIR COND) - Air Conditioning
9. 9 - 40 Amp (HEATER) - Heater & Air Conditioning
10. 10 - 40 Amp (COOLING FAN) - Cooling Fan
11. 11 - 60 Amp (ABS) - Anti-Lock Brake System
12. 12 - 60 Amp (BTN) - Front & Rear Side Marker Lights, Tail & License Plate Lights, Glove Compartment Light, O/D OFF Indicator, Foglight Indicator, Rear Wiper/Washer Indicator, Rear Window Defroster Indicator, Headlight Retractor & A/C Indicators, Cigarette Lighter Switch Illumination Light, Power Seats, Lumbar Support, Engine & Luggage Compartment Lights, Foot, Dome & Map Lights, Visor Mirror Light, Ignition & Door Key Lights, Illuminated Entry System, Keyless Entry System, Key Reminder, Audio System, Brakelights, High-Mount Brakelight, Horn, Shift-Lock System, Power Door Locks, Hazard Warning Lights, Turn Signals, Cigarette Lighter
13. 13 - 40 Amp (IG KEY) - Heater & A/C, Starting System, Power Windows & Mirrors, Front & Rear Wiper/Washer, Audio System, Rear Window Defroster, Air Bag System, Anti-Lock Brake System, Cooling Fan, Speed Control System, Emission & Fuel Control System, Back-Up Lights, Instrument Cluster, Rear Window Defroster Indicator, Power Window & Power Door Switch Illumination, Keyless Entry System, Power Antenna, Anti-Theft Warning System, Shift Lock System, Turn Signals, Moon Roof, A/C, Daytime Running Lights
14. 14 - Blank
15. 15 - 30 Amp (POWER SEAT) - Power Seats & Lumbar Support
16. 16 - 20 Amp (RETRA) - Headlight Retractors
17. 17 - 15 Amp (TAIL) - Front & Rear Side Marker Lights, Tail & License Plate Lights, Glove Compartment Light, Instrument Panel Indicator Lights, Rear Wiper/Washer & Defroster Switch Illumination, O/D Off, Fog Lights, Headlight Retractor, A/C & Cigar Lighter Switch Illumination
18. 18 - Relay - Daytime Running Lights (DRL)
19. 19 - 40 Amp - Rear Window Defroster
20. 20 - Relay - Turn Signal/Parking Lights
21. 21 - Relay - Fuel Pump
22. 22 - Relay - Ignition Main (1993), Powertrain Control Module (PCM) Power (1994-96)
23. 23 - Relay - Starter Interrupt
