POWER MIRRORS

Power side view mirror system consists of mirror head with integral servo motor assembly and mirror control switch.

Depressing side view mirror control switch push button, marked with arrows indicating adjustment directions, moves mirror up, down, left and right. A selector switch controls which mirror is adjusted. Selector switch should be placed in neutral position after adjustment.

SIDE MIRROR SWITCH

Remove side mirror switch. See SIDE MIRROR SWITCH R & I under REMOVAL & INSTALLATION. Using DVOM, check for continuity between specified wires. See appropriate SIDE MIRROR SWITCH TEST table. If switch fails any portion of test, replace switch.

Switch Position(2) Battery Voltage(3) Ground
Left Mirror
UpBRNBRN/YEL
DownBRN/YELBRN
LeftLT GRNBRN/YEL
RightBRN/YELLT GRN
Right Mirror
UpBRNBRN/BLK
DownBRN/BLKBRN
LeftLT GRN/BLKBRN/BLK
RightBRN/BLKLT GRN/BLK
(1) (Scheme 2)for connector terminal identification. (2) 11-13 volts. (3) 0-1 volt.
(1)(Scheme 2)for connector terminal identification.
(2)11-13 volts.
(3)0-1 volt.

SIDE MIRROR SWITCH TEST (1)

Scheme 2

Scheme 2

SIDE MIRROR MOTOR

Remove door trim panel. Disconnect mirror motor connector from mirror switch harness. Using 2 jumper wires, connect battery voltage and chassis ground to specified wire terminals. See SIDE MIRROR MOTOR TEST table. Observe mirror for proper movement. If mirror motor fails any portion of test, replace mirror assembly.

Mirror MovementBattery VoltageGround
Left Mirror
UpBRNBRN/YEL
DownBRN/YELBRN
LeftLT GRNBRN/YEL
RightBRN/YELLT GRN
Right Mirror
UpBRNBRN/BLK
DownBRN/BLKBRN
LeftLT GRN/BLKBRN/BLK
RightBRN/BLKLT GRN/BLK
(1) (Scheme 2)for connector terminal identification.
(1)(Scheme 2)for connector terminal identification.

SIDE MIRROR MOTOR TEST (1)

SIDE MIRROR GLASS & MOTOR

Mirror motor and/or mirror glass must be replaced as an assembly. See SIDE MIRROR ASSEMBLY .
