Wiring diagram: Headlights — Headlights circuit Ford Pickup F150

Components on these wiring diagrams 22

Click a component to highlight it on every diagram it appears on.

• 12 13 Computer Data Lines System Hs Can + Hs Can
• Autolamp Sensor
• Autolamp Sensor In
• Autolamp/ Sunload Sensor
• Automatic Manual A/C A/C
• Body Control Module
• Breakout To Battery Junction Box
• Datc Hvac Module
• Driver Sunload
• Emtc Hvac Module
• Fog Lamp Switch
• Fuse 47
• Headlamp Switch
• Hs Hs Can+ Can
• Instrument Panel Cluster
• Left Headlamp
• Multi-Function Switch 8 5 Vbatt Pwr Gnd
• Passenger Sunload
• Return
• Right Headlamp
• Steering Column
• Steering Column Control Module
