VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 3
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Severe Service
- Short Trips (About 10 Miles) In Freezing Temperatures
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
- Snow Plowing
- High Speed Operation With Fully Loaded Vehicle
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service List
| CAUTION | Diesel-powered models require additional servicing. Refer to Maintenance Schedule for Diesel Engines. |
ADDITIONAL MAINTENANCE
Wheel lug nut torque, clutch fluid reservoir level, exhaust system shielding, automatic transmission fluid level, automatic shift linkage, front axle spindle pins, clutch release lever pivots, driveshaft U-joints and slip yoke, if equipped with fittings, should be serviced or inspected every 6 months or 7500 miles for light duty emission vehicles and every 6 months or 5000 miles for diesel and heavy duty emissions vehicles.
REAR AXLE LUBRICATION
Rear axle lube quantities must be replaced every 100,000 miles, or if the axle has been submerged in water. Otherwise lube should not be checked unless a leak is suspected or repair required.
OFF-HIGHWAY VEHICLES
If vehicle is operated off-highway, perform the following items every 1000 miles. If vehicle is operated in mud and/or water, perform the following items daily.
- Lubricate Front Axle, Steering And Clutch Linkages, Axle And Driveshaft U-Joints, And Slip Yoke If Equipped With Fittings.
- Lubricate Automatic Transmission External Controls (Cables).
- Inspect Front Wheel Bearings And Lubrication.
- Inspect Disc And Drum Brake Systems, Hoses And Lines, Lube Caliper Slide Rails.
- Inspect Exhaust System For Leaks, Damage, Or Loose Parts And Remove Any Foreign Material Trapped By Shielding.
- Lubricate Clutch Release Lever Pivot (7.3L And 7.5L).
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
SERVICE LABOR TIMES
Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
TIRE INFLATION
Inflation pressure and recommended tire size can be found on the Safety Compliance Certification Label decal attached to the driver's door latch post pillar.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| F150 (5-Lug Wheel) | 100 (135) |
| F250/350 (8-Lug Wheel) | 140 (190) |
| F350 DRW (8-Lug Wheel) | 140 (190) |
| Super Duty (10-Lug Wheel) | 140 (190) |
TORQUE SPECIFICATIONS
Note. If wheels are equipped with locking type lug nuts, ALWAYS position the keyed nut opposite the valve stem.
| CAUTION | DO NOT attempt to use wheels which have cone-shaped lug nut seats on this vehicle. Use of incorrect wheels can lead to damage to wheel mounting system, and could result in wheels coming loose. |
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL AIR BAG SYSTEM
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
CHECKING AUTOMATIC TRANSMISSION FLUID
When checking the ATF always have the 4WD gear selector in any position other than neutral.
ANTI-LOCK BRAKE SYSTEM
On models with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed or add hydraulic fluid to system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in ABS-equipped vehicles.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical on all 4 tires.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BATTERY WARNING
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
BRAKE PAD REPLACEMENT
| WARNING | Use caution when checking and/or changing brake pads, some pads may contain asbestos which can irritate eyes and may cause other health hazards. A water based solution should be used to clean brake dust from wheel and brake components. DO NOT use compressed air to blow off brake dust. |
CATALYTIC CONVERTER
To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C) |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
DIESEL FUEL ANTI-FUNGAL ADDITIVES
| CAUTION | If fuel contamination due to fungi or other microorganisms is suspected a fuel additive with a biocide may be used. Follow the manufacturers dosage as recommended on product label. Use biocides ONLY when necessary, excessive use can may cause other fuel system problems. |
DIESEL FUEL CONTAMINATION
| WARNING | Diesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection. |
DIESEL FUEL REQUIREMENTS
| CAUTION | All diesel engines are to use Diesel Fuel #2 when the outside temperature is above 20°F (-7°C). In temperatures that are below 20°F (-7°C) use Diesel Fuel #1, this will reduce the chance of the fuel thickening and forming wax. |
Note. A Diesel Fuel #1 & #2 combination (Blended Fuel) may be used, and is recommended for mild winter driving.
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| CAUTION | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
FUEL CONDITIONER (DIESEL ENGINES)
Allowing water to remain in fuel conditioner could result in extensive damage to or failure of fuel injection system. Diesel fuel can damage asphalt and other surfaces. Always place a drain pan under fuel conditioner to collect fuel, and dispose of fuel properly.
FUEL PUMP SHUTOFF SWITCH
This switch stops the flow of fuel to the engine after a collision. The impact does not have to be great to trigger the switch. To reset, press the white reset button on the switch located on the floorboard, to the left and above where the steering column passes through the floorboard.
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
JUMP STARTING (TURBO DIESEL)
| WARNING | DO NOT USE a booster battery or power source that has more than 12 volts of power. NEVER USE a 24 volt power source. |
STARTING FLUID USE (TURBO DIESEL)
| WARNING | DO NOT USE starting fluids (ether) or flammable liquids to aid the starting of a Diesel engine. NEVER pour diesel fuel, flammable liquids or starting fluids into the air cleaner canister, air intake or turbocharger housing in an attempt to start the vehicle. A flash fire may result causing personal injury. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. |
TURBOCHARGED MODELS (TURBO-DIESEL)
| CAUTION | Do not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BASIC NEW CAR LIMITED WARRANTY
All parts of the vehicle, except tires, are covered against defects in factory-supplied materials and workmanship for 12 months or 12,000 miles, whichever occurs first.
POWERTRAIN WARRANTY
Note. Powertrain Warranty varies in coverage length (either 4 years/50,000 miles or 6 years/60,000 miles) depending on model year.
Under this warranty, certain parts of the engine, transmission, axle and driveline are warranted against defects in materials and workmanship. This coverage begins after 12 months or 12,000 miles. See copy of warranty for specific components covered and length of coverage.
BUMPER-TO-BUMPER COVERAGE
All 1992-93 vehicles have complete warranty coverage against defects in materials and workmanship for 3 years or 36,000 miles, whichever occurs first. There is no deductible with this warranty. Items not covered include tires and parts that are subject to normal wear and tear, such as windshield wiper blades, brake linings, brake pads, clutch linings and scheduled maintenance items. There is no extended powertrain coverage included in this warranty.
BATTERY COVERAGE
Begins at warranty start date and lasts up to 3 years or 36,000 miles, whichever occurs first. For the first 12 months in service (less than 36,000 miles), battery will be replaced at no charge. After that, battery will be replaced on a customer-participation basis: For the 13th-24th month in service, Ford will pay 50%; for the 25th-36th month, Ford will pay 25%. Labor is covered for 3 years or 36,000 miles, whichever occurs first.
SAFETY RESTRAINT SYSTEM COVERAGE
Begins at warranty start date and lasts for 5 years or 50,000 miles, whichever occurs first. Covers safety restraint problems not related to comfort or appearance. Coverage for model years earlier than 1990 is 3 years with unlimited miles.
CORROSION COVERAGE
Begins at warranty start date and lasts for 6 years or 60,000 miles, whichever occurs first. 1992-93 models are covered for 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.
EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed for the vehicle to pass a Federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered. Performance Warranty coverage is limited to fewer components after 2 years or 24,000 miles.
EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSIONS DEFECT WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
GVWR Over 8500 Lbs.
If an emission-related part on a vehicle with a GVWR over 8500 lbs. is defective, the part will be repaired or replaced by Ford Motor Co. for a period of 5 years or 50,000 miles (gasoline engines), or 5 years or 100,000 miles (diesel engines), whichever occurs first.
FUSE PANEL LOCATION
The fuse panel is located on the instrument panel behind access door, to the left of the steering column.
Scheme 10
Fuse & Circuit Breaker Identification
- 1 - 15 Amp Stoplights, Hazard Lights, Speed Control
- 2 - 15 Amp Exterior Lights, Instrument Panel Illumination
- 3 - 15 Amp Turn Signals, Back-Up Lights, Overdrive Transmission (1983-90), Roof Map Light (1991)
- 4 - 15 Amp Speed Control, Accessories & 4WD
- 5 - 15 Amp Courtesy Lights, Dome Lights, Cargo Light, Glove Box Light
- 6 - 30 Amp Heater & A/C-Heater
- 7 - 5 Amp Instrument Illumination, Clock Dimming, Radio Display Dimming
- 7 - 20 Amp Rear Anti-Lock Brakes
- 8 - 15 Amp Radio & Clock Illumination, Headlight Switch Illumination
- 9 - 30 Amp (Circuit Breaker) Power Door Locks
- 9 - 25 Amp Transfer Case Control (1991)
- 10 - 30 Amp (Circuit Breaker) Power Windows
- 10 - 25 Amp Tailgate Window
- 11 - 10 Amp Auxiliary Fuel Tank, Switch (If Equipped)
- 12 - 30 Amp Horn, Cigarette Lighter, Speed Control
- 13 - 5 Amp Instrument Illumination, Clock & Radio Display Dimming
- 13 - 20 Amp Rear Anti-Lock Brakes
- 14 - 15 Amp Safety Belt Buzzer, Warning Indicators, Tachometer, Diesel Glow Plug Control, Diesel Indicators
Scheme 11
- 1 - 15 Amp Stoplights, Hazard Lights
- 2 - 7 Amp (Circuit Breaker) Windshield Wiper Motor
- 3 - 15 Amp Marker Lights
- 4 - 15 Amp Turn Signals, Back-Up Lights, Overdrive Transmission (1983-90)
- 5 - 15 Amp Accessory Feed
- 6 - 15 Amp Glove Box Light, Interior Dome Light
- 7 - 30 Amp Heater Blower Motor
- 8 - 10 Amp Radio
- 9 - 5 Amp Instrument Panel Illumination
- 10 - 10 Amp Horn
- 11 - 15 Amp Gauges & Warning Lights
Scheme 12
- 1 - 30 Amp Heater A/C Blower
- 2 - 8.25 Amp Wiper/Washer
- 3 - Not Used
- 4 - 15 Amp Warning Buzzer/Chime Module, Exterior, Lights, Instrument Illumination, Trailer Exterior Light Relay
- 5 - Not Used
- 6 - 15 Amp A/C Clutch, Diesel, Auxiliary Fuel Selector
- 7 - 15 Amp Turn Signal Lights, Rear Window Defrost (Diesel Or Bronco Only)
- 8 - 15 Amp Courtesy, Dome & Cargo Lights, Electric Outside Mirrors, Radio/Clock Memory, Speedometer Memory, Warning Buzzer/Chime Module
- 9 - 15 Amp Power Point
- 10 - 4 Amp Instrument Panel Illumination
- 11 - 15 Amp Radio, Radio Display Dimmer
- 12 - 20 Amp Power Lumbar, Power Door Locks, Electronic Shift Motor 4WD, Key Switch & Tailgate Power, Window (Bronco Or Diesel)
- 13 - 15 Amp Stoplights, Hazard Lights, Keep Alive Memory Power (F-Series Only), Electronic Engine Control, Speed Control, Anti-Lock Brakes, Stop Sense For: Anti-Lock Brakes & Electronic Engine Control
- 14 - 20 Amp Power Windows, Tailgate Power Window, Instrument Panel Switch
- 15 - 20 Amp Anti-Lock Brakes (F-Series Only)
- 16 - 15 Amp Cigarette Lighter
- 17 - 10 Amp Warning Buzzer/Chime Module, Warning Indicators, Gauges, Tachometer, Transmission, Control Switch & Indicator Light
- 18 - 10 Amp Speed Control (F-Series), Electronic Shift Module 4WD, Speedometer
