Starting System: Removal & Installation Ford Mustang V рестайлинг

Starter 3 illustrations ~480 words

Removal

WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.

Scheme 17

Scheme 17
Scheme 17
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position the wires.
  5. If equipped, remove the nut and position the automatic transmission cooler tube bracket.
  6. Remove the 2 stud bolts and the starter motor.

Installation

  1. Position the starter motor and install the 2 stud bolts finger-tight. Tighten the upper stud bolt to 48 Nm (35 lb-ft). Tighten the lower stud bolt to 48 Nm (35 lb-ft).
  2. If equipped, position the automatic transmission cooler tube bracket and install the nut. Tighten to 12 Nm (106 lb-in).
  3. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  4. Install the starter solenoid terminal cover.
  5. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.

Scheme 18

Scheme 18: Starter Motor - 5.0L (4V)
Scheme 18: Starter Motor - 5.0L (4V)
ItemPart NumberDescription
111N087Starter solenoid terminal cover
2N805403Starter solenoid B+ terminal nut
314463Starter solenoid B+ terminal eyelet
4W705790Starter solenoid S-terminal nut
514463Starter solenoid S-terminal eyelet
6W500310Starter motor mounting bolts (3 required)
711000Starter motor

PARTS DESCRIPTION CHART

WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position the wires.
  5. Remove the 3 bolts and the starter motor.
  1. Position the starter motor and install the 3 bolts finger-tight. Tighten the upper bolt to 25 Nm (18 lb-ft). Tighten the lower 2 bolts to 25 Nm (18 lb-ft).
  2. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  3. Install the starter solenoid terminal cover.
  4. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.

Scheme 19

Scheme 19: Starter Motor - 5.4L (4V)
Scheme 19: Starter Motor - 5.4L (4V)
ItemPart NumberDescription
111N087Starter solenoid terminal cover
2W705790Starter solenoid S-terminal nut
314463Starter solenoid S-terminal eyelet
4N805403Starter solenoid B+ terminal nut
514463Starter solenoid B+ terminal eyelet
6W500310Starter motor mounting bolt (3 required)
711000Starter motor

PARTS DESCRIPTION CHART

WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position the wires.
  5. Remove the 3 bolts and the starter motor.
  1. Position the starter motor and install the 3 bolts finger-tight. Tighten the upper bolt to 25 Nm (18 lb-ft). Tighten the 2 lower bolts to 25 Nm (18 lb-ft).
  2. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  3. Install the starter solenoid terminal cover.
  4. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
