Front Suspension: Specifications Ford Mustang V рестайлинг 2

Suspension Front 4 illustrations ~190 words

SPECIFICATIONS

ItemSpecificationFill Capacity
Silicone Spray Lubricant XL-6ESR-M13P4-A

MATERIAL SPECIFICATIONS

DescriptionNm
Brake caliper anchor plate bolts115
Brake disc shield bolts20
Brake hose bracket bolt20
Lower arm forward bolt205
Lower arm rearward nuts185
Lower ball joint nut115
Stabilizer bar bracket nuts70
Stabilizer bar link nuts115
Steering gear bolts115
Strut rod nut103
Strut rod nut (GT500)80
Strut-to-spindle bolts225
Strut upper mount nuts35
Tie-rod end nuts80
Wheel hub nut340
Wheel speed sensor bolt15

TORQUE SPECIFICATIONS

The front suspension consists of the following components

  1. Strut and spring assembly
  2. Wheel spindle
  3. Lower arm
  4. Wheel bearing and wheel hub
  5. Stabilizer bar and links

The front suspension system incorporates a strut assembly that takes the place of the upper arm and ball joint. The strut carries out the function of a shock absorber and is encompassed by a coil spring. The strut and spring assembly supports the weight of the vehicle and is also the pivot point for the steering spindle. This system uses a lower control arm and ball joint for the lower (unloaded) pivot point of the steering spindle.

Refer to SUSPENSION SYSTEM - GENERAL INFORMATION .

Scheme 20

Scheme 20: Wheel Studs
Scheme 20: Wheel Studs
ItemPart NumberDescription
11104Wheel hub assembly
21107Wheel stud

Scheme 21

Scheme 21: Removal
Scheme 21: Removal
  1. Remove the wheel bearing and hub assembly. For additional information, refer to «WHEEL BEARING AND WHEEL HUB»(ref-574131-S29579007532013082300000) .
  2. Using a press, remove the wheel stud from the wheel bearing and hub assembly.

Scheme 22

Scheme 22: Installation
Scheme 22: Installation
  1. Using a press, install a new wheel stud.
  2. Install the wheel bearing and hub assembly. For additional information, refer to «WHEEL BEARING AND WHEEL HUB»(ref-574131-S29579007532013082300000) .

Scheme 23

Scheme 23: Wheel Bearing and Wheel Hub
Scheme 23: Wheel Bearing and Wheel Hub
ItemPart NumberDescription
1W710233Brake caliper anchor plate bolt (2 required)
2Brake caliper, pads and anchor plate assembly
31125Brake disc
41N135Wheel hub grease cap
53B477Wheel hub nut
61104Wheel hub assembly
