Starting System: Removal & Installation Ford Mustang V рестайлинг 2

Starter 2 illustrations ~581 words

Removal

WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-574118) .
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position aside the wires.
  5. If equipped, remove the nut and position the automatic transmission cooler tube bracket aside.
  6. Remove the 2 stud bolts and the starter motor.

Installation

  1. NOTE: To make sure of correct starter installation, the upper bolt must be tightened first. NOTE: Clean the starter motor mounting flange and mating surface of the starter motor to make sure there is a correct ground connection. Position the starter motor and install the 2 stud bolts finger-tight. Tighten the upper stud bolt to 48 Nm (35 lb-ft). Tighten the lower stud bolt to 48 Nm (35 lb-ft).
  2. If equipped, position the automatic transmission cooler tube bracket and install the nut. Tighten to 12 Nm (106 lb-in).
  3. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  4. Install the starter solenoid terminal cover.
  5. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .

Scheme 20

Scheme 20: Starter Motor - 5.0L (4V)
Scheme 20: Starter Motor - 5.0L (4V)
ItemPart NumberDescription
111N087Starter solenoid terminal cover
2N805403Starter solenoid B+ terminal nut
314463Starter solenoid B+ terminal eyelet
4W705790Starter solenoid S-terminal nut
514463Starter solenoid S-terminal eyelet
6W500310Starter motor mounting bolts (3 required)
711000Starter motor
WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-574118) .
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position aside the wires.
  5. Remove the 3 bolts and the starter motor.
  1. NOTE: To make sure of correct starter installation, the upper bolt must be tightened first. NOTE: Clean the starter motor mounting flange and mating surface of the starter motor to make sure there is a correct ground connection. Position the starter motor and install the 3 bolts finger-tight. Tighten the upper bolt to 25 Nm (18 lb-ft). Tighten the lower 2 bolts to 25 Nm (18 lb-ft).
  2. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  3. Install the starter solenoid terminal cover.
  4. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .

Scheme 21

Scheme 21: Starter Motor - 5.8L (4V)
Scheme 21: Starter Motor - 5.8L (4V)
ItemPart NumberDescription
111N087Starter solenoid terminal cover
2W705790Starter solenoid S-terminal nut
3Part of 14300Starter solenoid S-terminal eyelet
4W709450Starter solenoid B+ terminal nut
5Part of 14300Starter solenoid B+ terminal eyelet
6W500310Starter motor mounting bolt (3 required)
711002Starter motor
WARNINGAlways disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury.
  1. With the vehicle in NEUTRAL, position it on a hoist, refer to «JACKING & LIFTING»(ref-574118) .
  2. Disconnect the battery ground cable, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .
  3. Remove the starter solenoid terminal cover.
  4. Remove the 2 starter solenoid terminal nuts and position aside the wires.
  5. Remove the 3 bolts and the starter motor.
  1. NOTE: To make sure of correct starter installation, the upper bolt must be tightened first. NOTE: Clean the starter motor mounting flange and mating surface of the starter motor to make sure there is a correct ground connection. Position the starter motor and install the 3 bolts finger-tight. Tighten the upper bolt to 25 Nm (18 lb-ft). Tighten the 2 lower bolts to 25 Nm (18 lb-ft).
  2. Install the wires and the 2 starter solenoid terminal nuts. Tighten the starter solenoid B+ terminal nut to 12 Nm (106 lb-in). Tighten the starter solenoid S-terminal nut to 5 Nm (44 lb-in).
  3. Install the starter solenoid terminal cover.
  4. Connect the battery ground cable, refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) .
