Automatic Transmission - External Controls: Removal & Installation Ford Mustang IV рестайлинг

Installation

1. To install, reverse the removal procedure.

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

1. Remove the shifter top control panel. (Scheme 381): Removing Shifter Top Control Panel
2. Disconnect the electrical connectors. (Scheme 382): Disconnecting Electrical Connectors
3. Remove the shifter bezel. (Scheme 383): Removing Shifter Bezel
4. Remove the bulb from the bezel. (Scheme 384): Removing Bulb From Bezel
5. Disconnect the TCS connector. (Scheme 385): Disconnecting TCS Connector
6. Remove the screw and the handle.
7. Raise and support the vehicle.
8. Disconnect the shift cable and discard the plastic clip. (Scheme 387): Disconnecting Shift Cable And Discarding Plastic Clip
9. Lower the vehicle.
10. Remove the shifter. (Scheme 388): Removing Shifter

1. To install, reverse the removal procedure.

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

1. Remove the shifter top control panel. (Scheme 390): Removing Shifter Top Control Panel
2. Disconnect the electrical connectors. (Scheme 391): Disconnecting Electrical Connectors
3. Remove the shifter bezel. (Scheme 392): Removing Shifter Bezel
4. Remove the bulb from the bezel. (Scheme 393): Removing Bulb From Bezel
5. Disconnect the TCS connector. (Scheme 394): Disconnecting TCS Connector
6. Remove the screw and the handle.
7. Remove the transmission control switch. (Scheme 396): Removing Transmission Control Switch

1. To install, reverse the removal procedure.

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

1. Remove the shifter top control panel. (Scheme 397): Removing Shifter Top Control Panel
2. Disconnect the electrical connectors. (Scheme 398): Disconnecting Electrical Connectors
3. Remove the shifter bezel. (Scheme 399): Removing Shifter Bezel
4. Remove the bulb from the bezel. (Scheme 400): Removing Bulb From Bezel
5. Disconnect the connector. (Scheme 401): Disconnecting Connector
6. Remove the screw and the handle.
7. Remove the bezel.

1. To install, reverse the removal procedure.

Scheme 397

Scheme 398

Scheme 399

Scheme 400

1. Remove the floor console.
2. Remove the bolts, then position the bezel upward. (Scheme 403): Removing Bolts
3. Remove the bulb socket from the bezel. (Scheme 404): Removing Bulb Socket From Bezel
4. Remove the bulb. (Scheme 405): Removing Bulb
5. To install, reverse the removal procedure. (Scheme 406): Installing Bezel Bolts

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

1. Remove the shifter top control panel. see scheme 57: Removing Shifter Top Control Panel
2. Disconnect the electrical connectors. see scheme 58: Disconnecting Electrical Connectors
3. Remove the shifter bezel. see scheme 59: Removing Shifter Bezel
4. Remove the bulb from the bezel. see scheme 60: Removing Bulb From Bezel
5. Disconnect the TCS connector. see scheme 61: Disconnecting TCS Connector
6. Remove the screw and the handle.
7. Remove the transmission control switch. see scheme 63: Removing Transmission Control Switch

1. To install, reverse the removal procedure.
