MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article below

1. SCHEDULED SERVICES (1983-93)
2. SCHEDULED SERVICES - TURBO (1983-86)

Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

1. Short Trips (About 10 Miles) In Freezing Temperatures
2. Towing Or Heavily Loaded
3. Severe Dust Conditions
4. Hot Weather, Stop-And-Go Driving
5. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

CAMSHAFT TIMING BELT

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

1. Cracks Or Tears In Belt Surface
2. Missing, Damaged, Cracked Or Rounded Teeth
3. Oil Contamination
4. Damaged Or Faulty Tensioners
5. Incorrect Tension Adjustment

Replace camshaft timing belt on 2.3L engine every 60,000 miles.

TURBOCHARGED ENGINES

Maintenance for turbocharged and non-turbo engines is identical except for engine oil and filter change. On turbocharged engines, change oil and filter every 6 months or 5000 miles, whichever occurs first.

COOLING SYSTEM, HOSES & CLAMPS

Replace engine coolant every 36 months or 30,000 miles. Check coolant strength, condition of hoses and clamps annually regardless of mileage or driving conditions. Replace hoses and clamps as necessary.

REAR AXLE FLUID CHANGE

Rear axle lubricant must be changed every 100,000 miles. Change fluid immediately if the axle has been submerged in water. Otherwise, check level only if a leak is suspected or a repair is required.

Scheme 3

Scheme 4

Scheme 5

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Tire specification decal is located on front face of right door pillar.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 85-105 ft. lbs. (115-142 N.m). If wheels are equipped with locking type lug nuts, ALWAYS position "Keyed" nut opposite valve stem.

BATTERY SPECIFICATIONS

1983-87 models use a group 61, 62, or 63 battery depending on engine size. All 1988-93 models use group 58C batteries.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)

Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

AIR CONDITIONING SERVICING

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

BATTERY WARNING

REPLACING BLOWN FUSES

BRAKE PAD WEAR INDICATOR

CATALYTIC CONVERTER

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

ENGINE OIL

FUEL SYSTEM SERVICE

HALOGEN BULBS

RADIATOR CAP

RADIATOR FAN

TURBOCHARGED MODELS

WARRANTY INFORMATION

BASIC NEW CAR LIMITED WARRANTY

All parts of the vehicle, except tires, are covered against defects in factory-supplied materials and workmanship for 12 months or 12,000 miles, whichever occurs first.

POWERTRAIN WARRANTY

Note. Powertrain Warranty varies in coverage length (either 4 years/50,000 miles or 6 years/60,000 miles) depending on model year.

Under this warranty, certain parts of the engine, transmission, axle and driveline are warranted against defects in materials and workmanship. This coverage begins after 12 months or 12,000 miles. See copy of warranty for specific components covered and length of coverage.

BUMPER-TO-BUMPER COVERAGE

All 1992-93 vehicles have complete warranty coverage against defects in materials and workmanship for 3 years or 36,000 miles, whichever occurs first. There is no deductible with this warranty. Items not covered include tires and parts that are subject to normal wear and tear, such as windshield wiper blades, brake linings, brake pads, clutch linings and scheduled maintenance items. There is no extended powertrain coverage included in this warranty.

BATTERY COVERAGE

Begins at warranty start date and lasts up to 3 years or 36,000 miles, whichever occurs first. For the first 12 months in service (less than 36,000 miles), battery will be replaced at no charge. After that, battery will be replaced on a customer-participation basis: For the 13th-24th month in service, Ford will pay 50%; for the 25th-36th month, Ford will pay 25%. Labor is covered for 3 years or 36,000 miles, whichever occurs first.

SAFETY RESTRAINT SYSTEM COVERAGE

Begins at warranty start date and lasts for 5 years or 50,000 miles, whichever occurs first. Covers safety restraint problems not related to comfort or appearance. Coverage for model years earlier than 1990 is 3 years with unlimited miles.

CORROSION COVERAGE

Begins at warranty start date and lasts for 6 years or 60,000 miles, whichever occurs first. 1992-93 models are covered for 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.

EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed for the vehicle to pass a Federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered. Performance Warranty coverage is limited to fewer components after 2 years or 24,000 miles.

EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSIONS DEFECT WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

INTERIOR FUSE PANEL IDENTIFICATION

Fuse panel is located in instrument panel, just to the left of steering column.

Scheme 6

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp - Brakelights, Hazard Warning Lights, Speed Control Shift Lock, High-Mount Brakelight (1988-92)
2. 2 - 8.25 Amp (Circuit Breaker) - Windshield Wiper & Washer Pump, Interval Wiper & Washer Fluid Level Indicator
3. 3 - (Blank)
4. 4 - 10 Amp (1983-87) - 15 Amp (1988-93) - Headlights (1988-89), Taillights & Parking Lights, Side Marker Lights, Instrument Cluster Illumination Lights, License Lights, Warning Chime
5. 5 - 15 Amp - Turn Signal & Back-Up Lights, Fluid Level Module, Heated Rear Window Relay, Convertible Top (1988-89)
6. 6 - 20 Amp - A/C Clutch, Luggage Compartment Lid Release, Speed Control Module, Clock/Radio Display, A/C Throttle Positioner, Graphic Warning Display Module (1984-87), Day/Night Illumination Relay, Heated Backlight Control (1983-87), Rear Window Defroster (1988-89)
7. 7 - (Blank) - 15 Amp (1992-93) Air Bag System
8. 8 - 15 Amp - Courtesy Lights, Glove Box Light (1986-93), Key Warning Chime, Radio & Power Mirror (1986-93), Fuel Filler Door Release (If Equipped) (1983-89), Engine Light (1988-93), Power Window (1988-89)
9. 9 - 15 Amp (1983-86) - Heater Blower 30 Amp (1987-93) A/C Blower Motor (1987), A/C & Heater Blower Motor (1988-93)
10. 10 - 20 Amp - Flash-to-Pass, Low Oil Warning Relay
11. 11 - 15 Amp - Radio/Clock & Tape Player, Premium Sound, Graphic Equalizer
12. 12 - 20 Amp (Circuit Breaker) (1983-87) - Power Door Locks (If Used) Blank (1989-89) 20 Amp (Circuit Breaker) (1990-92) Air Bag System 15 Amp Convertible Top
13. 13 - 5 Amp - Instrument Cluster Illumination Lights, Radio (Some Models) & Climate Control, Ashtray Light, Floor PRNDL Light, Dash Symbols & Lights (1988-92)
14. 14 - 20 Amp (Circuit Breaker) - Power Windows
15. 15 - Blank (1983-87) - 15 Amp (1988-93) Foglights
16. 16 - 20 Amp - Horn & Cigarette Lighter, Speed Control (1990-92), Electronic Console Clock (1984-89)
17. 17 - (Blank)
18. 18 - 15 Amp - Warning Indicator Lights, Throttle Solenoid Positioner, Low Fuel Module, Dual Timer Buzzer Or Chime, Tachometer, Engine Idle Track Relay, Seat Belt Chime, Carburetor (EFI) Circuits (1988-92), Restart Choke Control (1988-92), Cooling Fan/Compressor Clutch Control (1988-92), Choke Restart Control (1990-92), Fluid Module Display (1993)
