General Information: Other Ford Kuga II

SERVICE INFORMATION CONTENT

This article is divided into groups, each containing service information is numbered based on the component part number. Service information contents may include

1. Specifications Fluid capacities, component specifications and torque values not covered in other procedures
2. Description and Operation Overview of the system, component locations, and system operation
3. Diagnosis and Testing Symptom charts, DTC charts and diagnostic tests See the «DIAGNOSIS AND TESTING INFORMATION»(ref-658825-S18660612682014092900000) in this document
4. General Procedures Service adjustments, electronic programming and other special procedures
5. Removal and Installation Component removal and installation instructions
6. Disassembly and Assembly Component disassembly and assembly instructions

IMPORTANT INFORMATION

1. Critical Health and Safety Precautions - service safety precautions applicable to the entire service information. For additional information, Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-658825-S13390094942014092900000) .
2. A Symbols Glossary - definitions of the action directed by each symbol. For additional information, Refer to: «SYMBOLS GLOSSARY»(ref-658825-S24475828692014092900000) .
3. Diagnostic Methods - support information for diagnostics. For additional information, Refer to: «DIAGNOSTIC METHODS»(ref-658825-S35602924032014092900000) .

WARNINGS

Warnings provide information to avoid personal injury and to make sure service actions on critical safety systems are performed correctly. Warnings that apply to an entire system.

For additional information, Refer to: HEALTH AND SAFETY PRECAUTIONS .

NOTICES (in some publications, CAUTIONS)

Notices provide information to avoid damage to the vehicle or a component.

NOTES

Notes provide information critical for a complete and effective repair.

Warnings, Notices, or Notes that apply to an entire procedure will be placed at the beginning of the procedure. Warnings, Notices, or Notes that apply to a single step are placed at the beginning of the step. Those that apply to a group of steps will be placed at the first step requiring it.

Specified Chemicals or Materials

Throughout this service information, chemicals or materials are specified that must be used to properly complete a service procedure or diagnostic step. In the event a specific material is not readily available, a substitute material meeting the same specification may be used. Ford has not reviewed third party products for compliance with environmental, health or safety regulations and is not responsible for their use. Use of third party products is at your own risk. Additionally, such products may cause degraded performance, premature failures, and/or vehicle component damage. All chemicals or materials used for vehicle servicing should be checked for compliance with local environmental and health and safety regulations.

LH and RH Designations

All LH and RH designations are oriented from the driver's seat position looking forward.

Scheme 1

All LH and RH engine designations are oriented from the flywheel position looking toward the crankshaft pulley.

Powertrain LH and RH definition

Standard Practices

The following rules apply, unless specified differently in the procedure

FASTENERS

1. Reuse standard fasteners.
2. Replace fasteners with self-locking features. Examples of fastener self-locking coatings or mechanical locking (with the locking features highlighted yellow) are shown in the illustration.
3. Replace fasteners with torque angle specifications (those tightened a specified number of degrees).

Examples of self-locking nuts and bolts

SEALS AND GASKETS

Replace seals and gaskets, unless specified differently in the procedure.

EXTERIOR TRIM PARTS

Replace exterior trim parts fastened with glue or adhesive tape, unless specified differently in the procedure.

Mechanical Procedures

Illustrations in this service information may be used instead of written step instructions. Color-coding (see color scheme illustration) is used to communicate the required step action or actions. Service action icons may be used to add information regarding the required action.

For additional information, Refer to: SYMBOLS GLOSSARY .

Illustration Color-coding

Other color coding

1. Alternating Blue and White Chemical, adhesive or sealer apply areas
2. Red Sectioned or cut-away areas
3. Grey Background components shown for location information

ILLUSTRATION TASK SEQUENCE

Components that must be removed or installed in a specific sequence are identified with a numbered callout. Any associated step text is numbered accordingly.

Simple procedure example showing color-coding and task sequence

Black arrows are used to draw attention to components (usually fasteners). Arrows with multiples specified (here, x2) identify an identical number of fasteners or items. Callouts (numbers inside circles) show a required sequence or tightening torque.

In the illustration, the callouts indicate the removal sequence, which is reversed for installation . The yellow coloring of the hose indicates it is to be positioned aside (not removed). Two identical (magenta-colored) fasteners are indicated by the x2 arrow. The fasteners in this illustration require different torques (same torque for the x2 fasteners) so numbered callouts are used to identify them with torque values in the associated step text. The (magenta-colored) hose clamp is another fastener to be removed.

Examples of fastener removal sequence and an identical service action for 12 fasteners. Other possible symbols are shown on the right .

Scheme 2

HIDDEN DETAILS

Separate detail boxes or transparent components may be used to show hidden items in an illustration.

SERVICE ACTION ICONS

Service action icons may be used to add information regarding the required action.

For additional information, Refer to: SYMBOLS GLOSSARY .

Example of service action icons pointing to highlighted components

Movement arrows and service action icons show three dimensional or rotational movements .

Example of two illustrations used together with sequence steps, service action icons and special service tools

Tool symbols direct the use of standard tools. The tool size or dimension may be specified .

HEALTH AND SAFETY SYMBOLS

Some procedures may contain health and safety symbols that are associated with a specific service action. For additional information, Refer to: SYMBOLS GLOSSARY . Always read and understand all health and safety precautions before beginning any procedure. For additional information, Refer to: HEALTH AND SAFETY PRECAUTIONS .

ISO warning symbols may be used to indicate potential hazards .

MODULE DESCRIPTIVE NAMES

A descriptive name is sometimes added to the diagnostic scan tool name to clarify module function. The descriptive name will be followed by the diagnostic scan tool acronym in brackets.

1. Example: "Driver Active Motion Seat Module [SCMG]".
2. Driver Active Motion Seat Module is the descriptive name added to clarify the function of the SCMG.
3. The SCMG acronym is used by diagnostic scan tool, defined as "Seat Control Module G".

Symbols Glossary

Symbols are used inside the graphics and in the text area to enhance the information display.

Movement Symbols

Movement symbols provide detailed information to a required component movement. These component movements can be rotational or 1-3 dimensional movements.

Turn Symbols

Turn symbols are used to provide further information on the direction or angle of component turns.

Steering Wheel Symbols

Steering wheel symbols are used to provide further information to a required steering wheel position or steering column lock status.

Body Types

Body type symbols are used to identify different body configurations.

Gearshift lever and selector lever position symbols

Gearshift lever and selector lever position symbols are used to show the lever position that is required to be selected to carry out a procedure step.

Screwdriver symbols

The screwdriver symbols are used to show which screwdriver bit is recommended to carry out a procedure step.

Scheme 3

Pliers symbols

The pliers symbols are used to show which pliers is recommended to carry out a procedure step.

Drill symbols

The drill symbols are used to show which type and size of drill bit is recommended to carry out a procedure step.

Cutting tool symbols

The cutting tool symbols are used to show which type of cutting tool is recommended to carry out a procedure step.

Apply Chemical or load symbols

The apply chemical or load symbols are used to show where to apply which type of chemical or load to carry out a procedure step.

Measurement symbols

The measurement symbols are used to show where to measure which type of measurement to carry out a procedure step.

General equipment symbols

The general equipment symbols are used to show where to use which type of general equipment to carry out a procedure step.

Welding symbols

These symbols indicate the type of welding to be used.

Scheme 4

Drilling and grinding symbols

These symbols indicate the type of drilling or grinding to be used.

Material symbols

The material symbols are used to show where to use which type of material to carry out a procedure step.

Miscellaneous symbols

These symbols provide further information that is required to carry out a procedure step.

Mandatory Protective equipment - Health and safety symbols

The protective equipment symbols advise to use a mandatory protective equipment to avoid or at least reduce possible health and safety risks.

Prohibition - Health and safety symbols and component damage

The prohibition symbols are used to prohibit the specified actions to avoid or at least reduce possible component damage and health and safety risks.

Warning symbols - Health and safety and component damage

The warning symbols are used to advise on hazardous conditions to avoid or at least reduce possible component damage and health and safety risks.

General Service Warnings

Review carefully the information below before beginning any repair. Following these warnings is a list of specific system warnings that must be reviewed before beginning work on any listed system.

Carefully review the safety warnings for each system using the links below before beginning any service or repair.

For additional information, Refer to: HIGH VOLTAGE SYSTEM HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: BATTERY AND BATTERY CHARGING HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: BRAKE AND CLUTCH SYSTEMS HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: BODY REPAIR HEALTH AND SAFETY AND GENERAL PRECAUTIONS .

For additional information, Refer to: ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: GASOLINE AND GASOLINE-ETHANOL FUEL SYSTEMS HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: LIQUEFIED PETROLEUM GAS (LPG) AND COMPRESSED NATURAL GAS (CNG) FUEL SYSTEMS HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: SAFETY BELT AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS) HEALTH AND SAFETY PRECAUTIONS .

For additional information, Refer to: WHEEL AND TIRE HEALTH AND SAFETY PRECAUTIONS .

Checking Power-Providing Circuits

1. Measuring a power wire with the intended load disconnected using a Digital Multimeter (DMM) will only find open circuits (open fuse or wire).
2. Recommended practice: Circuits carrying approximately 200-1000 mA* may be loaded with a 250-350 mA test light. Measure circuit voltage with a Digital Multimeter (DMM) while the test light is connected and illuminated. A reduction in the voltage present during test-light-loading indicates excessive circuit resistance.
3. Recommended practice: Circuits carrying more than one ampere* should be loaded with a device requiring similar current (e.g., a headlamp bulb may be effective). A reduction in the voltage present during loading indicates excessive resistance.
4. *Circuit current is matched to wire gauge/size; Examples: Conductor sizes of 24 gauge (.5 mm) or smaller are generally used to carry approximately 1 ampere (1000 mA) or less. Use of the test light to load these circuits is appropriate. Conductor sizes of 20 gauge (.8 mm) or larger are generally used to carry approximately 5 amperes (5000 mA) or more. Match the substitute load (measure substitute load current first as necessary) to this current level.

Checking Ground-Providing Circuits

1. The best method of checking ground circuits is to measure the circuit voltage drop during component operation (or attempted operation).
2. An ohmmeter may be accurately used if the battery has been disconnected.
3. Recommended practice: Expect less than 2 ohms for most small diameter (18 gauge and smaller) wires.
4. Ohmmeter accuracy is limited to circuits carrying less than approximately 5 amperes (this is due to the fact that very small resistances, undetectable by a Digital Multimeter (DMM), cause significant voltage loss in higher current circuits).
5. Digital Multimeter (DMM) ohmmeter readings are easily corrupted by the normal voltage present (battery connected) in many ground circuits. Recommended practice: Reverse the leads and check for changes in the measurement. Reversing the Digital Multimeter (DMM) lead connections should never change the resistance measurement (unless the circuit contains a semi-conductor). Measurement (non-semi-conductor) differences when leads are interchanged at the test points indicate invalid test results. The presence of voltage corrupts the reading, and causes the meter reading to change when the leads are reversed.

Checking Circuit Continuity

1. Recommended practice: Expect less than 2 ohms of resistance for most wires.
2. Ohmmeter low-resistance resolution (approximately 0.1 ohm) limits its use to circuits carrying less than approximately 5 amperes. This is due to the fact that very small resistances, below the resolution of a Digital Multimeter (DMM), cause significant voltage loss in higher current circuits.
3. The Digital Multimeter (DMM) applies a small amount of voltage to the circuit or component to calculate resistance. As a result, Digital Multimeter (DMM) ohmmeters are very sensitive to any level of voltage present. Voltage present in the circuit will corrupt the Digital Multimeter (DMM) reading.

Checking For Unintended Continuity (Shorts) To Other Circuits

1. A Digital Multimeter (DMM) ohmmeter may be used to detect undesired circuit connections to: Ground Other unpowered circuits
2. Recommended practice: Expect greater than 10, 000 ohms of resistance between two separate circuits; the best result is an open circuit Digital Multimeter (DMM) indication (no detected resistance).
3. Shorts to voltage are checked with a voltmeter
4. Recommended practice: Turn ignition on (with battery connected) and measure the circuit for any voltage present (none should be present)

Checking Circuits By Back-Probing A Connector

1. Back-probing should be a testing method of last resort. It should only be employed where a diagnostic step requires a circuit to be tested under actual operating conditions. Back-probing is a risky testing method due to the uncertainty of the probe connection and the possibility of damaging terminals.
2. Do not force test leads or other probes into connectors. Adequate care must be exercised to avoid connector terminal damage while ensuring that good electrical contact is made with the circuit or terminal. Failure to follow these instructions may cause damage to wiring, terminals, or connectors and subsequent electrical faults. Use back probes specifically designed for the purpose to assist in making a good test connection and to prevent connector or terminal damage during back-probing.
3. Do not test for the presence of voltage at a single point where zero volts is a possible result (you cannot tell the difference between a bad probe contact and a zero volt result).
4. Do not test for continuity/opens (using an ohmmeter) between two points (you cannot tell the difference between bad probe contacts and an open circuit).
5. Back-probing may be used where the circuit must be analyzed with the voltage-drop method (if the circuit carries greater than 5 amperes and no other means of testing will definitively eliminate circuit resistance as a possible fault). A zero-volt result indicates incorrect test conditions (no current flow) or bad back-probe connections.
6. Occasionally, module failure mode behavior will change the operation of a circuit when it is opened for testing. Back-probing is an acceptable remedy for these testing dilemmas.

Circuit Analysis Using Jumper Wires (Creating Substitute Circuits)

1. Jumper wires may be employed for circuit analysis.
2. CAUTION: Always use fused jumper wires - the recommended universal-testing jumper wire fuse is 2-5 amperes; larger fuse ratings should be used only in special circumstances. Use flex probes or equivalent to prevent connector terminal damage (flex probes are not intended to carry higher currents necessary to operate motors such as a cooling fan or blower motor). Follow workshop service information testing directions when using jumper wires to avoid component or harness damage due to incorrect jumper connections. Never repair a circuit by adding a new wire in parallel to the old one (overlaying the circuit) without fully understanding what caused the circuit to fail. Always find, examine, and repair the fault to correct the root cause and to repair any adjacent wiring that has been damaged.

Checking Modules

1. Generally, module failure rate is very low and therefore replacement modules usually do not resolve the root cause. Incorrect replacement of a module is often the result of inadequate testing. Understand the correct module function. Make sure programmable parameters are set correctly for the function in question (Refer to «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(ref-658827-S36740861182014092900000) Module Configuration for more information). Resolve DTCs first - as directed by Diagnostic Routines. Test all inputs, both hard-wired and networked. Test outputs (see "Checking module switching circuits" below). Check applicable TSBs for module software changes (flash programming).
2. Checking module switching circuits. Using the scan tool module-output command function (for example, IDS Output State Control) to activate components is a fast way to confirm an output is capable of being switched on by the module. Testing that reveals normal module-output function confirms the need to analyze the module inputs. Don't apply ground or power directly to module-switched components with jumper wires (unless directed by a workshop service information procedure), as the component could be damaged by a direct connection to ground/power.
