| Item | Specification |
|---|
| Displacement | 122 in 3 (2 L) |
| No. of cylinders | 4 |
| Bore | 3.4449 in (87.5 mm) |
| Stroke | 3.2717 in (83.1 mm) |
| Firing order | 1-3-4-2 |
| Compression ratio | 9.3:1 |
| Spark plug | 12405 |
| Spark plug gap | 0.031 in (.8 mm) |
| Engine weight - (without accessory drive components and flexplate) | 311 lb (141 kg) |
Overview
The 2.0L Gasoline Turbocharged Direct Injection (GTDI) 4-cylinder engine has the following features
- Dual overhead camshafts
- Four valves per cylinder
- Composite intake manifold
- Aluminum cylinder head
- Aluminum cylinder block
- GTDI
- Twin Independent Variable Camshaft Timing (Ti-VCT)
Engine Identification
Always refer to these labels when installation of new parts is necessary or when checking engine calibrations. The engine parts often differ within a CID family. Verification of the identification codes will make sure the correct parts are obtained. The codes contain all the pertinent information relating to the dates, optional equipment and revisions.
Scheme 528
Scheme 528: Engine Code Information Label
| Item | Description |
|---|
| 1 | Engine part number |
| 2 | Valencia Engine Plant |
| 3 | Plant code |
| 4 | Engine serial number |
| 5 | Engine displacement |
| 6 | Engine build date YYM (A-L) DD |
Scheme 529
Scheme 529: Engine Cylinder Identification
Scheme 530
Scheme 530: Engine Oil Flow Illustration
| Item | Description |
|---|
| 1 | Oil pump screen and pickup tube |
| 2 | Oil pump |
| 3 | Turbocharger oil return tube |
| 4 | Turbocharger oil return tube gasket |
| 5 | Timing chain tensioner |
| 6 | Turbocharger oil filter |
| 7 | Cylinder block |
| 8 | Turbocharger oil supply tube |
| 9 | Turbocharger |
| 10 | Intake VCT phaser and sprocket |
| 11 | Exhaust VCT phaser and sprocket |
| 12 | Exhaust camshaft |
| 13 | Camshaft front bearing cap (part of 6049) |
| 14 | VCT oil control solenoid |
| 15 | VCT oil control solenoid |
| 16 | Camshaft rear bearing cap (part of 6049) |
| 17 | Fuel pump housing |
| 18 | Intake camshaft |
| 19 | Vacuum pump |
| 20 | Cylinder head |
| 21 | Head gasket |
| 22 | Crankcase vent oil separator |
| 23 | Oil filter adapter gasket |
| 24 | Oil Filter Adapter |
| 25 | EOP switch |
| 26 | Oil filter |
| 27 | Crankshaft assembly |
| 28 | Balance shaft assembly |
| 29 | Oil pan |
