Suspension Front 12 illustrations ~180 words

Wheel Bearing and Wheel Hub

Special Tools Illustration Tool Name Tool Number Installer, Wheel Hub Bearing Cup 205-147 Pinion Bearing Cone Remover 205-D002 (D79L-4621-A) or equivalent Remover/Installer, Wheel Hub Cup 204-020 Step Plate 205-117

Scheme 11

Scheme 11: Wheel Bearing and Wheel Hub

Item	Part Number	Description
1	1104	Wheel hub
2	3B625	Snap ring
3	1215	Wheel bearing
4	2K005 LH/ 2K004 RH	Disc brake shield
5	3K171 LH/ 3K170 RH	Wheel knuckle

Lower Arm - Front

Special Tools Illustration Tool Name Tool Number Adapter for 204-592 204-592/1 Separator, Ball Joint 204-592

Scheme 12

Scheme 12: Lower Arm - Front

Scheme 13

Scheme 14

Item	Part Number	Description
1	3A423	Lower arm (front)
2	W500550	Damper fork-to-lower arm bolt
3	3C499	Lower ball joint nut (front)
4	3C156	Damper
5	W712840	Front lower arm-to-subframe bolt
6	3C347	Damper fork-to-lower arm flag nut

Lower Arm - Rear

Special Tools Illustration Tool Name Tool Number Adapter for 204-592 204-592/1 Separator, Ball Joint 204-592

Scheme 15

Item	Part Number	Description
1	3079 LH/ 3078 RH	Lower arm (rear)
2	3C499	Lower ball joint nut (rear)
3	W500752	Rear lower arm-to-subframe bolt
4	999581222	Washer
5	W520416	Subframe bracket-to-subframe nut (2 required)
6	5A552	Subframe bracket-to-subframe washer (2 required)
7	3B155 LH/ 3B154 RH	Subframe bracket (2 required)
8	3C496	Subframe bracket-to-body bolts (4 required)
9	5E212	Catalytic converter
10	W705443	Catalytic converter manifold-to-exhaust flexible pipe nuts (2 required)

Upper Arm

Special Tools Illustration Tool Name Tool Number Remover, Steering Arm 211-003 (T64P-3590-F)

Scheme 16

Scheme 16: Upper Arm

Item	Part Number	Description
1	3091 LH/ 3084 RH	Upper arm
2	3C498	Upper ball joint nut
3	W500525	Upper arm-to-body bolt (2 required)
4	5B800	Shock absorber upper mount nut (3 required)
5	W500020	Wheel speed sensor harness bolt
6	W500222	Wheel speed sensor bolt
7	2C204 RH/ 2C205 LH	Wheel speed sensor

Stabilizer Bar Bushing

Special Tools Illustration Tool Name Tool Number Remover, Tie-Rod End 211-105 (T85M-3395-A)

Scheme 17

Scheme 17: Stabilizer Bar Bushing

Scheme 18

Item	Part Number	Description
1	W705443	Catalytic converter-to-exhaust flexible pipe nuts (2 required)
2	W711918	Rear driveshaft-to-Power Transfer Unit (PTU) bolt (4 required)
3	5006930	Rear driveshaft assembly
4	5E212	Catalytic converter
5	3R827	Steering column shaft bolt
6	3C611B	Steering column shaft-to-dash seal
7	5801691	Lower steering column shaft joint cover nut (2 required)
8	3C611A	Lower steering column shaft joint cover

Scheme 19

Item	Part Number	Description
9	W520414	Stabilizer bar bracket nut (4 required)
10	5486	Stabilizer bar bushing bracket (2 required)
11	5484	Stabilizer bar bushing (2 required)
12	3C497	Steering gear-to-subframe bolt (3 required)

Stabilizer Bar
