REMOVAL AND INSTALLATION
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-291849) article.
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-291883) article.
- If equipped, remove the 7 screws and the underbody cover.
- Remove the starter motor solenoid wire nut and position the wire aside. To install, tighten to 5 Nm (44 lb-in).
- Position the starter motor solenoid battery cable terminal cover aside.
- Remove the starter motor solenoid battery cable nut and position the cable aside. To install, tighten to 12 Nm (9 lb-ft).
- Disconnect the wiring harness retainer from the starter motor stud bolt and position the wiring harness aside.
- Remove the starter motor bolt, stud bolt and the starter motor. To install, tighten to 25 Nm (18 lb-ft).
- To install, reverse the removal procedure.
Scheme 17
| Item | Part Number | Description |
|---|---|---|
| 1 | N805320 | Starter motor solenoid wire nut |
| 2 | 14463 | Starter motor solenoid wire (part of 12B637) |
| 3 | 14603 | Starter motor solenoid battery cable terminal cover |
| 4 | W706414 | Starter motor solenoid battery cable nut |
| 5 | 14463 | Starter motor solenoid battery cable (part of 14B060) |
| 6 | W503297 | Starter motor bolt (2 required) |
| 7 | 11000 | Starter motor |
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
- Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-291883) article.
- Remove the starter motor solenoid wire nut and position the wire aside. To install, tighten to 5 Nm (44 lb-in).
- Position the starter motor solenoid terminal battery cable cover aside.
- Remove the starter motor solenoid battery cable nut and position aside the cable. To install, tighten to 12 Nm (9 lb-ft).
- Remove the 2 starter motor bolts and the starter motor. To install, tighten to 27 Nm (20 lb-ft).
- To install, reverse the removal procedure.
Scheme 18
| Item | Part Number | Description |
|---|---|---|
| 1 | 14197 | Starter motor wire harness pin-type retainer (part of 14B060) |
| 2 | N805320 | Starter motor solenoid wire nut |
| 3 | 14463 | Starter motor solenoid wire (part of 14B060) |
| 4 | 14603 | Starter motor solenoid battery cable terminal cover |
| 5 | W706414 | Starter motor solenoid battery cable nut |
| 6 | 14463 | Starter motor solenoid battery cable (part of 14B060) |
| 7 | W503297 | Starter motor bolt (2 required) |
| 8 | 11000 | Starter motor |
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
- Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-291883) article.
- Detach the starter motor wire harness pin-type retainer.
- Remove the starter motor solenoid wire nut and position the wire aside. To install, tighten to 5 Nm (44 lb-in).
- Position the starter motor solenoid terminal battery cable cover aside.
- Remove the starter motor solenoid battery cable nut and position aside the cable. To install, tighten to 12 Nm (9 lb-ft).
- Remove the 2 starter motor bolts and the starter motor. To install, tighten to 27 Nm (20 lb-ft).
- To install, reverse the removal procedure.
