Rear View Mirrors: Removal & Installation Ford Fusion I рестайлинг

REMOVAL AND INSTALLATION

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-291874) article.
2. Remove the front door sail panel. If equipped, disconnect the speaker electrical connector.
3. Disconnect the exterior mirror electrical connector.
4. Remove the 3 exterior mirror nuts and the exterior mirror. To install, tighten to 8 Nm (71 lb-in).
5. To install, reverse the removal procedure.

REMOVAL

1. Position the exterior mirror glass in the full down position.
2. Pull the upper edge of the exterior mirror glass outward and then upward to release the locking tabs from the exterior mirror motor.
3. If equipped with heated mirrors, disconnect the electrical connectors from the exterior mirror glass.

INSTALLATION

1. If equipped with heated exterior mirrors, connect the electrical connectors to the exterior mirror glass.
2. Install the lower exterior mirror glass onto the exterior mirror motor.
3. Position the exterior glass upward.
4. Place a hand against the back of the exterior mirror and a hand flat against the upper exterior mirror glass and press the exterior mirror glass into the upper exterior mirror motor retainers.

1. Remove the window control switch bezel in the following sequence. Remove the window control switch screw. Disconnect the electrical connectors.
2. Remove the exterior mirror control switch. Depress the 2 locking tabs.
3. To install, reverse the removal procedure.

1. Remove the wire cover (if equipped).
2. Remove the compass by pulling down on the compass rearmost edge (if equipped).
3. Insert the special tool between the mirror mount and windshield bracket from the bottom.
4. Release the mirror mount from windshield bracket by pulling the tool away from the windshield.

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
2. Using the special tool, press the mirror assembly downward along the windshield until the mount is seated on the windshield bracket.
3. Install compass and wire cover (if equipped).

Auto-Dimming Interior Mirror

Special Tools Illustration Tool Name Tool Number Mirror Remover 501-D118

Scheme 65

1. Remove the wire cover.
2. Disconnect the electrical connector.
3. Insert the special tool between the mirror mount and windshield bracket from the top.
4. Release the mirror mount from the windshield bracket by pulling the tool and mirror down and away from the windshield.

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the upward position.
2. Quickly press the mirror assembly downward along the windshield until a click is felt. The click indicates the base is engaged to the windshield bracket.
3. Connect the electrical connector and wire cover.
4. If equipped, check the compass zone and calibration. For additional information, refer to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(ref-291880) article.
