REMOVAL AND INSTALLATION
- Open the overhead console storage door to access the screws. Remove the 2 screws.
- Pull the overhead console down and remove the console from the headliner retainer. Disconnect the electrical connector.
- To install, reverse the removal procedure.
Scheme 15
| Item | Part Number | Description |
|---|---|---|
| 1 | 13783 | Rear interior lamp lens |
| 2 | 13776 | Rear interior lamp |
| 3 | Rear interior lamp electrical connector (part of 14334) |
- Remove the rear interior lamp lens.
- Release the 2 retaining clips (through the access holes) and remove the rear interior lamp assembly. Disconnect the electrical connector.
- To install, reverse the removal procedure.
Scheme 16
| Item | Part Number | Description |
|---|---|---|
| 1 | W701679 | Ambient lighting module screws (2 required) |
| 2 | Ambient lighting module electrical connector (part of 14D375) | |
| 3 | 13C788 | Ambient lighting module |
- Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-291890) article.
- Remove the 2 screws and the ambient lighting module. Disconnect the electrical connector.
- To install, reverse the removal procedure.
Scheme 17
| Item | Part Number | Description |
|---|---|---|
| 1 | 044D90 | Floor console trim panel |
| 2 | Center console electrical connectors (part of 14014) | |
| 3 | Ambient lighting switch electrical connector (part of 14D375) | |
| 4 | Ambient lighting switch |
- Remove the floor console trim panel. Disconnect the electrical connectors.
- Squeeze the retaining tabs and remove the ambient lighting switch.
- To install, reverse the removal procedure.
