Vehicle Dynamic Systems: Removal & Installation Ford Fusion I рестайлинг

Anti-Lock/traction Control 4 illustrations ~445 words

REMOVAL AND INSTALLATION

WARNINGDo not use any fluid other than clean brake fluid meeting manufacturer's specification. Additionally, do not use brake fluid that has been previously drained. Following these instructions will help prevent system contamination, brake component damage and the risk of serious personal injury.
WARNINGCarefully read cautionary information on product label. For EMERGENCY MEDICAL INFORMATION seek medical advice. In the USA or Canada on Ford/Motorcraft products call: 1-800-959-3673. For additional information, consult the product Material Safety Data Sheet (MSDS) if available. Failure to follow these instructions may result in serious personal injury.
CAUTIONBrake fluid is harmful to painted and plastic surfaces. If brake fluid is spilled onto a painted or plastic surface, immediately wash it with water.
  1. Remove the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-291897) article.
  2. Disconnect the ABS module electrical connector.
  3. Disconnect the brake tube fittings. To install, tighten to 17 Nm (150 lb-in).
  4. Remove the hydraulic control unit (HCU) bracket-to-frame nut. To install, tighten to 23 Nm (17 lb-ft).
  5. Remove the HCU bracket-to-frame bolt. To install, tighten to 23 Nm (17 lb-ft).
  6. Remove the HCU bracket-to-frame stud. To install, tighten to 23 Nm (17 lb-ft).
  7. Remove the HCU and bracket.
  8. Remove the HCU bracket-to-HCU bolt and remove the bracket. To install, tighten to 9 Nm (80 lb-in).
  9. To install, reverse the removal procedure. Bleed the brake system. For additional information, refer to «BRAKE SYSTEM - GENERAL INFORMATION»(ref-291855) article.

Scheme 13

Scheme 13: Anti-Lock Brake System (ABS) Module
Scheme 13: Anti-Lock Brake System (ABS) Module
ItemPart NumberDescription
1ABS module electrical connector (part of 14290)
22M101ABS module screw (3 required)
32C219ABS module
CAUTIONElectronic modules are sensitive to electrical charges. The anti-lock brake system (ABS) module can be damaged if exposed to these charges.
CAUTIONDo not allow any brake fluid or foreign material to enter the mating side of the anti-lock brake system (ABS) module or damage to the solenoids can occur.
  1. Remove the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-291897) article.
  2. Disconnect the ABS module electrical connector.
  3. Remove the 3 ABS module screws and the ABS module. To install, tighten to 2 Nm (18 lb-in).
  4. To install, reverse the removal procedure.

Scheme 14

Scheme 14: Wheel Speed Sensor - Front
Scheme 14: Wheel Speed Sensor - Front
ItemPart NumberDescription
1Wheel speed sensor electrical connector (part of 14A227)
2W500020Wheel speed sensor harness bracket-to-body bolt
3Wheel speed sensor harness bracket-to-wheel knuckle bolt
4W500222Wheel speed sensor bolt
52C204 RH/ 2C205 LHWheel speed sensor
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-291849) article.
  2. Remove the retainers and position the fender splash shield aside.
  3. Disconnect the wheel speed sensor electrical connector.
  4. Remove the 2 wheel speed sensor harness bracket bolts. To install: Tighten the bracket-to-wheel knuckle bolt to 23 Nm (17 lb-ft). Tighten the bracket-to-body bolt to 7 Nm (62 lb-in).
  5. Remove the front wheel speed sensor bolt from the knuckle and remove the wheel speed sensor. To install, tighten to 23 Nm (17 lb-ft).
  6. To install, reverse the removal procedure.

Scheme 15

Scheme 15: Wheel Speed Sensor - Rear, Front Wheel Drive (FWD)
Scheme 15: Wheel Speed Sensor - Rear, Front Wheel Drive (FWD)
ItemPart NumberDescription
1Wheel speed sensor electrical connector (part of 14A227)
2W500222Wheel speed sensor bolt
32C186 RH/ 2C187 LHWheel speed sensor
  1. Remove the rear seat bolster. For additional information, refer to «SEATING»(ref-291875) article.
  2. Disconnect the wheel speed sensor electrical connector.
  3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-291849) article.
  4. Using a suitable tool, disconnect the grommet from the body.
  5. Disconnect the wheel speed sensor harness from the brackets.
  6. Remove the wheel speed sensor wire bolt and the wheel speed sensor. To install, tighten to 23 Nm (17 lb-ft).
  7. To install, reverse the removal procedure.

Scheme 16

Scheme 16: Wheel Speed Sensor - Rear, All Wheel Drive (AWD)
Scheme 16: Wheel Speed Sensor - Rear, All Wheel Drive (AWD)
ItemPart NumberDescription
1Wheel speed sensor electrical connector (part of 14A227)
2W505253Wheel speed sensor harness bolt
32C186 RH/ 2C187 LHWheel speed sensor
4W520102Wheel speed sensor harness nut
5W500222Wheel speed sensor bolt
  1. Remove the rear seat bolster. For additional information, refer to «SEATING»(ref-291875) article.
  2. Disconnect the wheel speed sensor electrical connector.
  3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-291849) article.
  4. Using a suitable tool, disconnect the grommet from the body.
  5. Remove the wheel speed sensor harness nut and bolt. To install, tighten to 23 Nm (17 lb-ft).
  6. Remove the wheel speed sensor wire bolt and the wheel speed sensor. To install, tighten to 23 Nm (17 lb-ft).
  7. To install, reverse the removal procedure.
