TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Front impact severity sensor bolt | 12 |
| Occupant classification sensor (OCS) system rail mounting bolts | 25 |
| Passenger air bag module bolts | 8 |
| Restraints control module (RCM) bolts | 12 |
| Seat position sensor bolt | 6 |
| Seat risers-to-OCS system rail bolts | 25 |
| Side air bag module bolt | 10 |
| Side air curtain module bolts | 7 |
| Side impact sensor (B-pillar) bolt | 12 |
| Side impact sensor (C-pillar) bolt | 12 |
TORQUE SPECIFICATIONS
The air bag supplemental restraint system (SRS) is designed to provide increased collision protection for front seat and second row outboard occupants, in addition to that provided by the 3-point safety belt system. Safety belt use is necessary to obtain the best occupant protection and to receive the full advantage of the SRS.
This vehicle line contains dual stage deployment (advanced restraint system) driver and front passenger air bag modules. These vehicles are also equipped with driver and front passenger safety belt retractor pretensioners, side air curtains and seat side air bag modules in the front seats.
Side air curtains deploy from the headliner, protecting the first and second row outboard occupants during a side impact. Seat side air bag modules deploy from the outboard front seat backrest upon a side impact. In addition, a front impact severity sensor is mounted to the lower radiator support, a seat position sensor is mounted to the driver seat and a usage detection switch is added to the front driver and passenger outboard buckles.
Vehicles are also equipped with an occupant classification sensor (OCS) system as part of the front passenger seat. The OCS includes 2 OCS rails and an occupant classification system module (OCSM).
The serviceable air bag and safety belt pretensioner SRS components are shown in the following illustration.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 04338 | Passenger air bag cover (part of kit) |
| 2 | 13D734 | Passenger air bag deactivation (PAD) indicator |
| 3 | 14B345 | Passenger side first row impact sensor |
| 4 | 611B08 | Passenger safety belt retractor pretensioner |
| 5 | 611D10 | Passenger seat side air bag module |
| 6 | 14B004 | Second row RH side impact sensor |
| 7 | 042D94 RH/ 042D95 LH | Side air curtain modules |
| 8 | 14B004 | Second row LH side impact sensor |
| 9 | 611D11 | Driver seat side air bag module |
| 10 | 611B09 | Driver safety belt retractor pretensioner |
| 11 | 14B345 | Driver side first row impact sensor |
| 12 | 043B13 | Driver air bag module |
| 13 | 14B416 | Driver seat track position sensor |
| 14 | 14A664 | Clockspring |
| 15 | 14B422 | Occupant classification system module (OCSM) |
| 16 | 14B321 | Restraints control module (RCM) |
| 17 | 14B004 | Front impact severity sensor |
| 18 | 61708 | Occupant classification system (OCS) rails (2 required) |
| 19 | 044A74 | Passenger air bag module assembly |
Refer to SYSTEM WIRING DIAGRAMS article for Fusion, SYSTEM WIRING DIAGRAMS article for Milan or SYSTEM WIRING DIAGRAMS article for MKZ for schematic and connector information.
Special Tools Illustration Tool Name Tool Number Flex Probe Kit 105-R025C or equivalent FLUKE 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
