Roof Opening Panel

The roof opening panel system consists of the following components

  1. Roof opening panel glass
  2. Roof opening panel shield (sunshade)
  3. Roof opening panel switch
  4. Roof opening panel motor and module assembly
  5. Roof opening panel trough
  6. Roof opening panel frame drain hoses
  7. Roof opening panel assembly

Refer to SYSTEM WIRING DIAGRAMS - FIVE HUNDRED , SYSTEM WIRING DIAGRAMS - FREESTYLE or SYSTEM WIRING DIAGRAMS - MONTEGO for schematic and connector information.

SPECIAL TOOL(S) DESCRIPTION 73111 Automotive Meter 105-R0057 or equivalent

The roof opening panel assembly uses an integrated motor and module to operate the roof opening panel. The roof opening panel motor and module are installed new as an assembly. The roof opening panel is an electronically operated glass panel that can be opened, closed or tilted by the roof opening panel switch. Actuating the switch in either a forward or rearward motion supplies a ground to the roof opening panel motor/module. The roof opening panel has an express open feature that is activated when the switch is momentarily pressed to the double detent OPEN position. This function is controlled by the roof opening panel motor/module.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Possible Causes

  1. Incorrect roof opening panel adjustment
  2. Poorly fitting roof opening panel seal/weatherstrip
  3. Incorrect installation of the roof opening panel and motor/module
  1. Incorrect roof opening panel adjustments
  2. Damaged roof opening panel drain hoses
  3. Roof opening panel not fully closed
  4. Damaged roof opening panel seal/weatherstrip
  5. Damaged roof opening panel frame
  6. Incorrect position of the roof opening panel glass

Rattling noises from the roof opening panel can be caused by any of the following loosely or incorrectly installed components

  1. Roof opening panel
  2. Roof opening panel air deflector assembly
  3. Roof opening panel water trough
  4. Roof opening panel lifter assemblies
  5. Headliner
  6. Roof opening panel motor/module pad
  7. Roof opening panel frame
  1. Obstructed or damaged roof opening panel
  2. Obstructed or damaged roof opening panel lifter assemblies
  3. Incorrect roof opening panel adjustment
  4. Noisy roof opening panel motor/module assembly
  1. Fuse(s)
  2. Open in circuits 2086 (RD/LB), 1205 (BK), 1173 (BN/OG), 692 (RD), 691 (DB) or 1175 (TN/RD)
  3. Inoperative roof opening panel switch
  4. Inoperative roof opening panel motor/module assembly
  5. Inoperative accessory delay relay
  6. Roof opening panel motor not initialized

Scheme 10

Scheme 10: PINPOINT TEST E: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14
  1. E1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. Refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-255323-S18105620952007053000000) . Is the concern still present? Yes: GO to E2 . No: The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. E2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? Yes: GO to E3 . No: REFER to «DELAYED ACCESSORY POWER»(ref-255263-S35134534022007053000000) to diagnose the accessory delay relay circuit.
  3. E3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch. Carry out the roof opening panel switch component test. Refer to «SYSTEM WIRING DIAGRAMS - FIVE HUNDRED»(ref-231699) , «SYSTEM WIRING DIAGRAMS - FREESTYLE»(ref-231702) and «SYSTEM WIRING DIAGRAMS - MONTEGO»(ref-231719) for component testing. Is the roof opening panel switch OK? Yes: GO to E4 . No: INSTALL a new roof opening panel switch. TEST the system for normal operation.
  4. E4 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUIT 2086 (RD/LB) AND 692 (RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921. Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit 2086 (RD/LB) and C921-6, circuit 692 (RD), harness side and ground. Are the voltages greater than 10 volts, but less than 16 volts? Yes: GO to E5 . No: VERIFY SJB fuse 15 (10A) and BJB fuse 6 (20A) are OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  5. E5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT 1205 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921-1, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes: GO to E6 . No: REPAIR the circuit. TEST the system for normal operation.
  6. E6 CHECK CIRCUIT 1173 (BN/OG) FOR AN OPEN Measure the resistance between overhead console C930-2, circuit 1173 (BN/OG), and roof opening panel motor/module C921-2, circuit 1173 (BN/OG) harness side. Is the resistance less than 5 ohms? Yes: CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1173 (BN/OG) between the roof opening panel switch socket and overhead console C930-2. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E7 . No: REPAIR the circuit. TEST the system for normal operation.
  7. E7 CHECK CIRCUIT 1175 (TN/RD) FOR AN OPEN Measure the resistance between overhead console C930-5, circuit 1175 (TN/RD), and roof opening panel motor/module C921-10, circuit 1175 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes: CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1175 (TN/RD) between the roof opening panel switch socket and overhead console C930-5. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E8 . No: REPAIR the circuit. TEST the system for normal operation.
  8. E8 CHECK CIRCUIT 691 (DB) FOR AN OPEN Measure the resistance between overhead console C930-1, circuit 691 (DB), and roof opening panel motor/module C921-5, circuit 691 (DB) harness side. Is the resistance less than 5 ohms? Yes: CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 691 (DB) between the roof opening panel switch socket and overhead console C930-1. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness, and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E9 . No: REPAIR the circuit. TEST the system for normal operation.
  9. E9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new roof opening panel motor/module. Refer to «ROOF OPENING PANEL MOTOR»(ref-255323-S16480788792007053000000) . TEST the system for normal operation. No: The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.
  1. Open in circuits 1174 (WH/RD) or 1175 (TN/RD)
  2. Inoperative roof opening panel switch
  3. Inoperative roof opening panel motor/module assembly

Scheme 15

Scheme 15: PINPOINT TEST F: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE IN VENT POSITION

Scheme 16

Scheme 16
  1. F1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-255323-S18105620952007053000000) . Is the concern still present, or does the roof opening panel motor fail to initialize? Yes: GO to F2 . No: The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. F2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch. Carry out the roof opening panel switch component test. Refer to «SYSTEM WIRING DIAGRAMS - FIVE HUNDRED»(ref-231699) , «SYSTEM WIRING DIAGRAMS - FREESTYLE»(ref-231702) and «SYSTEM WIRING DIAGRAMS - MONTEGO»(ref-231719) for component testing. Is the roof opening panel switch OK? Yes: GO to F3 . No: INSTALL a new roof opening panel switch. TEST the system for normal operation.
  3. F3 CHECK CIRCUIT 1174 (WH/RD) FOR AN OPEN Measure the resistance between overhead console C930-6, circuit 1174 (WH/RD), and roof opening panel motor/module C921-4, circuit 1174 (WH/RD) harness side. Is the resistance less than 5 ohms? Yes: CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1174 (WH/RD) between the roof opening panel switch socket and overhead console C930-6. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to F4 . No: REPAIR the circuit. TEST the system for normal operation.
  4. F4 CHECK CIRCUIT 1175 (TN/RD) FOR AN OPEN Measure the resistance between overhead console C930-5, circuit 1175 (TN/RD), and roof opening panel motor/module C921-10, circuit 1175 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes: CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1175 (TN/RD) between the roof opening panel switch socket and overhead console C930-5. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to F5 . No: REPAIR the circuit. TEST the system for normal operation.
  5. F5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new roof opening panel motor/module. refer to «ROOF OPENING PANEL MOTOR»(ref-255323-S16480788792007053000000) . TEST the system for normal operation. No: The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Scheme 17

Scheme 17: Roof Opening Panel Manual Operation
  1. Remove the LH and RH A-pillar trim panels. Position the weatherstrip aside near the A-pillar. Pull the outboard edge of the A-pillar trim panel toward the inside of the vehicle to disengage the retaining clips. Pull the A-pillar trim panel upward to remove from the dash panel.
  2. Remove the LH and RH sun visor assemblies. Remove the 3 sun visor retaining screws. Disconnect the sun visor wire harness electrical connector. Remove the sun visor arm clip screw. Remove the sun visor arm clip.
  3. Remove the overhead console. Open the bin and remove the screws. Disconnect the overhead console electrical connector.
  4. If equipped, disconnect the auto-dimming electrical connector from the interior rear view mirror.
  5. Pull down front of headliner to gain access to the roof opening panel motor.
  6. Insert an Allen wrench into the center of the manual drive hole. Rotate the Allen wrench counterclockwise until the roof opening panel is closed.

Roof Opening Panel Motor Initialization

CAUTIONBe sure there are no obstructions in the path of the roof opening panel glass before attempting to initialize the roof opening panel motor.

Note. A new roof opening panel motor will only vent and must be initialized. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Pinpoint Test F

F2 For an existing roof opening panel motor,
F3 For a new roof opening panel motor,
  1. For an existing motor, press and hold the switch in the VENT position (for approximately 10 seconds) until the roof opening panel glass moves past full VENT, then to full VENT, then quickly release the switch.

Roof Opening Panel - Exploded View

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION . Roof opening panel with rear entertainment system shown, roof opening panel without rear entertainment system similar.

Scheme 18

Scheme 18: Roof Opening Panel - Exploded View
  1. For additional information, refer to the appropriate procedure.
