GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants | |
| MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US ); XT-2-LM12 (Canada) | MERCON® |
| Power Steering Gear | |
| Fluid capacity | 1.13 L (2.4 pt) |
| Turning effort | 2.27 kg (5 lb) |
| Turns lock-to-lock | 2.86 |
| Power Steering Purge Vacuum | |
| Vacuum | 68-85 kPa (20-25 in/Hg) |
| Power Steering Pump | |
| Flow | 9.42 liters/minute (2.48 gpm) Fluid @ 74-80°C (165-176°F) Engine at idle |
| Pressure | 414 kPa (60 psi) Fluid @ 74-80°C (165-176°F) Engine at idle |
| Minimum capacity | 4.33 liters/minute (1.14 gpm) Fluid @ 74-80°C (165-176°F) Engine at idle Pressure at 5,102 kPa (740 psi) |
| Relief pressure | 9,997-10,894 kPa (1,450-1,580 psi) |
GENERAL SPECIFICATIONS
The steering system consists of
- power steering pump
- fluid reservoir
- rack and pinion steering gear
- fluid cooler
- power steering pressure and return lines/hoses
- steering column
- steering column switches
SPECIAL TOOL(S) Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Dial Thermometer 0-220°F 023-R0007 or equivalent 100W/12 Volt DC UV Lamp 164-R0751 Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent Evacuation Cap, Power Steering 211-265 or equivalent
Scheme 16
Scheme 17
Scheme 18
| Item | Specification |
|---|---|
| MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US); XT-2-LM12 (Canada) | MERCON® |
| Automatic Transmission/Power Steering Dye 164-R3701 or equivalent |
MATERIAL
