Removal
| CAUTION | Suspension fasteners are critical parts because they affect performance of vital parts and systems and their failure can result in major service expense. A new part with the same part number must be installed if installation becomes necessary. Do not use a replacement part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure of correct retention of these parts. |
Scheme 1
Scheme 2
- Remove both rear springs. For additional information, refer to «REAR SUSPENSION»(ref-255397) .
- Remove both rear lower control arms. For additional information, refer to «REAR SUSPENSION»(ref-255397) .
- Remove the stabilizer bar. For additional information, refer to «REAR SUSPENSION»(ref-255397) .
- Remove and discard the front lower arm inboard bolts. To install, tighten to 115 Nm (85 lb-ft).
- Remove and discard the upper arm inboard bolts. To install, tighten to 115 Nm (85 lb-ft).
- Support the wheel knuckle and trailing arm assembly using a tie strap or other suitable holding device.
- Using a suitable jack stand, support the exhaust system.
- Detach the exhaust system from the crossmember exhaust hanger isolator.
- Using a suitable jack, support the crossmember.
- Remove the 6 crossmember bolts. To install, tighten to 103 (76 lb-ft).
- Lower the jack and remove the crossmember.
- To install, reverse the removal procedure.
- Check and, if necessary, adjust the rear toe. For additional information, refer to «SUSPENSION SYSTEM-GENERAL INFORMATION»(ref-255383) .
