GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants | |
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 (Canada CPM-1) | ESA-M6C25-A or WSS-M6C62-A |
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Anti-lock brake system (ABS) module to hydraulic control unit (HCU) bolts | 2 |
| Brake tube fittings | 18 |
| HCU bracket-to-frame nuts | 9 |
| HCU-to-bracket bolts | 9 |
| Wheel speed sensor bolts | 9 |
TORQUE SPECIFICATIONS
Anti-Lock Control
The anti-lock brake system (ABS) consists of the following components
- Anti-lock brake system (ABS) module
- Hydraulic control unit (HCU)
- Front wheel speed sensor
- Front wheel speed sensor ring
- Rear wheel speed sensor
- Rear wheel speed sensor ring
- Red brake warning indicator
- Traction control switch
- Yellow ABS warning indicator
Refer to ANTI-LOCK BRAKES for schematic and connector information.
SPECIAL TOOL(S) Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool 73III Automotive Meter 105-R0057 or equivalent Flex Probe Kit 105-R025B Rotunda Active Wheel Speed Sensor Tester
Scheme 9
