Sunroof Ford Five Hundred I

Sun Roof/t-Top/convertible Top 20 illustrations ~6225 words

GENERAL SPECIFICATIONS

ItemSpecification
Roof opening panel glass clearance - front edge1.0 mm - 0.0 mm (-0.04 in - 0.0 in) flush at front
Roof opening panel glass clearance - rear edge0.0 mm - 1.00 mm (0.0 -0.04 in) flush at rear

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Roof opening panel glass screw4
Roof opening panel motor mounting screws2
Roof opening panel frame bolt6
Roof opening panel frame bracket bolt9
Roof opening panel frame bracket nut9
Roof opening panel frame rear bracket bolt6
Roof opening panel frame rear bracket nut6

TORQUE SPECIFICATIONS

Roof Opening Panel

The roof opening panel system consists of the following components

  1. Roof opening panel glass
  2. Roof opening panel shield (sunshade)
  3. Roof opening panel switch
  4. Roof opening panel motor and module assembly
  5. Roof opening panel trough
  6. Roof opening panel frame drain hoses
  7. Roof opening panel assembly

Refer to POWER TOP/SUNROOF (Montego), POWER TOP/SUNROOF (Five Hundred), POWER TOP/SUNROOF , Roof Opening Panel for schematic and connector information.

Special Tool(s)

SPECIAL TOOL(S) SPECIFICATION 73III Automotive Meter 105-R0057 or equivalent

Scheme 1

Scheme 1: Special Tool(s)
Scheme 1: Special Tool(s)

The roof opening panel assembly uses an integrated motor and module to operate the roof opening panel. The roof opening panel motor and module are installed new as an assembly. The roof opening panel is an electronically operated glass panel that can be opened, closed or tilted by the roof opening panel switch. Actuating the switch in either a forward or rearward motion supplies a ground to the roof opening panel motor/module. The roof opening panel has an express open feature that is activated when the switch is momentarily pressed to the double detent OPEN SWITCH position. This function is controlled by the roof opening panel motor/module.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed, or a new roof opening panel assembly has been installed.

Inspection and Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Roof opening panel Roof opening panel frame Roof opening panel drain hoses Roof opening panel lifter assemblies Roof opening panel water trough Roof opening panel air deflector assembly Roof opening panel seal Roof opening panel shield Battery junction box (BJB) fuse Circuitry Accessory delay relay Roof opening panel motor and module assembly Roof opening panel switch
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the concern is not visually evident, determine the symptom. GO to «SYMPTOM CHART»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .

Scheme 2

Scheme 2: Connector Circuit Reference
Scheme 2: Connector Circuit Reference

Scheme 3

Scheme 3
Scheme 3

Normal Operation

When the roof opening panel glass is completely closed, it is flush with the roof panel.

Possible Causes

  1. Incorrect roof opening panel adjustment.
  2. Poorly fitting roof opening panel seal/weatherstrip.
  3. Incorrect installation of the roof opening panel and motor/module.
  4. Incorrect curvature of the air deflector.

Testing

  1. A1 VERIFY ROOF OPENING PANEL NOISE Road test the vehicle with the roof opening panel in the closed and open positions. Is the wind noise present only in the open position? Yes : GO to A4 . No : GO to A2.
  2. A2 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in closed, vent and open positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? Yes : GO to A3. No : INSTALL a new roof opening panel weatherstrip. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) . TEST the system for normal operation.
  3. A3 CHECK ROOF OPENING PANEL ADJUSTMENT Check the roof opening panel adjustment. Is the adjustment OK? Yes : CHECK for correct installation of the roof opening panel and motor/module. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) , «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) , and «ROOF OPENING PANEL MOTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. No : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  4. A4 CHECK THE AIR DEFLECTOR Make sure the air deflector is securely attached and check for damaged or unsecured springs. Is the air deflector OK? Yes : PARTIALLY close the roof opening panel until the noise is eliminated. If the noise is eliminated, INFORM the customer that changing glass location will eliminate the wind noise. If the wind noise is not eliminated, INSTALL a new air deflector. TEST the system for normal operation. No : INSTALL new air deflector assembly. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «AIR DEFLECTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

When the roof opening panel glass is completely closed, it is flush with the roof panel.

  1. Incorrect roof opening panel adjustments.
  2. Damaged roof opening panel drain hoses.
  3. Damaged roof opening panel seal/weatherstrip.
  4. Damaged roof opening panel frame.
  5. Incorrect position of the roof opening panel glass.

PINPOINT TEST B: THE ROOF OPENING PANEL LEAKS

  1. B1 CHECK THE ADJUSTMENT OF THE ROOF OPENING PANEL NOTE: Make sure the roof opening panel weatherstrip is not cracked or loose. Check the roof opening panel weatherstrip. Does the roof opening panel seal correctly? Yes : GO to B2. No : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  2. B2 CHECK THE ROOF OPENING PANEL DRAIN HOSES NOTE: Make sure the roof opening panel drain hoses are not cracked, slit, pinched or obstructed. Check the 4 roof opening panel drain hoses for correct operation. Are the roof opening panel drain hoses OK? Yes : GO to B3. No : REPAIR or INSTALL a new roof opening panel drain hose(s). TEST the system for normal operation.
  3. B3 CHECK THE ROOF OPENING PANEL DRAIN HOSE ATTACHMENT POINTS NOTE: Make sure the roof opening panel drain hose attachment points are not damaged or obstructed. Check the roof opening panel drain hose attachment points for correct attachment. Are the roof opening panel drain hose attachment points OK? Yes : GO to B4. No : REPAIR or INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. B4 CHECK THE ROOF OPENING PANEL REAR TROUGH CONDITION Check the roof opening panel rear trough for damage. Is the roof opening panel trough OK? Yes : GO to B5. No : REPAIR or INSTALL a new roof opening rear trough. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) , «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) , and «TROUGH ASSEMBLY»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. B5 CHECK THE CONDITION OF THE ROOF OPENING GLASS PANEL Check the roof opening panel frame for damage that may cause the roof opening panel glass seal to seat incorrectly. Is the roof opening panel frame OK? Yes : INSTALL a new roof opening panel glass. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation No : REPAIR or INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

When the roof opening panel glass is completely closed, it is flush with the roof panel. All components should be secured correctly.

Rattling noises from the roof opening panel can be caused by any of the following loosely or incorrectly installed components

  1. Roof opening panel
  2. Roof opening panel air deflector assembly
  3. Roof opening panel water trough
  4. Roof opening panel lifter assemblies
  5. Headliner
  6. Roof opening panel motor/module pad
  7. Roof opening panel frame
  1. C1 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in CLOSED, VENT and OPEN positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? Yes : GO to C2. No : INSTALL a new roof opening panel weatherstrip. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) . TEST the system for normal operation.
  2. C2 CHECK THE ROOF OPENING PANEL TIGHTNESS Manually push up and fore/aft. Is the roof opening panel loose? Yes : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. No : GO to C3.
  3. C3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof opening panel. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? Yes : GO to C4. No : REMOVE all the roof opening panel track obstructions and REPAIR the roof opening panel tracks. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. C4 CHECK THE ROOF OPENING PANEL WATER TROUGH AND TROUGH GUIDES Check the water roof opening panel water trough and trough guides for any loose obstructions. Are the roof opening panel water trough and trough guides installed securely and free from obstructions? Yes : GO to C5. No : REMOVE all obstructions from the roof opening panel water trough guides and install securely. INSTALL a new roof opening panel frame if the water trough guides are damaged. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. C5 CHECK THE ROOF OPENING PANEL SHIELD (SUNSHADE) Check the roof opening panel shield for correct installation. Is the roof opening panel shield installed correctly? Yes : GO to C6. No : INSTALL the roof opening panel shield correctly. REFER to «ROOF OPENING PANEL SHIELD»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. C6 CHECK THE ROOF OPENING PANEL AIR DEFLECTOR ASSEMBLY Check the roof opening panel air deflector assembly for obstructions and damage. Is the roof opening panel air deflector assembly OK? Yes : GO to C7. No : REMOVE all obstructions and REPAIR or INSTALL a new roof opening panel air deflector assembly. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  7. C7 CHECK THE ROOF OPENING PANEL GLASS Verify the roof opening panel glass is free from obstructions and damage, and is securely fastened. Is the roof opening panel glass OK? Yes : GO to C8. No : REPAIR or INSTALL a new roof opening panel glass. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  8. C8 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Verify the roof opening panel lifter assemblies are free from obstructions and damage. Are the roof opening panel lifter assemblies OK? Yes : GO to C9. No : REMOVE all obstructions from the roof opening panel lifter assemblies and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  9. C9 CHECK ROOF OPENING PANEL FRAME INSTALLATION Check all roof opening fasteners for correct torque and verify correct installation of the roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . Is the roof opening panel correctly installed and tightened to specification? Yes : GO to C10. No : TIGHTEN the loose fasteners or RE-INSTALL the roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  10. C10 CHECK THE ROOF OPENING PANEL FRAME FOR RATTLES Check the roof opening panel frame assembly for any loose parts or for any condition that will cause rattles. Is there a condition that will cause rattles? Yes : INSTALL a suitable sound damper material to correct the condition. If the rattle still persists, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) in this section. TEST the system for normal operation. No : INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

The roof opening panel operates smoothly while opening and closing.

  1. Obstructed or damaged roof opening panel.
  2. Obstructed or damaged roof opening panel lifter assemblies.
  3. Incorrect roof opening panel adjustment.
  4. Noisy roof opening panel motor/module assembly.
  1. D1 CHECK THE ROOF OPENING PANEL FOR OBSTRUCTIONS OR DAMAGE Check the roof opening panel for any obstructions and damage. Are there any obstructions and/or damage? Yes : REMOVE all obstructions. REPAIR any damage. If the damage cannot be repaired, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. No : GO to D2.
  2. D2 CHECK THE ROOF OPENING PANEL OPERATION Check the roof opening panel during operation. Is the roof opening panel loose or incorrectly adjusted? Yes : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. No : GO to D3.
  3. D3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? Yes : GO to D4. No : REMOVE all obstructions and REPAIR any damage. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. D4 CHECK THE ROOF OPENING PANEL SHIELD Check the roof opening panel shield for correct movement. Is the roof opening panel shield moving correctly? Yes : GO to D5. No : REMOVE and RE-INSTALL the roof opening panel shield. REFER to «ROOF OPENING PANEL SHIELD»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. D5 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? Yes : GO to D6. No : REMOVE all obstructions and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. D6 CHECK THE ROOF OPENING PANEL MOTOR/MODULE Remove the roof opening panel motor/module and leave the electrical connector connected. Operate the roof opening panel to the full OPEN and CLOSED position. Does the motor/module make excessive noise? Yes : INSTALL a new roof opening panel motor/module. REFER to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL MOTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. No : REINSTALL the roof opening panel motor/module. TEST the system for normal operation. If the roof opening panel is still noisy, INSTALL a new roof opening panel frame. Refer to «ROOF OPENING PANEL - EXPLODED VIEW»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-exploded-view) and «ROOF OPENING PANEL FRAME»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . If the roof opening panel is no longer noise, the system is operating correctly. The concern may have been caused by an incorrectly installed roof opening panel motor.

Pinpoint Test E: The Roof Opening Panel Does Not Open Or Close

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed, or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit 2086 (RD/LB) when the key is in the ACC or RUN position. The roof opening panel motor/module provides ground to the roof opening panel switch through circuit 1173 (BN/OG). When the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit 1175 (TN/RD), which causes the roof opening panel to close. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit 691 (DB), which causes the roof opening panel to open.

  1. Open in circuits 2086 (RD/LB), 1205 (BK), 1173 (BN/OG), 691 (DB) or 1175 (TN/RD).
  2. Inoperative roof opening panel switch.
  3. Inoperative roof opening panel motor/module assembly.
  4. Inoperative accessory delay relay.
  5. Roof opening panel motor not initialized.

Scheme 4

Scheme 4: Testing
Scheme 4: Testing

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. E1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present? Yes : GO to E2. No : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. E2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? Yes : GO to E3. No : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/five-hundred/i-2004-2007/remont/windows/#window-and-glass) to diagnose the accessory delay relay circuit.
  3. E3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch. Carry out the roof opening panel switch component test. Refer to «COMPONENT TESTING»(/ford/five-hundred/i-2004-2007/remont/accessories-control-systems/#component-testing) . Is the roof opening panel switch OK? Yes : GO to E4. No : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  4. E4 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUIT 2086 (RD/LB) AND 692 (RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921. Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit 2086 (RD/LB) and C921-6, circuit 692 (RD), harness side and ground. Are the voltages greater than 10 volts, but less than 16 volts? Yes : GO to E5. No : REPAIR the circuit. TEST the system for normal operation.
  5. E5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT 1205 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921 -1, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to E6. No : REPAIR the circuit. TEST the system for normal operation.
  6. E6 CHECK CIRCUIT 1173 (BN/OG) FOR AN OPEN Measure the resistance between overhead console C930-2, circuit 1173 (BN/OG), and roof opening panel motor/module C921-2, circuit 1173 (BN/OG) harness side. Is the resistance less than 5 ohms? Yes : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1173 (BN/OG) between the roof opening panel switch socket and overhead console C930-2. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E7. No : REPAIR the circuit. TEST the system for normal operation.
  7. E7 CHECK CIRCUIT 1175 (TN/RD) FOR AN OPEN Measure the resistance between overhead console C930-5, circuit 1175 (TN/RD), and roof opening panel motor/module C921-10, circuit 1175 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1175 (TN/RD) between the roof opening panel switch socket and overhead console C930-5. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E8. No : REPAIR the circuit. TEST the system for normal operation.
  8. E8 CHECK CIRCUIT 691 (DB) FOR AN OPEN Measure the resistance between overhead console C930-1, circuit 691 (DB), and roof opening panel motor/module C921-5, circuit 691 (DB) harness side. Is the resistance less than 5 ohms? Yes : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 691 (DB) between the roof opening panel switch socket and overhead console C930-1. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness, and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to E9. No : REPAIR the circuit. TEST the system for normal operation.
  9. E9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new roof opening panel motor/module. REFER to «ROOF OPENING PANEL MOTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test F: The roof opening panel does not open or close in vent position

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed, or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit 2086 (RD/LB) when the key is in the ACC or RUN position. The roof opening panel motor/module provides ground to the roof opening panel switch through circuit 1173 (BN/OG). When the roof opening panel switch is pressed to the TILT position, a ground signal is sent to the roof opening panel motor/module through circuit 1174 (WH/RD), which causes the roof opening panel to open to the tilt position. When the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit 1175 (TN/RD), which causes the roof opening panel to close.

  1. Open in circuits 1174 (WH/RD) or 1175 (TN/RD).
  2. Inoperative roof opening panel switch.
  3. Inoperative roof opening panel motor/module assembly.

Scheme 9

Scheme 9: Testing
Scheme 9: Testing
  1. F1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present, or does the roof opening panel motor fail to initialize? Yes : GO to F2. No : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. F2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch. Carry out the roof opening panel switch component test. Refer to «COMPONENT TESTING»(/ford/five-hundred/i-2004-2007/remont/accessories-control-systems/#component-testing) . Is the roof opening panel switch OK? Yes : GO to F3. No : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  3. F3 CHECK CIRCUIT 1174 (WH/RD) FOR AN OPEN Measure the resistance between overhead console C930-6, circuit 1174 (WH/RD), and roof opening panel motor/module C921-4, circuit 1174 (WH/RD) harness side. Is the resistance less than 5 ohms? Yes : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1174 (WH/RD) between the roof opening panel switch socket and overhead console C930-6. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to F4. No : REPAIR the circuit. TEST the system for normal operation.
  4. F4 CHECK CIRCUIT 1175 (TN/RD) FOR AN OPEN Measure the resistance between overhead console C930-5, circuit 1175 (TN/RD), and roof opening panel motor/module C921-10, circuit 1175 (TN/RD) harness side. Is the resistance less than 5 ohms? Yes : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit 1175 (TN/RD) between the roof opening panel switch socket and overhead console C930-5. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, GO to F5. No : REPAIR the circuit. TEST the system for normal operation.
  5. F5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new roof opening panel motor/module. REFER to «ROOF OPENING PANEL MOTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Scheme 10

Scheme 10: Roof Opening Panel Manual Operation
Scheme 10: Roof Opening Panel Manual Operation
  1. Remove the LH and RH A-pillar trim panels. Position the weatherstrip aside near the A-pillar. Pull the outboard edge of the A-pillar trim panel toward the inside of the vehicle to disengage the retaining clips. Pull the A-pillar trim panel upward to remove from the dash panel.
  2. Remove the LH and RH sun visor assemblies. Remove the 3 sun visor retaining screws. Disconnect the sun visor wire harness electrical connector. Remove the sun visor arm clip screw. Remove the sun visor arm clip.
  3. Remove the overhead console. Open the bin and remove the screws. Disconnect the overhead console electrical connector.
  4. If equipped, disconnect the auto-dimming electrical connector from the interior rear view mirror.
  5. Pull down front of headliner to gain access to the roof opening panel motor.
  6. Insert an Allen wrench into the center of the manual drive hole. Rotate the Allen wrench counterclockwise until the roof opening panel is closed.

Roof Opening Panel Alignment

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

Scheme 11

Scheme 11: Roof Opening Panel Alignment
Scheme 11: Roof Opening Panel Alignment

Scheme 12

Scheme 12
Scheme 12
  1. Cycle the roof sliding outer glass panel through the fully OPEN to the fully CLOSED positions.
  2. Loosen the roof opening panel glass screws. Loosen only the front screws to adjust the front. Loosen only the rear screws to adjust the rear. To install, tighten to 4 Nm (35 lb-in).
  3. Adjust the roof opening panel glass to specification.
  4. Tighten the roof opening panel glass screws.
  5. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Roof Opening Panel Motor Initialization

CAUTIONBe sure there are no obstructions in the path of the roof opening panel glass before attempting to initialize the roof opening panel motor.

Note. A new roof opening panel motor will only vent and must be initialized.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Pinpoint Test F

F2 For an existing roof opening panel motor,
F3 For a new roof opening panel motor,
  1. For an existing motor, press and hold the switch in the VENT position (for approximately 10 seconds) until the roof opening panel glass moves past full VENT, then to full VENT, then quickly release the switch.

Timing Adjustment

Note. Anytime a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

Scheme 13

Scheme 13: Timing Adjustment
Scheme 13: Timing Adjustment

Scheme 14

Scheme 14
Scheme 14
  1. Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With the roof opening panel glass removed, position the roof opening panel to the CLOSED position.
  3. Remove the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  4. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame.
  5. Slide the trough assembly rearward to gain access to the alignment holes.
  6. Use a small Allen wrench or pick to confirm timing as shown. Move the affected cables by hand until the timing holes are aligned with each other. There is a hole in the lifter arm and a hole in the cable link. They will only align in one position.
  7. With the timing holes aligned, install the roof opening panel motor. Tighten the motor screws to 2 Nm (18 lb-in).
  8. Reinstall the trough assembly. For additional information, refer to «TROUGH ASSEMBLY»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  9. Reinstall the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  10. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Roof Opening Panel - Exploded View

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

Note. Roof opening panel with rear entertainment system shown, roof opening panel without rear entertainment system similar.

Scheme 15

Scheme 15: Roof Opening Panel - Exploded View
Scheme 15: Roof Opening Panel - Exploded View
  1. For additional information, refer to the procedures in this article.

Removal and Installation

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

  1. Open the roof opening panel to the VENT position.
  2. Remove the 4 roof opening panel glass screws. To access the glass screws, unclip the top portion of the concertina blind and position aside as shown. To install, tighten to 4 Nm (35 lb-in) and make sure concertina blind is clipped properly back in place.
  3. From the outside of the vehicle, remove the roof opening panel glass assembly.
  4. To install, reverse the removal procedure. Check for correct alignment of the roof opening panel. For additional information, refer to «ROOF OPENING PANEL ALIGNMENT»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) .
  5. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Scheme 16

Scheme 16: Removal and Installation
Scheme 16: Removal and Installation
  1. Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With glass removed, place roof opening panel into the CLOSED position.
  3. With roof opening panel shield in full forward position, remove the 4 Torx® screws. Remove the 2 front screws first to allow shield to slide further forward in track to expose 2 rear screws.
  4. Lift the roof opening panel shield upward through roof opening.
  5. To install, reverse the removal procedure.

Note. Anytime a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed. For additional information, refer to TIMING ADJUSTMENT .

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

Scheme 17

Scheme 17: Removal and Installation
Scheme 17: Removal and Installation
  1. Remove the overhead console. Open the bin and remove the screws. Disconnect the overhead console electrical connector.
  2. Remove the roof opening panel motor screws. To install, tighten to 2 Nm (18 lb-in).
  3. Remove the roof opening panel motor.
  4. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to ROOF OPENING PANEL MOTOR INITIALIZATION .

Note. Anytime a roof opening panel motor is removed, the cables/mechanisms can experience free-play movement. It is important that the cables do not move. They are timed to be parallel with each other. If one or both are moved in either direction, they must be re-timed. For additional information, refer to TIMING ADJUSTMENT .

  1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Disconnect the 4 roof opening panel drain hoses from the corners of the roof opening panel frame.
  3. Remove the 12 roof opening panel frame bolts. To install, tighten to 6 Nm (53 lb-in).
  4. Remove the roof opening panel frame.
  5. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Scheme 18

Scheme 18
Scheme 18
  1. Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(/ford/five-hundred/i-2004-2007/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. With roof opening glass removed, position the roof opening panel to the CLOSED position.
  3. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame.
  4. Deflect the trough downward in the center and pull it to one side. This will allow it to flex enough to disengage one side from the track slot.
  5. With one guide disengaged, push the trough to the other side of the vehicle to disengage the opposite guide.
  6. Tilt and pull trough forward and upward to remove through roof opening.
  7. To install, reverse the removal procedure.

Scheme 19

Scheme 19: Removal and Installation
Scheme 19: Removal and Installation

Scheme 20

Scheme 20
Scheme 20
  1. Place the roof opening panel glass in the FULL OPEN position.
  2. From top of vehicle, depress spring steel locating tab downward on each side with flat-blade screwdriver while pushing deflector toward rear of vehicle. To install, make sure locating tabs are firmly locked in place.
  3. Tilt the air deflector upward and pull forward to remove.
  4. To install, reverse the removal procedure.
