TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Front Seats

The front seats can be equipped with the following systems

1. Manual seat tracks
2. Power seat tracks (2-way and 6-way)
3. Manual backrest adjust (recline)
4. Power backrest adjust (recline)
5. Passenger seat fold-flat load floor
6. Manual lumbar adjust
7. Heated seats
8. Memory driver seat
9. Seat side air bags
10. Occupant classification sensor (OCS) system on passenger seat

Driver Seat Module - Memory Seat

Note. The memory seat track position sensors are integral to the memory seat track motors. The memory seat track motor electrical connectors will connect to a seat track without the memory option. Make sure the correct seat track is being installed.

The power driver seat, power outside rear view mirrors and power adjustable pedals are controlled by the driver seat module (DSM) only when the vehicle is equipped with the programmable/recall memory option. The DSM is located underneath the driver seat cushion.

Note. During reflash, if the flash operation fails, disconnect the battery for 30 seconds, then reconnect the battery and continue.

This system allows automatic positioning of the driver seat to 2 programmable positions.

1. A power driver seat position can be stored at any time. The driver must move the seat to the desired position using the driver seat switch assembly. The driver must then depress the memory SET switch which activates the memory SET switch light emitting diode (LED). Within 5 seconds (before the LED goes out), the driver must select a memory position. Memory 1 is selected by depressing memory switch 1. Memory 2 is selected by depressing memory switch 2.
2. If no memory switch input is received within the 5-second time limit, the operation is aborted and the memory SET switch LED is turned off. This also occurs if one of the following inputs is received during the 5-second programming limit: Power driver seat switch Memory SET switch Power adjustable pedal switch

A position can only be recalled when the transmission selector is in PARK or NEUTRAL. A position may be programmed at any time.

Heated Seats

This system allows the electrical heating of the front seats on passenger demand.

The components of the system are

1. the seat heating elements located in the seat cushion and backrest.
2. the heated seat module located on the seat cushion pan.
3. the heated seat control switch, located on the electronic automatic temperature control (EATC) module.
4. the temperature sensor, located in the seat cushion heating element.

Occupant Classification Sensor (OCS)

The occupant classification sensor (OCS) is standard equipment on all front passenger seats. For additional information on diagnosing or servicing the OCS, refer to SUPPLEMENTAL RESTRAINT SYSTEM .

Five Hundred and Montego

These seats have a 60/40 split backrest. The 60 percent has a fold down armrest. Each backrest is held in place at the top with its own striker attached to the package tray sheet metal and a latch attached to each backrest frame.

Freestyle

There are 2 seating options for the second row: a 60/40 or a 40/40. All seats will fold forward to ease entry to the third row of seating. Each configuration's backrests will recline and fold flat. The 40/40 seats have an optional adjustable seat track in place of the stationary riser.

Third Row Seating

There are 2 seating options for the third row; abench seat or 50/50 split bench seat is available. Both seats will fold flat into the floor, forming a load floor for carrying cargo.

Seats

Refer to POWER SEATS (Montego), POWER SEATS (Five Hundred), or POWER SEATS (Freestyle) , Climate Control Seats, Power Seats and Memory Seats for schematic and connector information.

Refer to COMPONENT TESTING , Component Testing for component testing.

Special Tool(s)

SPECIAL TOOL(S) CHART Fluke 73III Automotive Meter 105-R0057 or equivalent Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool Diagnostic Tool, Restraint System (2 required) 418-133

Scheme 1

Scheme 2

Restraint System Diagnostic Tool Warning

Diagnostic Tool and Controller Area Network Note

Note. This vehicle utilizes a communication system called a medium-speed controller area network (MS-CAN). When diagnosing the driver seat module and memory seat system use the Worldwide Diagnostic System (WDS) and the latest software update or equivalent diagnostic tool with the capability of communicating over the MS-CAN bus.

Driver and Passenger Power Seats Without Memory

The driver power seat uses a 6-way power seat track and 3 electric motors directly controlled by a seat mounted 6-way seat control switch for horizontal (forward/rearward), front height and rear height adjustment. The passenger seat uses a 2-way seat track with a single electric motor and is directly controlled by a 2-way seat mounted seat control switch for horizontal adjustment. Both driver and passenger seats can also be equipped with a power recliner mechanism, which uses a single electric motor and is also directly controlled by an 8-way seat control switch (driver seat) or a 4-way seat control switch (passenger).

The driver and passenger power seat and power recliner motors are hard-wired to the seat control switch. The circuits are normally at ground through the seat control switch. An individual motor is switched to power circuit 566 (DG) (driver seat) or circuit 1462 (RD/WH) (passenger seat) and ground circuit 1205 (BK) when a specific adjustment position is selected. The power seat feature operates independent of the position of the ignition switch.

Power Driver Seat With Memory

The memory driver seat feature allows the driver to program a personalized seat position that can be recalled using the memory switch or a remote keyless entry (RKE) transmitter. There are 2 memory settings possible. The outside rear view mirror positions and the power adjustable pedals (if equipped) are also stored and recalled with the power driver seat positions.

The driver power seat is controlled by the driver seat module (DSM), if equipped. A new DSM must be configured after installation. For additional information, refer to MODULE CONFIGURATION . The driver seat also must be calibrated when a new DSM is installed or after the driver seat track is installed (if repaired or installed new). For additional information, refer to SEAT CALIBRATION .

The driver seat control switch provides voltage to the DSM when activated. The NEUTRAL position of each driver seat control switch position is a ground state through the seat control switch contacts. A voltage input causes the DSM to power the appropriate motor until the input is removed. Ground is the normal state of the motor circuits through the DSM and is not switched to control the motors. The DSM internally switches the appropriate circuit from ground to power for operating the motors.

As the seat is adjusted, the DSM constantly monitors the motor position sensors to record the current seat position. The DSM will remove power from the motor upon termination of the seat control switch input or if the DSM does not see movement from the motor by monitoring the position sensor. The DSM must be calibrated to the driver seat track for correct memory seat operation. For additional information, refer to SEAT CALIBRATION . Once the DSM is calibrated to the seat track, it will only allow movement within the calibrated range.

The DSM communicates diagnostic trouble code (DTC) and other information using the MS-CAN communication bus. It should be noted for diagnostics that because CAN bus communication is more robust and reliable than other methods, it may be possible to have limited module communication with one of the CAN bus circuits disconnected or shorted to ground. Refer to MODULE COMMUNICATIONS NETWORK for additional information concerning MS-CAN bus communication.

Seat Calibration

The DSM is calibrated using a diagnostic tool. The calibration procedure automatically powers the driver power seat through its full range of motion and records the full stop positions by monitoring the motor position sensors. Once the full stop positions or range of the seat have been recorded, the DSM will only operate within the calibrated range. Any input attempting to drive the seat beyond the calibrated range will be ignored. This calibration is used for all seat control functions including manual switch control and memory recall positioning. During the seat calibration, the DSM may identify a function that is inoperative, such as a position sensor not changing. If the DSM identifies a concern that has a related diagnostic trouble code (DTC), the DSM will set the related DTC at the end of the validation procedure.

Programming Memory Seat Positions

1. A power driver seat position can be stored at any time. The driver must move the seat to the desired position using the driver seat control switch. The driver must then depress the memory SET switch which activates the memory SET switch light emitting diode (LED). Within 5 seconds (before the LED goes out), the driver must select a memory position. Memory 1 is selected by depressing memory switch 1. Memory 2 is selected by depressing memory switch 2.
2. If no memory switch input is received within the 5-second time limit, the operation is aborted and the memory SET switch LED is turned off. If one of the following inputs is received during the 5-second programming limit, the operation is aborted and the memory SET switch LED is turned off: Power driver seat control switch. Power outside rear view mirror switch. Memory SET switch. Power adjustable pedal switch.

Recalling a Stored Memory Seat Position

Note. A memory recall can be initiated only if the vehicle is in PARK or NEUTRAL gear and the ignition switch is not in START. A memory recall in progress will not be affected by moving the ignition switch to START or by moving the gearshift lever out of PARK or NEUTRAL.

Once the driver has stored the driver seat position, the driver can recall the setting by depressing the corresponding memory switch or by using a programmed remote entry transmitter.

The driver can recall the desired driver seat position by depressing one of the memory recall switches. Depressing memory switch 1 will initiate a recall of the power driver seat position stored in memory 1. Depressing memory switch 2 will initiate a recall of the power driver seat position stored in memory 2.

A remote entry transmitter can be used to recall previously set memory positions. The transmitter that has been assigned with personality 1 is capable of recalling memory position 1 only. Similarly, the personality 2 transmitter can recall only memory position 2.

Memory recall occurs when the UNLOCK switch is depressed on the remote entry transmitter. The second depression of the UNLOCK switch, which unlocks passenger doors, does not initiate a memory recall.

A memory recall in progress does not prohibit the initiation of another memory recall; the most recently requested memory recall will be executed.

Memory positions that have not been programmed will not initiate any motion for the power driver seat, power memory rear view mirrors or adjustable pedals.

The driver and passenger heated seat modules (if equipped) share a common battery feed and ground source and have a separate ignition feed. The electronic automatic temperature control (EATC) module includes the heated seat control buttons and indicators. The heated seat system will function when the EATC module is ON or OFF. When a heated seat control button on the EATC module is pressed with the ignition switch in RUN or START, a momentary ground signal is sent to the heated seat module. Upon receiving a signal, the heated seat module will decrease one setting (the sequence is HI, LO, OFF, HI, etc.). When a heated seat is set to HI, both LED indicators above the heated seat control button will illuminate. When a heated seat is set to LO, only the left LED indicator will illuminate. When a heated seat is set to OFF, neither LED will be illuminated. For additional information, refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

When the heated seat system is ON, the heated seat module then supplies power to the heating element circuit. The cushion element and backrest element are wired in series and powered by the same output. The heated seat module will remain on for 10 minutes or until the heated seat control button is pressed to cycle the heated seat module to the OFF state. If the ignition source is removed from the module, the heated seat module will enter an OFF state and will not return to ON until the heated seat control button is once again pressed with the ignition switch in RUN. The heated seat module is designed to heat the seat to 37.5°C (99.5°F) in LO setting and 42°C (107.6°F) in HI setting and maintain the temperature until switched off. This temperature is maintained by the heated seat module monitoring the temperature sensor, located in the seat cushion element, and adjusting the current flow to the heating elements.

Inspection and Verification

1. Verify the customer concern by operating the power seat, memory seat or climate controlled seat functions.
2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Seat track Fuse(s) Circuitry Memory SET switch Seat control switch Heated seat element (damaged seat coverings or foam pad) Heated seat module Power seat motor (seat track) Driver seat module (DSM) Electronic automatic temperature control (EATC) module
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is with the power seat (non-memory seat) or climate controlled seat and the cause is not visually evident, verify the symptom and GO to «SYMPTOM CHART»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system__symptom-chart) .
5. If the concern is with the memory seat and the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: Check that the program card is correctly installed. Check the connections to the vehicle. Check the ignition switch position.
6. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
7. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: CAN circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-communications-network-system) . No response/not equipped for DSM, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-communications-network-system) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), clear the continuous DTCs and carry out self-test diagnostics for the DSM.
8. If the DTCs retrieved are related to the concern, go to «DRIVER SEAT MODULE (DSM) DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system__driver-seat-module-dsm-diagnostic-trouble) .
9. If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system__symptom-chart) .

Driver Seat Module (DSM) Diagnostic Trouble Code (DTC) Index

DTC DETECTION CONDITION CHART

Symptom Chart

SYMPTOM CHART

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Pinpoint Tests

Refer to INSPECTION AND VERIFICATION , the DSM Diagnostic Trouble Code (DTC) Table and the SYMPTOM CHART for direction to the appropriate Pinpoint Test.

Normal Operation

The driver seat control switch is powered by battery voltage to the driver seat control switch, circuit 566 (DG), and is supplied ground on driver circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to a power seat track motor or power recliner motor to move the seat or backrest. When pressed in the opposite direction, the seat control switch reverses the polarity to that same power seat track motor or power recliner motor, which moves the seat or backrest in the opposite direction. There are 3 power seat track motors that combine to move the seat cushion horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). There is an additional motor in the power recliner mechanism to move the seat backrest forward and rearward. If a new motor needs to be installed, it is necessary to install an entire power seat track or power recliner mechanism.

Possible Causes

An inoperative driver power seat can be caused by

1. a fuse.
2. wiring, terminals or connectors.
3. a faulty seat control switch.
4. a faulty power seat motor (power seat track).

Scheme 29

Scheme 30

1. A1 CHECK CIRCUIT 566 (DG) FOR VOLTAGE WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Disconnect: Driver Seat Control Switch C369. Measure the voltage between driver seat control switch C369 pin 5, circuit 566 (DG), harness side and ground. Is the voltage greater than 10 volts? Result/ Action to Take Yes : GO to A2. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. A2 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between driver seat control switch C369 pin 3, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver seat control switch is powered by battery voltage to the driver seat control switch, circuit 566 (DG), and is supplied ground on driver circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to a power seat track motor to move the seat. When pressed in the opposite direction, the seat control switch reverses the polarity to that same power seat track motor, which moves the seat in the opposite direction. There are 3 power seat track motors that combine to move the seat cushion horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). If a new motor needs to be installed, it is necessary to install an entire power seat track.

An inoperative driver power seat can be caused by

1. a fuse.
2. wiring, terminals or connectors.
3. a faulty seat control switch.
4. a faulty power seat motor (power seat track).

Scheme 31

Scheme 32

1. B1 CHECK CIRCUIT 566 (DG) FOR VOLTAGE WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Disconnect: Driver Seat Control Switch C360. . Is the voltage greater than 10 volts? Result/ Action to Take Yes : GO to B2. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. B2 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between driver seat control switch C360 pin 2, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The passenger seat control switch is powered by battery voltage to the passenger seat control switch, circuit 1462 (RD/WH), and is supplied ground on passenger circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to the power seat track motor or power recliner motor to move the seat or backrest. When pressed in the opposite direction, the seat control switch reverses the polarity to the power seat track motor or power recliner motor, which moves the seat or backrest in the opposite direction. There is 1 power seat track motor which moves the seat cushion horizontally (FORWARD/REARWARD) and an additional motor in the power recliner mechanism to move the seat backrest forward and rearward. If a new motor needs to be installed, it is necessary to install an entire power seat track or power recliner mechanism.

An inoperative passenger power seat can be caused by

1. a fuse.
2. wiring, terminals or connectors.
3. a faulty seat control switch.
4. a faulty power seat motor (power seat track).

Scheme 33

Scheme 34

1. C1 CHECK FOR POWER TO THE PASSENGER SEAT CONTROL SWITCH WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3227. Connect the battery ground cable. Disconnect: Passenger Seat Control Switch C330. Measure the voltage between passenger seat control switch C330 pin 5, circuit 1462 (RD/WH), harness side and ground. Is the voltage greater than 10 volts? Result/ Action to Take Yes : GO to C2. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. C2 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between passenger seat control switch C330 pin 3, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new passenger seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The passenger seat control switch is powered by battery voltage to the passenger seat control switch, circuit 1462 (RD/WH), and is supplied ground on passenger circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to the power seat track motor to move the seat. When pressed in the opposite direction, the seat control switch reverses the polarity to the power seat track motor, which moves the seat in the opposite direction. There is 1 power seat track motor which moves the seat horizontally (FORWARD/REARWARD). If a new motor needs to be installed, it is necessary to install an entire power seat track.

An inoperative passenger power seat can be caused by

1. a fuse.
2. wiring, terminals or connectors.
3. a faulty seat control switch.
4. a faulty power seat motor (power seat track).

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. D1 CHECK VOLTAGE TO THE PASSENGER SEAT HORIZONTAL MOTOR WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3227. Connect the battery ground cable. Disconnect: Passenger Seat Horizontal Motor C332. Measure the voltage between passenger seat horizontal motor C332 pin 2, circuit 986 (YE/WH), harness side and C332 pin 1, circuit 987 (RD/WH), harness side, while pushing the passenger seat control switch forward and rearward. Is the voltage greater than 10 volts when the switch is pushed FORWARD, greater than -10 volts when the switch is pushed REARWARD, and 0 volts when the switch is in a REST position? Result/ Action to Take Yes : INSTALL a new passenger seat horizontal motor. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to D2.
2. D2 CHECK FOR POWER TO THE PASSENGER SEAT CONTROL SWITCH Disconnect: Passenger Seat Control Switch C3190. Measure the voltage between passenger seat control switch C3190 pin 4, circuit 1462 (RD/WH), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to D3. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. D3 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between passenger seat control switch C3190 pin 2, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to D4. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. D4 CHECK CIRCUIT 986 (YE/WH) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between passenger seat control switch C3190 pin 3, circuit 986 (YE/WH), harness side and passenger seat horizontal motor C332 pin 2, circuit 986 (YE/WH), harness side; and between passenger seat control switch C3190 pin 3, circuit 986 (YE/WH), harness side and ground. Is the resistance less than 5 ohms between the passenger seat horizontal motor and the passenger seat control switch; and greater than 10,000 ohms between the passenger seat control switch and ground? Yes : GO to D5. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
5. D5 CHECK CIRCUIT 987 (RD/WH) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between passenger seat control switch C3190 pin 6, circuit 987 (RD/WH), harness side and passenger seat horizontal motor C332 pin 1, circuit 987 (RD/WH), harness side; and between passenger seat control switch C3190 pin 6, circuit 987 (RD/WH), harness side and ground. Is the resistance less than 5 ohms between the passenger seat horizontal motor and the passenger seat control switch; and greater than 10,000 ohms between the passenger seat control switch and ground? Yes : INSTALL a new passenger seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver seat control switch is powered by battery voltage on driver circuit 566 (DG) and is supplied ground on circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to a power seat track motor or power recliner motor to move the seat or backrest. When pressed in the opposite direction, the seat control switch reverses the polarity to that same power seat track motor or power recliner motor, which moves the seat or backrest in the opposite direction. There are 3 power seat track motors that combine to move the seat cushion horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). There is an additional motor in the power recliner mechanism to move the seat backrest forward and rearward. If a new motor needs to be installed, it is necessary to install an entire power seat track or power recliner mechanism.

A driver power seat that does not move horizontally and/or vertically can be caused by

1. wiring, terminals or connectors.
2. a faulty seat control switch.
3. a faulty seat track motor (seat track).
4. a faulty power recliner mechanism.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. E1 CHECK THE HORIZONTAL DIRECTION MOTOR FOR CORRECT OPERATION WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Operate the driver power seat forward and rearward. Will the seat move horizontally? Result/ Action to Take Yes : GO to E2. No : GO to E3 .
2. E2 CHECK THE RECLINER MOTOR FOR CORRECT OPERATION Recline the driver backrest forward and rearward. Will the seat backrest recline FORWARD and REARWARD? Yes : GO to E6 . No : GO to E13 .
3. E3 CHECK THE VOLTAGE TO THE DRIVER SEAT HORIZONTAL MOTOR Disconnect: Driver Seat Horizontal Motor C362. Measure the voltage between driver seat horizontal motor C362 pin 1, circuit 980 (YE/WH), harness side and C362 pin 2, circuit 981 (RD/WH), harness side, while pushing the driver seat control switch forward and rearward. Is the voltage greater than 10 volts when the switch is pushed FORWARD, greater than -10 volts when the switch is pushed REARWARD, and 0 volts when the switch is in a REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3227. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to E4.
4. E4 CHECK CIRCUIT 980 (YE/WH) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C369. Measure the resistance between driver seat control switch C369 pin 4, circuit 980 (YE/WH), harness side and driver seat horizontal motor C362 pin 1, circuit 980 (YE/WH), harness side; and between driver seat control switch C369 pin 4, circuit 980 (YE/WH), harness side and ground. Is the resistance less than 5 ohms between the driver seat horizontal motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to E5. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
5. E5 CHECK CIRCUIT 981 (RD/WH) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between driver seat control switch C369 pin 9, circuit 981 (RD/WH), harness side and driver seat horizontal motor C362 pin 2, circuit 981 (RD/WH), harness side; and between driver seat control switch C369 pin 9, circuit 981 (RD/WH), harness side and ground. Is the resistance less than 5 ohms between the driver seat horizontal motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
6. E6 DETERMINE THE SEAT TILTING FAILURE Determine the seat tilting failure. Can the seat be tilted FORWARD or BACKWARD? Yes : If only forward tilting operates, GO to E7. If only rear tilting operates, GO to E10 . No : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
7. E7 CHECK THE VOLTAGE TO THE DRIVER SEAT REAR HEIGHT MOTOR Disconnect: Driver Seat Rear Height Motor C363. Measure the voltage between driver seat rear height motor C363 pin 2, circuit 982 (YE/LG), harness side and C363 pin 1, circuit 983 (RD/LG), harness side, while depressing the rear tilt switch up and down. Is the voltage greater than +10 volts when the rear tilt switch is pressed DOWN, greater than -10 volts when the rear tilt switch is pressed UP and 0 volts when the switch is in the REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to E8.
8. E8 CHECK CIRCUIT 982 (YE/LG) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C369. Measure the resistance between driver seat control switch C369 pin 1, circuit 982 (YE/LG), harness side and driver seat rear height motor C363 pin 2, circuit 982 (YE/LG), harness side; and between driver seat control switch C369 pin 1, circuit 982 (YE/LG), harness side and ground. Is the resistance less than 5 ohms between the driver seat rear height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to E9. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
9. E9 CHECK CIRCUIT 983 (RD/LG) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between driver seat control switch C369 pin 12, circuit 983 (RD/LG), harness side and driver seat rear height motor C363 pin 1, circuit 983 (RD/LG), harness side; and between driver seat control switch C369 pin 12, circuit 983 (RD/LG), harness side and ground. Is the resistance less than 5 ohms between the driver seat rear height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
10. E10 CHECK THE VOLTAGE TO DRIVER SEAT FRONT HEIGHT MOTOR Disconnect: Driver Seat Front Height Motor C382. Measure the voltage between driver seat front height motor C382 pin 1, circuit 979 (RD/LB), harness side and C382 pin 2, circuit 978 (YE/LB), while pushing the rear tilting switch up and down. Is the voltage greater than +10 volts when the front tilt switch is pressed DOWN, greater than -10 volts when the front tilt switch is pressed UP and 0 volts when the switch is in the REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to E11.
11. E11 CHECK CIRCUIT 978 (YE/LB) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C369. Measure the resistance between driver seat control switch C369 pin 2, circuit 978 (YE/LB), harness side and driver seat front height motor C382 pin 2, circuit 978 (YE/LB), harness side; and between driver seat control switch C369 pin 2, circuit 978 (YE/LB), harness side and ground. Is the resistance less than 5 ohms between the driver seat front height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to E12. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
12. E12 CHECK CIRCUIT 979 (RD/LB) FOR AN OPEN Measure the resistance between driver seat control switch C369 pin 6, circuit 979 (RD/LB) harness side, and driver seat front height motor C382 pin 1, circuit 979 (RD/LB), harness side; and between driver seat control switch C369 pin 6, circuit 979 (RD/LB), harness side and ground. Is the resistance less than 5 ohms between the driver seat front height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
13. E13 CHECK VOLTAGE TO THE DRIVER SEAT RECLINER MOTOR Disconnect: Driver Seat Recliner Motor C3187. Measure the voltage between driver seat recliner motor C3187 pin 2, circuit 919 (GY/BK), harness side and C3187 pin 1, circuit 918 (GY), while pushing the recline switch forward and rearward. Is the voltage greater than 10 volts when the switch is pushed FORWARD, greater than -10 volts when the switch is pushed REARWARD, and 0 volts when the switch is in a REST position? Yes : INSTALL a new driver seat recliner motor. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to E14.
14. E14 CHECK CIRCUIT 919 (GY/BK) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C369. Measure the resistance between driver seat control switch C369 pin 8, circuit 919 (GY/BK), harness side and driver seat recliner motor C3187 pin 2, circuit 919 (GY/BK), harness side; and between driver seat control switch C369 pin 8, circuit 919 (GY/BK), harness side and ground. Is the resistance less than 5 ohms between the driver seat recliner motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to E15. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
15. E15 CHECK CIRCUIT 918 (GY) FOR AN OPEN Measure the resistance between driver seat control switch C369 pin 11, circuit 918 (GY) harness side, and driver seat recliner motor C3187 pin 1, circuit 918 (GY), harness side; and between driver seat control switch C369 pin 11, circuit 918 (GY), harness side and ground. Is the resistance less than 5 ohms between the driver seat recliner motor and the driver seat control switch; and greater than 10,000 ohms between the seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver seat control switch is powered by battery voltage on driver circuit 566 (DG) and is supplied ground on circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to a power seat track motor to move the seat. When pressed in the opposite direction, the seat control switch reverses the polarity to that same power seat track motor, which moves the seat in the opposite direction. There are 3 power seat track motors that combine to move the seat cushion horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). If a new motor needs to be installed, it is necessary to install an entire power seat track.

A driver power seat that does not move horizontally and/or vertically can be caused by

1. wiring, terminals or connectors.
2. a faulty seat control switch.
3. a faulty seat track motor (seat track).

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. F1 CHECK HORIZONTAL DIRECTION MOTOR FOR CORRECT OPERATION WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Operate the driver power seat forward and rearward. Will the seat move horizontally? Result/ Action to Take Yes : GO to F5 . No : GO to F2.
2. F2 CHECK VOLTAGE TO THE DRIVER SEAT HORIZONTAL MOTOR Disconnect: Driver Seat Horizontal Motor C362. Measure the voltage between driver seat horizontal motor C362 pin 1, circuit 980 (YE/WH), harness side and C362 pin 2, circuit 981 (RD/WH), harness side, while pushing the driver seat control switch forward and rearward. Is the voltage greater than 10 volts when the switch is pushed FORWARD, greater than -10 volts when the switch is pushed REARWARD, and 0 volts when the switch is in a REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to F3.
3. F3 CHECK CIRCUIT 980 (YE/WH) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C360. Measure the resistance between driver seat control switch C360 pin 3, circuit 980 (YE/WH), harness side and driver seat horizontal motor C362 pin 1, circuit 980 (YE/WH), harness side; and between driver seat control switch C360 pin 3, circuit 980 (YE/WH), harness side and ground. Is the resistance less than 5 ohms between the driver seat horizontal motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to F4. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. F4 CHECK CIRCUIT 981 (RD/WH) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between driver seat control switch C360 pin 6, circuit 981 (RD/WH), harness side and driver seat horizontal motor C362 pin 2, circuit 981 (RD/WH), harness side; and between driver seat control switch C360 pin 6, circuit 981 (RD/WH), harness side and ground. Is the resistance less than 5 ohms between the driver seat horizontal motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
5. F5 DETERMINE SEAT TILTING FAILURE Determine seat tilting failure. Can the seat be tilted FORWARD or BACKWARD? Yes : If only forward tilting operates, GO to F6. If only rear tilting operates, GO to F9 . No : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
6. F6 CHECK VOLTAGE TO THE DRIVER SEAT REAR HEIGHT MOTOR Disconnect: Driver Seat Rear Height Motor C363. Measure the voltage between driver seat rear height motor C363 pin 2, circuit 982 (YE/LG), harness side and C363 pin 1, circuit 983 (RD/LG), harness side, while depressing the rear tilt switch up and down. Is the voltage greater than +10 volts when the rear tilt switch is pressed DOWN, greater than -10 volts when the rear tilt switch is pressed UP and 0 volts when the switch is in the REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to F7.
7. F7 CHECK CIRCUIT 982 (YE/LG) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C360. Measure the resistance between driver seat control switch C360 pin 5, circuit 982 (YE/LG), harness side and driver seat rear height motor C363 pin 2, circuit 982 (YE/LG), harness side; and between driver seat control switch C360 pin 5, circuit 982 (YE/LG), harness side and ground. Is the resistance less than 5 ohms between the driver seat rear height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to F8. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
8. F8 CHECK CIRCUIT 983 (RD/LG) FOR AN OPEN AND SHORT TO GROUND Measure the resistance between driver seat control switch C360 pin 7, circuit 983 (RD/LG), harness side and driver seat rear height motor C363 pin 1, circuit 983 (RD/LG), harness side; and between driver seat control switch C360 pin 7, circuit 983 (RD/LG), harness side and ground. Is the resistance less than 5 ohms between the driver seat rear height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
9. F9 CHECK THE VOLTAGE TO THE DRIVER SEAT FRONT HEIGHT MOTOR Disconnect: Driver Seat Front Height Motor C382. Measure the voltage between driver seat front height motor C382 pin 1, circuit 979 (RD/LB), harness side and C382 pin 2, circuit 978 (YE/LB), while pushing the rear tilting switch up and down. Is the voltage greater than +10 volts when the front tilt switch is pressed DOWN, greater than -10 volts when the front tilt switch is pressed UP and 0 volts when the switch is in the REST position? Yes : INSTALL a new driver seat track assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to F10.
10. F10 CHECK CIRCUIT 978 (YE/LB) FOR AN OPEN AND SHORT TO GROUND Disconnect: Driver Seat Control Switch C360. Measure the resistance between driver seat control switch C360 pin 1, circuit 978 (YE/LB), harness side and driver seat front height motor C382 pin 2, circuit 978 (YE/LB), harness side; and between driver seat control switch C360 pin 1, circuit 978 (YE/LB), harness side and ground. Is the resistance less than 5 ohms between the driver seat front height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : GO to F11. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
11. F11 CHECK CIRCUIT 979 (RD/LB) FOR AN OPEN Measure the resistance between driver seat control switch C360 pin 8, circuit 979 (RD/LB) harness side, and driver seat front height motor C382 pin 1, circuit 979 (RD/LB), harness side; and between driver seat control switch C360 pin 8, circuit 979 (RD/LB), harness side and ground. Is the resistance less than 5 ohms between the driver seat front height motor and the driver seat control switch; and greater than 10,000 ohms between the driver seat control switch and ground? Yes : INSTALL a new driver seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The passenger seat control switch is powered by battery voltage on circuit 1462 (RD/WH) and is supplied ground on circuit 1205 (BK). When pressed, the seat control switch supplies that voltage and ground to a power seat track motor to move the seat. When pressed in the opposite direction, the seat control switch reverses the polarity to that same power seat track motor, which moves the seat in the opposite direction. There is a power seat track motor that moves the seat horizontally (FORWARD/REVERSE) and a motor in the power recliner mechanism that moves the seat backrest forward or rearward.

A power seat that does not move horizontally and/or vertically can be caused by

1. wiring, terminals or connectors.
2. a faulty seat control switch.
3. a faulty seat track motor (seat track).

Scheme 55

Scheme 56

Scheme 57

1. G1 CHECK THE PASSENGER SEAT MOTOR OPERATION WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3227. Connect the battery ground cable. Disconnect the passenger seat motor connector in question: (horizontal motor C332 or seat recliner motor C3189). Using the following table, measure the voltage between the inoperative passenger seat motor connector, harness side and ground, while moving the seat control switch in the indicated direction: PIN CONNECTOR CIRCUIT REFERENCE Motor Connector Pin Circuit Direction of Control Switch Horizontal Motor C332 2 986 (YE/WH) FORWARD Horizontal Motor C332 1 987 (RD/WH) REARWARD Recliner Motor C3189 1 988 (YE/LG) FORWARD Recliner Motor C3189 2 989 (RD/LG) REARWARD Are the voltages greater than 10 volts in the inoperative directions? Result/ Action to Take Yes : INSTALL a new passenger seat track assembly or backrest frame assembly. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to G2.
2. G2 CHECK THE PASSENGER SEAT MOTOR CIRCUITS FOR A SHORT TO GROUND Disconnect: Passenger Seat Control Switch C330. Using the following table, measure the resistance between passenger seat control switch C330 pins, harness side and ground: PIN CONNECTOR CIRCUIT REFERENCE Pin Circuit Inoperative Motor 8 989 (RD/LG) Recliner 11 988 (YE/LG) Recliner 4 986 (YE/WH) Horizontal 9 987 (RD/WH) Horizontal Are the resistances greater than 10,000 ohms? Yes : GO to G3. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. G3 CHECK FOR AN OPEN CIRCUIT Key in OFF position. Measure the resistance between passenger seat control switch C330 pins, harness side and the inoperative motor connector, harness side: PIN CONNECTOR CIRCUIT REFERENCE C330 Pin Circuit Motor Connector Horizontal Motor 4 986 (YE/WH) C332 pin 2 9 987 (RD/WH) C332 pin 1 Recliner Motor 8 989 (RD/LG) C338 pin 2 11 988 (YE/LG) C338 pin 1 Are the resistances less than 5 ohms? Yes : INSTALL a new passenger seat control switch. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The power seat should move quietly during operation. Some noise is acceptable.

A noisy power seat can be caused by

1. a misaligned seat track.
2. a faulty seat track component.
3. an object obstructing seat movement.

Testing

1. H1 CHECK THE TRACK ALIGNMENT WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect the driver seat side air bag C3226 or passenger seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226 or passenger seat side air bag C3227. Connect the battery ground cable. Check the alignment of the track to the floor and the track to the seat. Is the track out of alignment? Result/ Action to Take Yes : ALIGN the track to the seat and the floor. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : INSTALL a new seat track part. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The power seat movement should be smooth and the seat cushion should not rock during or after operation.

A loose power seat can be caused by

1. loose fastening hardware.
2. a faulty seat track component.

1. I1 CHECK THE FASTENING HARDWARE WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect the driver seat side air bag C3226 or passenger seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226 or passenger seat side air bag C3227. Connect the battery ground cable. Key in OFF position. Is the fastening hardware loose? Result/ Action to Take Yes : TIGHTEN all fastening hardware to specification. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : IDENTIFY the cause and INSTALL a new seat track component. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver power seat should travel fully horizontal (FORWARD/REARWARD) and vertical (front UP/DOWN and rear UP/DOWN). The passenger power seat should travel fully horizontal (FORWARD/REARWARD).

A power seat that does not make full travel can be caused by

1. an obstruction.
2. a faulty seat track component.

1. J1 CHECK FOR AN OBSTRUCTION IN THE SEAT TRACK WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect the driver seat side air bag C3226 or passenger seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226 or passenger seat side air bag C3227. Connect the battery ground cable. Remove the affected seat. Refer to «SEAT - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) in this section. Are there any obstructions in the track? Result/ Action to Take Yes : REMOVE the obstruction(s) and GREASE the track(s). TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : IDENTIFY the cause and INSTALL a new seat track component. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226 or passenger seat side air bag module C3227. CONNECT driver seat side air bag module C3226 or passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver seat control switch is powered by battery voltage on circuit 956 (OG/LG) and is supplied ground on circuit 1205 (BK). When pressed, the seat control switch supplies the voltage and ground to the applicable driver seat module (DSM) inputs. The DSM then supplies voltage and ground to the appropriate power seat track motor based on the inputs received from the seat control switch. When pressed in the opposite direction, the seat control switch reverses the polarity to the DSM inputs, and the DSM likewise reverses polarity of the appropriate power seat track motor or power recliner motor circuits causing the seat or backrest to move in the opposite direction. There are 3 power seat track motors that combine to move the seat horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). The seat backrest power recliner mechanism uses a single motor to move the seat backrest FORWARD and REARWARD.

Battery voltage is also supplied to DSM circuit 566 (DG) and is supplied ground to DSM circuit 1203 (BK/LB).

Each motor, in the memory power seat track and power recliner mechanism contains a Hall-effect position sensor. The DSM supplies a signal feed circuit to each position sensor and a shared reference signal return circuit. Each position sensor sends a signal voltage back to the DSM used to monitor the position of the power seat and seat backrest. The DSM uses this information to return the seat to a stored pre-programmed position when pressing the memory SET switch or a remote entry transmitter. Refer to PRINCIPLES OF OPERATION or the owner's literature for additional information on programming the DSM for storing memory seat positions.

The following pinpoint test diagnoses a memory seat that does not operate in one or more directions when using the seat control switch. If the memory seat moves in all directions using the seat control switch, GO to PINPOINT TEST G .

An inoperative memory seat can be caused by

1. a fuse.
2. wiring, terminals or connectors.
3. a faulty seat control switch.
4. a faulty power seat track.
5. a faulty power recliner mechanism.
6. a faulty DSM.

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. K1 RETRIEVE THE DTCs WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a SRS fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track position sensors are integral to the memory seat track motors. The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Connect the scan tool. Enter the following diagnostic mode on the scan tool: Retrieve and Document Continuous DTCs. Enter the following diagnostic mode on the scan tool: Clear the Continuous DTCs. Enter the following diagnostic mode on the scan tool: On-Demand Self Test. Are any DTCs retrieved? Result/ Action to Take Yes : If DTCs B1663, B1664, B1665 and B1666 are all retrieved, GO to K10 . If DTC B1663, GO to K20 . If DTC B1664, GO to K23 . If DTC B1665, GO to K26 . If DTC B1666, GO to K29 . If DTC B1703, GO to K3 . If DTC B1707, GO to K3 . If DTC B1711, GO to K3 . If DTC B1715, GO to K3 . If DTC B1719, GO to K3 . If DTC B1723, GO to K3 . If DTC B1727, GO to K3 . If DTC B1731, GO to K3 . If DTC B1342, INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K2.
2. K2 MONITOR THE DSM PIDs AND CHECK FOR CORRECT MEMORY SEAT SWITCH INPUTS Enter the following diagnostic mode on the scan tool: Monitor DSM PIDs: DRIVER SEAT/PEDAL INPUT SWITCH STATUS. Monitor DSM PIDs SFNT_SW, SFWD_SW, SREARSW, and SRCL_SW while activating the seat switch in all positions. Do the PID values agree with the switch positions? Yes : GO to K9 . No : If smart junction box (SJB) F2.10 (7.5A) fails while operating the seat control switch, DISCONNECT the seat control switch C369 and GO to K7 . If SJB F2.10 (7.5A) is OK, GO to K3.
3. K3 CHECK THE SEAT CONTROL SWITCH Key in OFF position. Disconnect: Seat Control Switch C369. Check the seat control switch. Refer to «COMPONENT TESTING»(/ford/five-hundred/i-2004-2007/remont/accessories-control-systems/#component-testing) . Is the seat control switch OK? Yes : GO to K4. No : INSTALL a new seat control switch. REFER to «SEAT CONTROL SWITCH»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. K4 CHECK CIRCUIT 956 (OG/LG) FOR VOLTAGE TO THE SEAT CONTROL SWITCH Measure the voltage between seat control switch C369 pin 5, circuit 956 (OG/LG), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to K5. No : REPAIR the circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
5. K5 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between seat control switch C369 pin 3, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to K6. No : REPAIR the circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
6. K6 CHECK CIRCUITS 456, 457, 1463, 1464, 1465, 1466, 1467 AND 1468 FOR A SHORT TO POWER Disconnect: DSM C341b. Key in ON position. Measure the voltage between the following seat control switch C369 pins, harness side and ground. CONNECTOR CIRCUIT REFERENCE Connector C369 Circuit Pin 9 1466 (GY/OG) Pin 4 1465 (GY/WH) Pin 2 1463 (RD/YE) Pin 6 1464 (YE) Pin 11 456 (GY) Pin 8 457 (GY/BK) Pin 12 1467 (GY/YE) Pin 1 1468 (GY/LB) Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K7.
7. K7 CHECK CIRCUITS 456, 457, 1463, 1464, 1465, 1466, 1467 AND 1468 FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between the following seat control switch C369 pins, harness side and ground. CONNECTOR CIRCUIT REFERENCE Connector C369 Circuit Pin 9 1466 (GY/OG) Pin 4 1465 (GY/WH) Pin 2 1463 (RD/YE) Pin 6 1464 (YE) Pin 11 456 (GY) Pin 8 457 (GY/BK) Pin 12 1467 (GY/YE) Pin 1 1468 (GY/LB) Are the resistances greater than 10,000 ohms? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K8.
8. K8 CHECK CIRCUITS 456, 457, 1463, 1464, 1465, 1466, 1467 AND 1468 FOR AN OPEN Measure the resistance between the following seat control switch C369 pins, harness side and DSM C341b pins, harness side. SEAT CONTROL SWITCH SPECIFICATION Seat Control Switch C369 Circuit DSM C341b Pin 9 1466 (GY/OG) Pin 15 Pin 4 1465 (GY/WH) Pin 3 Pin 2 1463 (RD/YE) Pin 14 Pin 6 1464 (YE) Pin 2 Pin 11 456 (GY) Pin 17 Pin 8 457 (GY/BK) Pin 5 Pin 12 1467 (GY/YE) Pin 4 Pin 1 1468 (GY/LB) Pin 16 Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
9. K9 CHECK THE DSM FOR CORRECT OUTPUTS USING A DIAGNOSTIC TOOL AND DSM ACTIVE COMMANDS Enter the following diagnostic mode on the scan tool: Active Commands: DRIVER SEAT OUTPUT CONTROL. Toggle the following DSM active commands ON and OFF while monitoring the seat movement: FRONT MOTOR UP FRONT MOTOR DOWN REAR MOTOR UP REAR MOTOR DOWN HORIZONTAL MOTOR FORWARD HORIZONTAL MOTOR BACKWARD RECLINE MOTOR FORWARD RECLINE MOTOR BACKWARD Does the driver seat operate correctly? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : If no seat movement, GO to K10. If no front vertical seat movement, GO to K20 . If no rear vertical seat movement, GO to K23 . If no horizontal seat movement, GO to K26 . If no recline seat movement, GO to K29 .
10. K10 CHECK DSM CIRCUIT 566 (DG) FOR VOLTAGE Key in OFF position. Disconnect: DSM C341a. Measure the voltage between DSM C341a pin 2, circuit 566 (DG), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to K11. No : REPAIR the circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
11. K11 CHECK CIRCUITS 1205 (BK) AND 1203 (BK/LB) FOR AN OPEN Measure the resistance between DSM C341a pin 1, circuit 1205 (BK), harness side and ground; and between DSM C341c pin 13, circuit 1203 (BK/LB), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to K12. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
12. K12 CHECK CIRCUITS 1469 (RD/LB) AND 1470 (YE/LB) FOR A SHORT TO GROUND Disconnect: DSM C341b. Measure the resistance between DSM C341b pin 9, circuit 1469 (RD/LB), harness side and ground; and between DSM C341 b pin 23, circuit 1470 (YE/LB), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to K14 . No : GO to K13.
13. K13 CHECK FRONT HEIGHT POWER SEAT MOTOR CIRCUITS 1469 (RD/LB) AND 1470 (YE/LB) FOR A SHORT TO GROUND Disconnect: Front Height Power Seat Motor C382. Measure the resistance between DSM C341b pin 9, circuit 1469 (RD/LB), harness side and ground; and between DSM C341b pin 23, circuit 1470 (YE/LB), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
14. K14 CHECK CIRCUITS 1474 (RD/LG) AND 1473 (YE/LG) FOR A SHORT TO GROUND Measure the resistance between DSM C341b pin 8, circuit 1474 (RD/LG), harness side and ground; and between DSM C341b pin 22, circuit 1473 (YE/LG), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to K16 . No : GO to K15.
15. K15 CHECK THE REAR HEIGHT POWER SEAT MOTOR CIRCUITS 1474 (RD/LG) AND 1473 (YE/LG) FOR A SHORT TO GROUND Disconnect: Rear Height Power Seat Motor C363. Measure the resistance between DSM C341b pin 8, circuit 1474 (RD/LG), harness side and ground; and between DSM C341b pin 22, circuit 1473 (YE/LG), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
16. K16 CHECK CIRCUITS 1472 (YE/WH) AND 1471 (RD/WH) FOR A SHORT TO GROUND Measure the resistance between DSM C341b pin 10, circuit 1472 (YE/WH), harness side and ground; and between DSM C341b pin 12, circuit 1471 (RD/WH), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to K18 . No : GO to K17.
17. K17 CHECK THE HORIZONTAL POWER SEAT MOTOR CIRCUITS 1472 (YE/WH) AND 1471 (RD/WH) FOR A SHORT TO GROUND Disconnect: Horizontal Power Seat Motor C362. Measure the resistance between DSM C341b pin 10, circuit 1472 (YE/WH), harness side and ground; and between DSM C341b pin 12, circuit 1471 (RD/WH), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
18. K18 CHECK CIRCUITS 1947 (DG/WH) AND 1948 (LB/WH) FOR A SHORT TO GROUND Measure the resistance between DSM C341b pin 11, circuit 1947 (DG/WH), harness side and ground; and between DSM C341b pin 21, circuit 1948 (LB/WH), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K19.
19. K19 CHECK THE DRIVER POWER SEAT RECLINER MOTOR CIRCUITS 1947 (DG/WH) AND 1948 (LB/WH) FOR A SHORT TO GROUND Disconnect: Driver Power Seat Recliner Motor C3187. Measure the resistance between DSM C341b pin 11, circuit 1947 (DG/WH), harness side and ground; and between DSM C341b pin 21, circuit 1948 (LB/WH), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : INSTALL a new driver seat recliner assembly. REFER to «SEAT RECLINER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
20. K20 CHECK THE FRONT HEIGHT POWER SEAT MOTOR FOR CORRECT OPERATION Key in OFF position. Disconnect: Front Height Power Seat Motor C382. Key in ON position. Enter the following diagnostic mode on the scan tool: DSM Active Command: DRIVER SEAT OUTPUT CONTROL. Measure the voltage between front height power seat motor C382 pin 2, circuit 1469 (RD/LB) and C382 pin 1, circuit 1470 (YE/LB), harness side while toggling DSM active commands FRONT MOTOR UP and FRONT MOTOR DOWN, ON and OFF. Is voltage present when the motor is commanded ON and no voltage present when commanded OFF? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K21.
21. K21 CHECK CIRCUITS 1469 (RD/LB) AND 1470 (YE/LB) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Key in ON position. Measure the voltage between DSM C341b pin 9, circuit 1469 (RD/LB), harness side and ground; and between DSM C341b pin 23, circuit 1470 (YE/LB), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K22.
22. K22 CHECK CIRCUITS 1469 (RD/LB) AND 1470 (YE/LB) FOR AN OPEN Key in OFF position. Measure the resistance between DSM C341b pin 9, circuit 1469 (RD/LB), harness side and front height power seat motor C382 pin 2, circuit 1469 (RD/LB), harness side; and between DSM C341b pin 23, circuit 1470 (YE/LB), harness side and front height power seat motor C382 pin 1 circuit 1470 (YE/LB), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
23. K23 CHECK THE REAR HEIGHT MOTOR FOR CORRECT OPERATION Key in OFF position. Disconnect: Rear Height Power Seat Motor C363. Key in ON position. Enter the following diagnostic mode on the scan tool: DSM Active Command: DRIVER SEAT OUTPUT CONTROL. Measure the voltage between rear height power seat motor C363 pin 2, circuit 1474 (RD/LG), harness side and C363 pin 1, circuit 1473 (YE/LG), harness side while toggling DSM active commands REAR MOTOR UP and REAR MOTOR DOWN, ON and OFF. Is voltage present when the motor is commanded ON and no voltage present when commanded OFF? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K24.
24. K24 CHECK CIRCUITS 1474 (RD/LG) AND 1473 (YE/LG) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Key in ON position. Measure the voltage between DSM C341b pin 8, circuit 1474 (RD/LG), harness side and ground; and between DSM C341b pin 22, circuit 1473 (YE/LG), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K25.
25. K25 CHECK CIRCUITS 1474 (RD/LG) AND 1473 (YE/LG) FOR AN OPEN Key in OFF position. Measure the resistance between DSM C341b pin 8, circuit 1474 (RD/LG), harness side and rear height power seat motor C363 pin 2, circuit 1474 (RD/LG), harness side; and between DSM C341b pin 22, circuit 1473 (YE/LG), harness side and rear height power seat motor C363 pin 1, circuit 1473 (YE/LG), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
26. K26 CHECK THE HORIZONTAL MOTOR FOR CORRECT OPERATION Key in OFF position. Disconnect: Horizontal Power Seat Motor C362. Key in ON position. Enter the following diagnostic mode on the scan tool: DSM Active Command: DRIVER SEAT OUTPUT CONTROL. Measure the voltage between horizontal power seat motor C362 pin 2, circuit 1472 (YE/WH) and C362 pin 1, circuit 1471 (RD/WH), harness side while toggling DSM active commands HORIZONTAL MOTOR FORWARD and HORIZONTAL MOTOR BACKWARD, ON and OFF. Is voltage present when the motor is commanded ON and no voltage present when commanded OFF? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K27.
27. K27 CHECK CIRCUITS 1472 (YE/WH) AND 1471 (RD/WH) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Key in ON position. Measure the voltage between DSM C341b pin 10, circuit 1472 (YE/WH), harness side and ground; and between DSM C341b pin 12, circuit 1471 (RD/WH), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K28.
28. K28 CHECK CIRCUITS 1472 (YE/WH) AND 1471 (RD/WH) FOR AN OPEN Key in OFF position. Measure the resistance between DSM C341b pin 10, circuit 1472 (YE/WH), harness side and horizontal power seat motor C362 pin 2, circuit 1472 (YE/WH), harness side; and between DSM C341b pin 12, circuit 1471 (RD/WH), harness side and horizontal power seat motor C362 pin 1, circuit 1471 (RD/WH), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
29. K29 CHECK THE DRIVER SEAT POWER RECLINER MOTOR FOR CORRECT OPERATION Key in OFF position. Disconnect: Driver Seat Power Recliner Motor C3187. Key in ON position. Enter the following diagnostic mode on the scan tool: DSM Active Command: DRIVER SEAT OUTPUT CONTROL. Measure the voltage between driver seat power recliner motor C3187 pin 1, circuit 1947 (DG/WH) and C3187 pin 2, circuit 1948 (LB/WH), harness side while toggling DSM active commands RECLINE MOTOR FORWARD and RECLINE MOTOR BACKWARD, ON and OFF. Is voltage present when the motor is commanded ON and no voltage present when commanded OFF? Yes : INSTALL a new driver seat recliner assembly. REFER to «SEAT RECLINER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K30.
30. K30 CHECK CIRCUITS 1947 (DG/WH) AND 1948 (LB/WH) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Key in ON position. Measure the voltage between DSM C341b pin 11, circuit 1947 (DG/WH), harness side and ground; and between DSM C341b pin 21, circuit 1948 (LB/WH), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to K31.
31. K31 CHECK CIRCUITS 1947 (DG/WH) AND 1948 (LB/WH) FOR AN OPEN Key in OFF position. Measure the resistance between DSM C341b pin 11, circuit 1947 (DG/WH), harness side and recliner power seat motor C3187 pin 1, circuit 1947 (DG/WH), harness side; and between DSM C341b pin 21, circuit 1948 (LB/WH), harness side and recliner power seat motor C3187 pin 2, circuit 1948 (LB/WH), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver seat control switch is powered by battery voltage on circuit 956 (OG/LG) and is supplied ground on circuit 1205 (BK). When pressed, the seat control switch supplies the voltage and ground to the applicable driver seat module (DSM) inputs. The DSM then supplies voltage and ground to the appropriate power seat track motor based on the inputs received from the seat control switch. When pressed in the opposite direction, the seat control switch reverses the polarity to the DSM inputs, and the DSM likewise reverses polarity of the appropriate power seat track motor or power recliner motor circuits causing the seat or backrest to move in the opposite direction. There are 3 power seat track motors that combine to move the seat horizontally (FORWARD/REARWARD) and vertically (front UP/DOWN and rear UP/DOWN). The seat backrest power recliner mechanism uses a single motor to move the seat backrest FORWARD and REARWARD.

Battery voltage is also supplied to DSM circuit 566 (DG) and is supplied ground to DSM circuit 1203 (BK/LB).

Each motor, in the memory power seat track and power recliner mechanism contains a Hall-effect position sensor. The DSM supplies a signal feed circuit to each position sensor and a shared reference signal return circuit. Each position sensor sends a signal voltage back to the DSM used to monitor the position of the power seat and seat backrest. The DSM uses this information to return the seat to a stored pre-programmed position when pressing the memory SET switch or a remote entry transmitter. Refer to the owner literature or Principles of Operation in this section. For additional information on programming the DSM for storing memory seat positions.

The following pinpoint test diagnoses a memory seat that does not operate correctly using the memory SET switch. If the memory seat does not move in all directions using the seat control switch, GO to PINPOINT TEST K .

A memory seat that does not operate correctly can be caused by

1. wiring, terminals or connectors.
2. a faulty memory SET switch.
3. a faulty remote entry transmitter.
4. a faulty memory power seat track.
5. a faulty recliner mechanism.
6. a faulty DSM.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. L1 RETRIEVE THE DTCs WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a SRS fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. NOTE: The memory seat track position sensors are integral to the memory seat track motors. The memory seat track motor electrical connectors will connect to a seat track without the memory option. When installing a new seat track, make sure the correct memory or non-memory seat track is being installed. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Connect the scan tool. Enter the following diagnostic mode on the scan tool: Retrieve and Document Continuous DTCs. Enter the following diagnostic mode on the scan tool: Clear Continuous DTCs. Enter the following diagnostic mode on the scan tool: On-Demand Self Test. NOTE: During the On-Demand Self Test, document when the memory SET LED illuminates and turns off. Are any DTCs retrieved or does the memory SET LED fail to illuminate during the On-Demand Self Test? Result/ Action to Take Yes : If the memory SET LED fails to illuminate during the On-Demand Self Test, GO to L5 . If DTC B2084, GO to L5 . If DTCs B1952, B1956, B1960 and B1964 are all retrieved, GO to L8 . If DTCs B1953, B1957, B1961, and B1965 are all retrieved, GO to L8 . If DTC B1530, GO to L3 . If DTC B1534, GO to L3 . If DTC B1538, GO to L3 . If DTC B1663, GO to L9 . If DTC B1664, GO to L12 . If DTC B1665, GO to L15 . If DTC B1666, GO to L18 . If DTC B1952, GO to L12 . If DTC B1953, GO to L12 . If DTC B1956, GO to L9 . If DTC B1957, GO to L9 . If DTC B1960, GO to L18 . If DTC B1961, GO to L18 . If DTC B1964, GO to L15 . If DTC B1965, GO to L15 . If DTC B1342, INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L2.
2. L2 MONITOR THE DSM PIDs AND CHECK THE DSM FOR CORRECT MEMORY SET SWITCH INPUTS Enter the following diagnostic mode on the scan tool: Monitor DSM PIDs: MEMORY SET/RECALL INPUT SWITCH STATUS. Monitor the DSM PIDs MEMORY SET SWITCH, MEMORY SET/RECALL 1 SWITCH and MEMORY SET RECALL 2 SWITCH while activating the memory switch SET, recall 1 and recall 2 buttons. Do the PID values agree with the switch button positions? Yes : GO to L8 . No : GO to L3.
3. L3 CHECK THE MEMORY SET SWITCH Key in OFF position. Disconnect: Memory SET Switch C503. Carry out the Memory SET Switch Component Test. Is the memory SET switch OK? Yes : GO to L4. No : INSTALL a new memory SET switch. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. L4 CHECK GROUND CIRCUIT 1205 (BK) TO THE MEMORY SET SWITCH Key in ON position. Measure the resistance between memory SET switch C503 pin 2, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to L5. No : REPAIR the circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
5. L5 CHECK CIRCUITS 267 (BN/LG), 268 (BK/OG), 270 (BN/OG) AND 272 (WH/OG) FOR A SHORT TO POWER Disconnect: DSM C341c. Key in ON position. Measure the voltage between the following memory SET switch C503 pins, harness side and ground: CONNECTOR CIRCUIT REFERENCE Connector C503 Circuit Pin 3 268 (BK/OG) Pin 4 270 (BN/OG) Pin 7 267 (BN/LG) Pin 8 272 (WH/OG) Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L6.
6. L6 CHECK CIRCUITS 267 (BN/LG), 268 (BK/OG), 270 (BN/OG) AND 272 (WH/OG) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between the following memory SET switch C503 pins, harness side and ground: CONNECTOR CIRCUIT REFERENCE Connector C503 Circuit Pin 3 268 (BK/OG) Pin 4 270 (BN/OG) Pin 7 267 (BN/LG) Pin 8 272 (WH/OG) Are the resistances greater than 10,000 ohms? Yes : GO to L7. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
7. L7 CHECK CIRCUITS 267 (BN/LG), 268 (BK/OG), 270 (BN/OG) AND 272 (WH/OG) FOR AN OPEN Measure the resistance between the following memory SET switch C503 pins and DSM C341c pins: DTC DETECTION CONDITION CHART Memory SET Switch C503 Circuit DSM C341c Pin 3 268 (BK/OG) Pin 4 Pin 4 270 (BN/OG) Pin 3 Pin 7 267 (BN/LG) Pin 15 Pin 8 272 (WH/OG) Pin 8 Are the resistances less than 5 ohms? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
8. L8 MONITOR THE DSM PIDs Place the seat in a central position, using the seat control switch. Enter the following diagnostic mode on the scan tool: Monitor DSM PID: DRIVER SEAT/MIRROR/PEDAL SENSOR OUTPUT STATUS. Monitor the DSM PIDs SFNT_MT, SREARMT, SFWD_MT and SRCL_MT. Does each PID indicate SENSED? Yes : INSTALL a new DSM. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#multifunction-electronic-modules-system) . CONFIGURE the DSM. REFER to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : If PID SFNT_MT indicates not sensed (notSEN), GO to L9. If PID SREARMT indicates notSEN, GO to L12 . If PID SFWD_MT indicates notSEN, GO to L15 . If the PID SRCL_MT indicates notSEN, GO to L18 .
9. L9 CHECK CIRCUITS 443 (LG/RD) AND 452 (GY/RD) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Disconnect: Driver Seat Front Height Motor C382. Key in ON position. Measure the voltage between driver seat front height motor C382 pin 4, circuit 443 (LG/RD), harness side and ground; and between driver seat front height motor C382 pin 3, circuit 452 (GY/RD), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L10.
10. L10 CHECK CIRCUITS 443 (LG/RD) AND 452 (GY/RD) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between driver seat front height motor C382 pin 4, circuit 443 (LG/RD), harness side and ground; and between driver seat front height motor C382 pin 3, circuit 452 (GY/RD), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to L11. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
11. L11 CHECK CIRCUITS 443 (LG/RD) AND 452 (GY/RD) FOR AN OPEN Measure the resistance between driver seat front height motor C382 pin 4, circuit 443 (LG/RD), harness side and DSM C341b pin 7, circuit 443 (LG/RD), harness side; and between driver seat front height motor C382 pin 3, circuit 452 (GY/RD), harness side and DSM C341b pin 20, circuit 452 (GY/RD), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
12. L12 CHECK CIRCUITS 444 (LG/BK) AND 452 (GY/RD) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Disconnect: Driver Seat Rear Height Motor C363. Measure the voltage between driver seat rear height motor C363 pin 4, circuit 444 (LG/BK), harness side and ground; and between driver seat rear height motor C363 pin 3, circuit 452 (GY/RD), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L13.
13. L13 CHECK CIRCUITS 444 (LG/BK) AND 452 (GY/RD) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between driver seat rear height motor C363 pin 4, circuit 444 (LG/BK), harness side and ground; and between driver seat rear height motor C363 pin 3, circuit 452 (GY/RD), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to L14. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
14. L14 CHECK CIRCUITS 444 (LG/BK) AND 452 (GY/RD) AND FOR AN OPEN Measure the resistance between driver seat rear height motor C363 pin 4, circuit 444 (LG/BK), harness side and DSM C341b pin 18, circuit 444 (LG/BK), harness side; and between driver seat rear height motor C363 pin 3, circuit 452 (GY/RD), harness side and DSM C341b pin 20, circuit 452 (GY/RD), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit(s) in question. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
15. L15 CHECK CIRCUITS 442 (LG/OG) AND 452 (GY/RD) AND FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Disconnect: Driver Seat Horizontal Motor C362. Measure the voltage between driver seat horizontal motor C362 pin 4, circuit 442 (LG/OG), harness side and ground; and between driver seat horizontal motor C362 pin 3, circuit 452 (GY/RD), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L16.
16. L16 CHECK CIRCUITS 442 (LG/OG) AND 452 (GY/RD) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between driver seat horizontal motor C362 pin 4, circuit 442 (LG/OG), harness side and ground; and between driver seat horizontal motor C362 pin 3, circuit 452 (GY/RD), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to L17. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
17. L17 CHECK CIRCUITS 442 (LG/OG) AND 452 (GY/RD) FOR AN OPEN Measure the resistance between driver seat horizontal motor C362 pin 4, circuit 442 (LG/OG), harness side and DSM C341b pin 19, circuit 442 (LG/OG), harness side; and between driver seat horizontal motor C362 pin 3, circuit 452 (GY/RD), harness side and DSM C341b pin 20, circuit 452 (GY/RD), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new driver seat track assembly. REFER to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
18. L18 CHECK CIRCUITS 449 (BN/PK) AND 452 (GY/RD) FOR A SHORT TO POWER Key in OFF position. Disconnect: DSM C341b. Disconnect: Driver Seat Recliner Motor C3187. Measure the voltage between driver seat recliner motor C3187 pin 4, circuit 449 (BN/PK), harness side and ground; and between driver seat recliner motor C3187 pin 3, circuit 452 (GY/RD), harness side and ground. Is voltage indicated? Yes : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to L19.
19. L19 CHECK CIRCUITS 449 (BN/PK) AND 452 (GY/RD) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between driver seat recliner motor C3187 pin 4, circuit 449 (BN/PK), harness side and ground; and between driver seat recliner motor C3187 pin 3, circuit 452 (GY/RD), harness side and ground. Are the resistances greater than 10,000 ohms? Yes : GO to L20. No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
20. L20 CHECK CIRCUITS 449 (BN/PK) AND 452 (GY/RD) FOR AN OPEN Measure the resistance between driver seat recliner motor C3187 pin 4, circuit 449 (BN/PK), harness side and DSM C341b pin 6, circuit 449 (BN/PK), harness side; and between driver seat recliner motor C3187 pin 3, circuit 452 (GY/RD), harness side and DSM C341b pin 20, circuit 452 (GY/RD), harness side. Are the resistances less than 5 ohms? Yes : INSTALL a new driver seat recliner assembly. REFER to «SEAT RECLINER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuit. REPEAT the self-test. CLEAR the DTCs. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver and passenger heated seat modules share a common battery and ignition feed and have a separate ground source. The electronic automatic temperature control (EATC) module includes the heated seat control buttons and indicators. The heated seat system will function when the EATC module is ON or OFF. When a heated seat control button on the EATC module is pressed with the ignition switch in RUN or START, a momentary ground signal is sent to the heated seat module. Upon receiving a signal, the heated seat module will decrease one setting (the sequence is HI, LO, OFF, HI, etc.). When the heated seat system is ON, the heated seat module then supplies power to the heating element circuit. The cushion element and backrest element are wired in series and powered by the same output. The heated seat module will remain on for 10 minutes or until the heated seat control button is pressed to cycle the heated seat module to the OFF state. If the ignition source is removed from the module, the heated seat module will enter an OFF state and will not return to ON until the heated seat control button is once again pressed with the ignition switch in RUN.

An inoperative heated seat can be caused by

1. open fuse.
2. wiring, terminals or connectors.
3. a faulty heated seat element.
4. a faulty heated seat module.
5. a faulty EATC module.

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

1. M1 CHECK THE VOLTAGE TO THE HEATED SEAT MODULE WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Disconnect: Driver Heated Seat Module C359. Key in ON position. Measure the voltage between driver heated seat module C359 pin 12, circuit 1048 (LB/WH), harness side and ground; and between driver heated seat module C359 pin 5, circuit 972 (BK/WH), harness side and ground. Are the voltages greater than 10 volts? Result/ Action to Take Yes : GO to M2. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. M2 CHECK THE HEATED SEAT MODULE GROUND Key in OFF position. Measure the resistance between driver heated seat module C359 pin 1, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to M3. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. M3 CHECK THE HEATED SEAT TEMPERATURE SENSOR CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between driver heated seat module C359 pin 3, circuit 1061 (BN/LB), harness side and ground; and between C359 pin 4, circuit 1060 (BK/LB), harness side and ground. Is voltage present on either circuit? Yes : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to M4.
4. M4 CHECK THE HEATED SEAT TEMPERATURE SENSOR Key in OFF position. Measure the resistance between driver heated seat module C359 pin 3, circuit 1061 (BN/LB), harness side and C359 pin 4, circuit 1060 (BK/LB), harness side; and between C359 pin 3, circuit 1061 (BN/LB), harness side and ground. Is the resistance between 50 ohms and 300,000 ohms between C359 pin 3 and pin 4 and greater than 10,000 ohms between C359 pin 3 and ground? Yes : GO to M7 . No : GO to M5.
5. M5 CHECK CIRCUIT 1060 (BK/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Driver Seat Cushion Heated Seat Element C364. Measure the resistance between driver heated seat module C359 pin 4, circuit 1060 (BK/LB), harness side and driver seat cushion heated seat element C364 pin 2, circuit 1060 (BK/LB), harness side; and between driver heated seat module C359 pin 4, circuit 1060 (BK/LB), harness side and ground. Is the resistance less than 5 ohms between C359 pin 4 and C364 pin 2; and greater than 10,000 ohms between C359 pin 4 and ground? Yes : GO to M6. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
6. M6 CHECK CIRCUIT 1061 (BN/LB) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between driver heated seat module C359 pin 3, circuit 1061 (BN/LB), harness side and driver seat cushion heated seat element C364 pin 3, circuit 1061 (BN/LB), harness side; and between driver heated seat module C359 pin 3, circuit 1061 (BN/LB), harness side and ground. Is the resistance less than 5 ohms between C359 pin 3 and C364 pin 3; and greater than 10,000 ohms between C359 pin 3 and ground? Yes : INSTALL a new driver seat cushion heated seat element. REFER to «SEAT CUSHION - DRIVER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
7. M7 CHECK THE SEAT CUSHION HEATED SEAT ELEMENT AND THE SEAT BACK HEATED SEAT ELEMENT FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between driver heated seat module C359 pin 6, circuit 1064 (YE/LB), harness side and ground; and between C359 pin 7, circuit 1067 (VT/LB), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit 1064 (YE/LB), circuit 1067 (VT/LB) or circuit 1066 (GY/LB) for short to voltage. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to M8.
8. M8 CHECK THE SEAT CUSHION HEATED SEAT ELEMENT AND SEAT BACK HEATED SEAT ELEMENT CIRCUITS Key in OFF position. Measure the resistance between driver heated seat module C359 pin 6, circuit 1064 (YE/LB), harness side and C359 pin 7, circuit 1067 (VT/LB), harness side; and between driver heated seat module C359 pin 6, circuit 1064 (YE/LB), harness side and ground Is the resistance between 1.6 ohms and 10 ohms between C359 pin 6 and pin 7 and greater than 10,000 ohms between C359 pin 6 and ground? Yes : GO to M13 . No : GO to M9.
9. M9 CHECK CIRCUIT 1064 (YE/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Driver Seat Cushion Heated Seat Element C364. Measure the resistance between driver heated seat module C359 pin 6, circuit 1064 (YE/LB), harness side and driver seat cushion heated seat element C364 pin 1, circuit 1064 (YE/LB), harness side; and between driver heated seat module C359 pin 6, circuit 1064 (YE/LB), harness side and ground. Is the resistance less than 5 ohms between C359 pin 6 and C364 pin 1 and greater than 10,000 ohms between C359 pin 6 and ground? Yes : GO to M10. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
10. M10 CHECK CIRCUIT 1067 (VT/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Driver Seat Backrest Heated Seat Element C365. Measure the resistance between driver heated seat module C359 pin 7, circuit 1067 (VT/LB), harness side and driver seat backrest heated seat element C365 pin 1, circuit 1067 (VT/LB), harness side; and between driver heated seat module C359 pin 7, circuit 1067 (VT/LB), harness side and ground. Is the resistance less than 5 ohms between C359 pin 7 and C365 pin 1; and greater than 10,000 ohms between C359 pin 7 and ground? Yes : GO to M11. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
11. M11 CHECK CIRCUIT 1066 (GY/LB) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between driver seat cushion heated seat element C364 pin 4, circuit 1066 (GY/LB), harness side and driver seat backrest heated seat element C365 pin 2, circuit 1066 (GY/LB), harness side; and between driver seat cushion heated seat element C364 pin 4, circuit 1066 (GY/LB), harness side and ground. Is the resistance less than 5 ohms between C364 pin 4 and pin 2; and greater than 10,000 ohms between C364 pin 4 and ground? Yes : GO to M12. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
12. M12 CHECK THE DRIVER SEAT BACKREST HEATED SEAT ELEMENT Measure the resistance between driver seat backrest heated seat element C365 pin 1, component side and C365 pin 2, component side. Is the resistance between 0.6 and 1.2 ohms? Yes : INSTALL a new driver seat cushion heated seat element. REFER to «SEAT CUSHION - DRIVER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : INSTALL a new driver seat backrest heated seat element. REFER to «SEAT BACKREST - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
13. M13 CHECK CIRCUIT 1255 (WH/RD) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: EATC Module C228b. Key in ON position. Measure the voltage between driver heated seat module C359 pin 8, circuit 1255 (WH/RD), harness side and ground. Is the voltage less than 0.2 volt? Yes : GO to M14. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
14. M14 CHECK CIRCUIT 1255 (WH/RD) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between driver heated seat module C359 pin 8, circuit 1255 (WH/RD), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to M15. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
15. M15 CHECK CIRCUIT 1255 (WH/RD) FOR AN OPEN Measure the resistance between driver heated seat module C359 pin 8, circuit 1255 (WH/RD), harness side and EATC module C228b pin 6, circuit 1255 (WH/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to M16. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
16. M16 CHECK THE HEATED SEAT MODULE Connect: Driver Heated Seat Module C359. Key in ON position. Measure the voltage between EATC module C228b pin 7, circuit 580 (BN), harness side and ground; and between EATC module C228b pin 8, circuit 579 (BK/OG), harness side and ground. Are the voltages less than 0.2 volt? Yes : GO to M18 . No : GO to M17.
17. M17 CHECK CIRCUITS 580 (BN) AND 579 (BK/OG) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Heated Seat Module C359. Key in ON position. Measure the voltage between EATC module C228b pin 7, circuit 580 (BN), harness side and ground; and between EATC module C228b pin 8, circuit 579 (BK/OG), harness side and ground. Are the voltages less than 0.2 volt? Yes : INSTALL a new heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuits. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
18. M18 CHECK CIRCUITS 580 (BN) AND 579 (BK/OG) FOR A SHORT Key in OFF position. Measure the resistance between EATC module C228b pin 7, circuit 580 (BN), harness side and C228b pin 8, circuit 579 (BK/OG), harness side. Is the resistance greater than 10,000 ohms? Yes : GO to M19. No : REPAIR the shorted circuits. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
19. M19 CHECK THE EATC MODULE OUTPUT Connect: EATC Module C228b. Connect: Driver Heated Seat Module C359. Key in ON position. NOTE: The following measurement must be taken by back-probing the driver heated seat module C359. NOTE: The voltage on circuit 1255 (WH/RD) should drop momentarily when the driver heated seat control button is pressed. Measure the voltage between driver heated seat module C359 pin 8, circuit 1255 (WH/RD), harness side and ground by back-probing driver heated seat module C359 pin 8. Press the driver heated seat control button on the EATC module and note the voltage. Is the voltage greater than 10 volts before pressing the driver heated seat control button, then momentarily drops when the heated seat control button is pressed? Yes : INSTALL a new driver heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : If the voltage is greater than 10 volts but did not drop when the driver heated seat button was pressed, INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . If the voltage is less than 10 volts, INSTALL a new driver heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

The driver and passenger heated seat modules share a common battery and ignition feed and have a separate ground source. The electronic automatic temperature control (EATC) module includes the heated seat control buttons and indicators. The heated seat system will function when the EATC module is ON or OFF. When a heated seat control button on the EATC module is pressed with the ignition switch in RUN or START, a momentary ground signal is sent to the heated seat module. Upon receiving a signal, the heated seat module will decrease one setting (the sequence is HI, LO, OFF, HI, etc.). When the heated seat system is ON, the heated seat module then supplies power to the heating element circuit. The cushion element and backrest element are wired in series and powered by the same output. The heated seat module will remain on for 10 minutes or until the heated seat control button is pressed to cycle the heated seat module to the OFF state. If the ignition source is removed from the module, the heated seat module will enter an OFF state and will not return to ON until the heated seat control button is once again pressed with the ignition switch in RUN.

An inoperative heated seat can be caused by

1. open fuse.
2. wiring, terminals or connectors.
3. a faulty heated seat element.
4. a faulty heated seat module.
5. a faulty EATC module.

Scheme 103

Scheme 104

Scheme 105

1. N1 CHECK VOLTAGE TO THE HEATED SEAT MODULE WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect passenger seat side air bag C3227. Connect restraint system diagnostic tool 418-133 to passenger seat side air bag C3227. Connect the battery ground cable. Disconnect: Passenger Heated Seat Module C329. Key in ON position. Measure the voltage between passenger heated seat module C329 pin 12, circuit 1048 (LB/WH), harness side and ground; and between passenger heated seat module C329 pin 5, circuit 972 (BK/WH), harness side and ground. Are the voltages greater than 10 volts? Result/ Action to Take Yes : GO to N2. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. N2 CHECK THE HEATED SEAT MODULE GROUND Key in OFF position. Measure the resistance between passenger heated seat module C329 pin 1, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to N3. No : REPAIR circuit 1205 (BK). TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. N3 CHECK THE HEATED SEAT TEMPERATURE SENSOR CIRCUITS FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between passenger heated seat module C329 pin 3, circuit 2121 (BN/LB), harness side and ground; and between C329 pin 4, circuit 2120 (BK/LB), harness side and ground. Is voltage present on either circuit? Yes : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to N4.
4. N4 CHECK THE HEATED SEAT TEMPERATURE SENSOR Key in OFF position. Measure the resistance between passenger heated seat module C329 pin 3, circuit 2121 (BN/LB), harness side and C329 pin 4, circuit 2120 (BK/LB), harness side; and between C329 pin 3, circuit 2121 (BN/LB), harness side and ground. Is the resistance between 50 ohms and 300,000 ohms between C329 pin 3 and pin 4 and greater than 10,000 ohms between C329 pin 3 and ground? Yes : GO to N7 . No : GO to N5.
5. N5 CHECK CIRCUIT 2120 (BK/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Passenger Seat Cushion Heated Seat Element C334. Measure the resistance between passenger heated seat module C329 pin 4, circuit 2120 (BK/LB), harness side and passenger seat cushion heated seat element C334 pin 2, circuit 2120 (BK/LB), harness side; and between passenger heated seat module C329 pin 4, circuit 2120 (BK/LB), harness side and ground. Is the resistance less than 5 ohms between C329 pin 4 and C334 pin 2; and greater than 10,000 ohms between C329 pin 4 and ground? Yes : GO to N6. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
6. N6 CHECK CIRCUIT 2121 (BN/LB) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between passenger heated seat module C329 pin 3, circuit 2121 (BN/LB), harness side and passenger seat cushion heated seat element C334 pin 3, circuit 2121 (BN/LB), harness side; and between passenger heated seat module C329 pin 3, circuit 2121 (BN/LB), harness side and ground. Is the resistance less than 5 ohms between C329 pin 3 and C334 pin 3 and greater than 10,000 ohms between C329 pin 3 and ground? Yes : INSTALL a new passenger seat cushion heated seat element. REFER to «SEAT CUSHION - PASSENGER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REFER to «OCCUPANT CLASSIFICATION SENSOR (OCS) SERVICE KIT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system__occupant-classification-sensor-ocs) in the Removal and Installation portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
7. N7 CHECK THE SEAT CUSHION HEATED SEAT ELEMENT AND THE SEAT BACK HEATED SEAT ELEMENT FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between passenger heated seat module C329 pin 6, circuit 2124 (YE/LB), harness side and ground; and between C329 pin 7, circuit 2127 (VT/LB), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit 2124 (YE/LB), circuit 2127 (VT/LB) or circuit 2126 (GY/LB). TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : GO to N8.
8. N8 CHECK THE SEAT CUSHION HEATED SEAT ELEMENT AND SEAT BACK HEATED SEAT ELEMENT CIRCUITS Key in OFF position. Measure the resistance between passenger heated seat module C329 pin 6, circuit 2124 (YE/LB), harness side and C329 pin 7, circuit 2127 (VT/LB), harness side; and between passenger heated seat module C329 pin 6, circuit 2124 (YE/LB), harness side and ground Is the resistance between 1.6 ohms and 10 ohms between C329 pin 6 and pin 7 and greater than 10,000 ohms between C329 pin 6 and ground? Yes : GO to N13 . No : GO to N9.
9. N9 CHECK CIRCUIT 2124 (YE/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Passenger Seat Cushion Heated Seat Element C334. Measure the resistance between passenger heated seat module C329 pin 6, circuit 2124 (YE/LB), harness side and passenger seat cushion heated seat element C334 pin 1, circuit 2124 (YE/LB), harness side; and between passenger heated seat module C329 pin 6, circuit 2124 (YE/LB), harness side and ground. Is the resistance less than 5 ohms between C329 pin 6 and C334 pin 1; and greater than 10,000 ohms between C329 pin 6 and ground? Yes : GO to N10. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
10. N10 CHECK CIRCUIT 2127 (VT/LB) FOR AN OPEN OR SHORT TO GROUND Disconnect: Passenger Seat Backrest Heated Seat Element C335. Measure the resistance between passenger heated seat module C329 pin 7, circuit 2127 (VT/LB), harness side and passenger seat backrest heated seat element C335 pin 1, circuit 2127 (VT/LB), harness side; and between passenger heated seat module C329 pin 7, circuit 2127 (VT/LB), harness side and ground. Is the resistance less than 5 ohms between C329 pin 7 and C335 pin 1; and greater than 10,000 ohms between C329 pin 7 and ground? Yes : GO to N11. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
11. N11 CHECK CIRCUIT 2126 (GY/LB) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between passenger seat cushion heated seat element C334 pin 4, circuit 2126 (GY/LB), harness side and passenger seat backrest heated seat element C335 pin 2, circuit 2126 (GY/LB), harness side; and between passenger seat cushion heated seat element C334 pin 4, circuit 2126 (GY/LB), harness side and ground. Is the resistance less than 5 ohms between C334 pin 4 and C335 pin 2; and greater than 10,000 ohms between C334 pin 4 and ground? Yes : GO to N12. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
12. N12 CHECK THE PASSENGER SEAT BACKREST HEATED SEAT ELEMENT Measure the resistance between passenger seat backrest heated seat element C335 pin 1, component side and C335 pin 2, component side. Is the resistance between 0.6 and 1.2 ohms? Yes : INSTALL a new passenger seat cushion heated seat element. REFER to «SEAT CUSHION - PASSENGER»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . REFER to «OCCUPANT CLASSIFICATION SENSOR (OCS) SERVICE KIT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system__occupant-classification-sensor-ocs) in the Removal and Installation portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : INSTALL a new passenger seat backrest heated seat element. REFER to «SEAT BACKREST - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
13. N13 CHECK CIRCUIT 1256 (WH/YE) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: EATC Module C228b. Key in ON position. Measure the voltage between passenger heated seat module C329 pin 8, circuit 1256 (WH/YE), harness side and ground. Is the voltage less than 0.2 volt? Yes : GO to N14. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
14. N14 CHECK CIRCUIT 1256 (WH/YE) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between passenger heated seat module C329 pin 8, circuit 1256 (WH/YE), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to N15. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
15. N15 CHECK CIRCUIT 1256 (WH/YE) FOR AN OPEN Measure the resistance between passenger heated seat module C329 pin 8, circuit 1256 (WH/YE), harness side and EATC module C228b pin 19, circuit 1256 (WH/YE), harness side. Is the resistance less than 5 ohms? Yes : GO to N16. No : REPAIR the circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
16. N16 CHECK THE HEATED SEAT MODULE Connect: Passenger Heated Seat Module C329. Key in ON position. Measure the voltage between EATC module C228b pin 20, circuit 2070 (GY/LB), harness side and ground; and between EATC module C228b pin 21, circuit 2069 (VT/LG), harness side and ground. Are the voltages less than 0.2 volt? Yes : GO to N18 . No : GO to N17.
17. N17 CHECK CIRCUITS 2070 (GY/LB) AND 2069 (VT/LG) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Passenger Heated Seat Module C329. Key in ON position. Measure the voltage between EATC module C228b pin 20, circuit 2070 (GY/LB), harness side and ground; and between EATC module C228b pin 21, circuit 2069 (VT/LG), harness side and ground. Are the voltages less than 0.2 volt? Yes : INSTALL a new heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : REPAIR the affected circuits. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
18. N18 CHECK CIRCUITS 2070 (GY/LB) AND 2069 (VT/LG) FOR A SHORT Key in OFF position. Measure the resistance between EATC module C228b pin 20, circuit 2070 (GY/LB), harness side and C228b pin 21, circuit 2069 (VT/LG), harness side. Is the resistance greater than 10,000 ohms? Yes : GO to N19. No : REPAIR the shorted circuits. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
19. N19 CHECK THE EATC MODULE OUTPUT Connect: EATC Module C228b. Connect: Passenger Heated Seat Module C329. Key in ON position. NOTE: The following measurement must be taken by back-probing the driver heated seat module C329. NOTE: The voltage on circuit 1256 (WH/YE) should drop momentarily when the driver heated seat control button is pressed. Measure the voltage between passenger heated seat module C329 pin 8, circuit 1256 (WH/YE), harness side and ground by back-probing the passenger heated seat module C329 pin 8. Press the passenger heated seat control button on the EATC module and note the voltage. Is the voltage greater than 10 volts before pressing the driver heated seat control button, then momentarily drops when the heated seat control button is pressed? Yes : INSTALL a new passenger heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : If the voltage is greater than 10 volts but did not drop when the driver heated seat button was pressed, INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . If the voltage is less than 10 volts, INSTALL a new driver heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

Upon receiving a signal from the electronic automatic temperature control (EATC) module, the heated seat module will decrease one setting (the sequence is HI, LO, OFF, HI, etc.). When a heated seat is set to HI, both LED indicators above the heated seat control button will illuminate. When a heated seat is set to LO, only the left LED indicator will illuminate. When a heated seat is set to OFF, neither LED will be illuminated.

An inoperative heated seat indicator can be caused by

1. wiring, terminals or connectors.
2. a faulty heated seat module.
3. a faulty EATC module.

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. O1 CHECK CIRCUITS 580 (BN) AND 579 (BK/OG) FOR A SHORT TO GROUND WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Disconnect: EATC Module C228b. Disconnect: Driver Heated Seat Module C359. Measure the resistance between EATC module C228b pin 7, circuit 580 (BN), harness side and ground; and between EATC module C228b pin 8, circuit 579 (BK/OG), harness side and ground. Are the resistances greater than 10,000 ohms? Result/ Action to Take Yes : GO to O2. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. O2 CHECK CIRCUITS 580 (BN) AND 579 (BK/OG) FOR AN OPEN Key in ON position. Measure the resistance between EATC module C228b pin 7, circuit 580 (BN), harness side and driver heated seat module C359 pin 9, circuit 580 (BN), harness side; and between EATC module C228b pin 8, circuit 579 (BK/OG), harness side and driver heated seat module C359 pin 10, circuit 579 (BK/OG), harness side. Are the resistances less than 5 ohms? Yes : GO to O3. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. O3 CHECK THE HEATED SEAT MODULE HI INDICATOR ON THE EATC MODULE Connect: EATC Module C228b. Key in ON position. Connect a fused jumper lead between driver heated seat module C359 pin 10, circuit 579 (BK/OG), harness side and C359 pin 12, circuit 1048 (LB/WH), harness side. Do both driver heated seat indicator LEDs illuminate on the EATC module? Yes : GO to O4. No : INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. O4 CHECK THE HEATED SEAT MODULE HI INDICATOR ON THE EATC MODULE Connect a fused jumper lead between driver heated seat module C359 pin 9, circuit 580 (BN), harness side and C359 pin 12, circuit 1048 (LB/WH), harness side. Does only the left driver heated seat indicator LED illuminate on the EATC module? Yes : INSTALL a new driver heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from driver seat side air bag module C3226. CONNECT driver seat side air bag module C3226. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

Upon receiving a signal from the electronic automatic temperature control (EATC) module, the heated seat module will decrease one setting (the sequence is HI, LO, OFF, HI, etc.). When a heated seat is set to HI, both LED indicators above the heated seat control button will illuminate. When a heated seat is set to LO, only the left LED indicator will illuminate. When a heated seat is set to OFF, neither LED will illuminate.

An inoperative heated seat indicator can be caused by

1. wiring, terminals or connectors.
2. a faulty heated seat module.
3. a faulty EATC module.

Scheme 110

Scheme 111

1. P1 CHECK CIRCUITS 2070 (GY/LB) AND 2069 (VT/LG) FOR A SHORT TO GROUND WARNING: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards. NOTE: If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . NOTE: The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault. NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the customer. Key in OFF position. WARNING: Be sure that nobody is in the vehicle and that there is nothing blocking or set in front of any air bag module when the battery ground cable is connected. For vehicles equipped with seat side air bags, carry out the following: Depower the SRS. Refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect driver seat side air bag C3226. Connect restraint system diagnostic tool 418-133 to driver seat side air bag C3226. Connect the battery ground cable. Disconnect: EATC Module C228b. Disconnect: Passenger Heated Seat Module C329. Measure the resistance between EATC module C228b pin 20, circuit 2070 (GY/LB), harness side and ground; and between EATC module C228b pin 21, circuit 2069 (VT/LG), harness side and ground. Are the resistances greater than 10,000 ohms? Result/ Action to Take Yes : GO to P2. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. P2 CHECK CIRCUITS 2070 (GY/LB) AND 2069 (VT/LG) FOR AN OPEN Key in ON position. Measure the resistance between EATC module C228b pin 20, circuit 2070 (GY/LB), harness side and passenger heated seat module C329 pin 9, circuit 2070 (GY/LB), harness side; and between EATC module C228b pin 21, circuit 2069 (VT/LG), harness side and passenger heated seat module C329 pin 10, circuit 2069 (VT/LG), harness side. Are the resistances less than 5 ohms? Yes : GO to P3. No : REPAIR the affected circuit. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. P3 CHECK THE HEATED SEAT MODULE HI INDICATOR ON THE EATC MODULE Connect: EATC Module C228b. Key in ON position. Connect a fused jumper lead between passenger heated seat module C329 pin 10, circuit 2069 (VT/LG), harness side and C329 pin 12, circuit 1048 (LB/WH), harness side. Do both passenger heated seat indicator LEDs illuminate on the EATC module? Yes : GO to P4. No : INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
4. P4 CHECK THE HEATED SEAT MODULE HI INDICATOR ON THE EATC MODULE Connect a fused jumper lead between passenger heated seat module C329 pin 9, circuit 2070 (GY/LB), harness side and C329 pin 12, circuit 1048 (LB/WH), harness side. Does only the left passenger heated seat indicator LED illuminate on the EATC module? Yes : INSTALL a new passenger heated seat module. TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) . No : INSTALL a new EATC module. REFER to «CONTROL COMPONENTS»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-control-components) . TEST the system for normal operation. For vehicles equipped with seat side air bags, DISCONNECT the battery ground cable. DISCONNECT the restraint system diagnostic tool from passenger seat side air bag module C3227. CONNECT passenger seat side air bag module C3227. REPOWER the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

Scheme 112

Remove the memory SET switch.

Measure the resistance between the following indicated terminals while pressing the requested switches.

TERMINAL SWITCH SPECIFICATION

The resistance should be less than 5 ohms for each switch position.

If the resistance is not less than 5 ohms for each switch, install a new switch; otherwise, return to the calling Pinpoint Test.

TERMINAL SWITCH SPECIFICATION

Note. Refer to Multimeter User's Manual for testing diodes.

To check the memory SET switch LED, connect the positive meter lead to terminal 2 and the negative lead to terminal 8. The meter should indicate greater than 0.3 volts. Reversing the leads, the meter should read OL.

If the meter readings are not as indicated above, install a new switch; otherwise, return to the calling Pinpoint Test.

Scheme 113

Scheme 114

Removal

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. RH seat shown, unless otherwise noted.

Scheme 115

Scheme 116

Scheme 117

1. Position the SIPS and install the 6 SIPS-to-floor bolts. Tighten to 48 Nm (35 lb-ft).
2. Install the passenger side front and rear door scuff plate assembly.
3. Install the driver side front and rear door scuff plate assembly.
4. Install the center console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/ford/five-hundred/i-2004-2007/remont/gauges-instrument-panels/#instrument-panel-and-console) .
5. Position the seat in the vehicle.
6. Tip the seat and connect the seat electrical connector.
7. Tip the seat and connect the memory seat electrical connector. Make sure the lever is all the way back and in the fully released position. Align the connector uniformly and lightly push in until a subtle audible click is heard and slight resistance is felt. Using the lever, pivot it toward the seat connector end, drawing the connector into its mating end. Make sure the locking tab is engaged to the retainer on the lever.
8. Tip the seat and connect the seat electrical connector.
9. Position the seat track on the side impact protection system (SIPS) bar and install the 2 rear bolts. Align the seat track rear locators into the SIPS. Tighten to 48 Nm (35 lb-ft).
10. Install the 2 seat track-to-floor front bolts. Tighten to 48 Nm (35 lb-ft).
11. Install the 2 seat track front inner and outer bolt covers.
12. Position the safety belt anchor onto the stud and install the nut. Tighten to 35 Nm (26 lb-ft).
13. Position the safety belt anchor with BTS onto the stud, install the nut and connect the electrical connector. Tighten to 35 Nm (26 lb-ft). Connect the BTS.
14. Install the seat cushion side shield cover.
15. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
16. Check the active restraint system. Make sure the safety belts and buckles are accessible to the occupants after installation. Verify the safety belt retractor operates without excessive effort or binding.

Seat - Exploded View, Front

Front Seat Backrest

Note. Passenger seat shown, driver seat similar.

Scheme 118

Driver Front Seat Cushion

Scheme 119

Passenger Front Seat Cushion

Scheme 120

Scheme 121

1. For additional information, refer to the procedures in this article.

DTC DETECTION CONDITION CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Removal and Installation

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 122

Scheme 123

Scheme 124

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. Remove the head restraint.
3. Remove the lumbar adjust handle clip and the lumbar adjust handle.
4. Release the backrest trim cover lower J-clips and hook and loop strips.
5. Place a hand between the backrest trim cover and backrest foam pad and carefully separate the hook and loop strips, then carefully roll up the backrest trim cover in an inside out fashion to the first row of hog rings in the front. On passenger seats, pull the backrest latch fold-flat release strap through the backrest trim cover bezel opening.
6. Remove the first row of hog rings in the front.
7. Release the hook and loop strip, invert the trim cover and remove the second row of hog rings in the front.
8. Release the J-clips at the back of the backrest trim cover.
9. Release the side air bag module backrest trim cover chute J-clip from around the side air bag module.
10. Feed the side air bag module backrest trim cover chute and J-clip retainers out through the side air bag module backrest foam pad opening.
11. Release the hook and loop strip, invert the backrest trim cover and remove the third row of hog rings in front.
12. Release the hook and loop strips in front, invert the backrest trim cover and remove the hog rings at the back.
13. Release the tabs and remove the head restraint guide.
14. Remove the backrest trim cover.

Installation

SPECIAL TOOL(S) CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Note. The heated seat element on the front passenger seat cushion is not serviceable separately. If a new heated seat element is needed on the front passenger seat cushion, a new occupant classification sensor (OCS) service kit and a new heated seat element must be installed.

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered.

Note. The air bag warning lamp illuminates when the restraint control module (RCM) fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a SRS fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. Repair is made by installing a new part only. If the new part does not correct the condition, install the original part and perform the diagnostic procedure again.

Scheme 125

1. Release the tab in the slot and slide the heated seat module off the bracket. Disconnect and remove the heated seat module.
2. To install, reverse the removal procedure.

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 126

Scheme 127

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. Remove the lumbar adjust handle clip and the lumbar adjust handle.
3. Release the backrest trim cover lower J-clips and hook and loop strips.
4. Place a hand between the backrest trim cover and backrest foam pad and carefully separate the hook and loop strips, then carefully roll up the backrest trim cover in an inside out fashion to the first row of hog rings in the front. Pull the backrest latch fold-flat release strap through the trim cover bezel opening.
5. Remove the first row of hog rings in the front.
6. Release the hook and loop strip, invert the backrest trim cover and remove the second row of hog rings in the front.
7. Release the J-clips at the back of the backrest trim cover.
8. Release the side air bag module backrest trim cover chute J-clip from around the side air bag module.
9. Feed the side air bag module backrest trim cover chute and J-clip retainers out through the side air bag module backrest foam pad opening.
10. Release the hook and loop strip, invert the trim cover and remove the third row of hog rings in front.
11. Release the hook and loop strips in front, invert the backrest trim cover and remove the hog rings at the back.
12. Remove the hog rings attaching the lumbar basket and backrest foam pad to the backrest frame.
13. Remove the tie straps at the top and outboard side of the backrest frame.
14. Remove the 2 screws and separate the lumbar adjuster.
15. Release the lumbar basket at the bottom and top and remove the assembly.

Scheme 128

1. Attach the lumbar basket to the backrest frame at the bottom and top.
2. Position the lumbar adjuster and install the 2 screws.
3. Wrap the 2 tie straps around the backrest frame at the top and the outboard side.
4. Install the hog rings attaching the lumbar basket (if equipped) or backrest support (if equipped) and backrest foam pad to the backrest frame.
5. Roll the trim cover down, attaching the hook and loop strips at the front and install the hog rings at the back.
6. Install the third row of hog rings in front and attach the hook and loop strips.
7. Roll down the backrest trim cover to the side air bag module.
8. Feed the side air bag module backrest trim cover chute and J-clip retainers back through the side air bag module backrest foam pad opening.
9. Install the side air bag module backrest trim cover chute and J-clips around the side air bag module and backrest frame. Attach the chute J-clips.
10. Attach the J-clips at the back of the backrest trim cover.
11. Attach the hook and loop strips, roll the backrest trim cover down and install the second row of hog rings in the front.
12. Attach the hook and loop strips, roll the backrest trim cover down and install the first row of hog rings in the front.
13. Pull the backrest latch fold-flat release strap through the trim cover bezel opening.
14. Attach the backrest trim cover lower J-clip.
15. Position the lumbar adjust handle clip on the lumbar adjust handle and push it on the lumbar adjuster.
16. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
2. Pull out and remove the manual recline handle.
3. Remove the seat control switch knob and power recline knob (if equipped).
4. Remove the rear screw, pull out on the side and front and separate the side shield.
5. Release the seat control switch wire harness pin-type retainer and remove the seat control switch from the side shield. Disconnect and remove the seat control switch.
6. To install, reverse the removal procedure.
7. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

SPECIAL TOOL(S) CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

SPECIAL TOOL(S) CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. The memory seat track position sensors are integral to the memory seat track motors. The memory seat track motor electrical connectors will connect to a seat track without the memory option. Make sure the correct seat track is being installed.

40 Percent Backrest

Scheme 129

60 Percent Backrest

Scheme 130

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 40 percent backrest lower outboard nut. To install, tighten to 48 Nm (35 lb-ft).
3. Pull the 40 percent backrest release strap, releasing the backrest latch from the striker and pivot the 40 percent seat forward.
4. Slide the 40 percent backrest out of the 60 percent pivot rod and remove.
5. Remove the 3 60 percent backrest lower nuts at the 2 backrest mounting brackets. To install, tighten to 48 Nm (35 lb-ft).
6. Pull the 60 percent backrest release strap, releasing the backrest latch from the striker and pivot the 60 percent seat forward and remove.
7. To install, reverse the removal procedure. Make sure the safety betls and buckles are accessible to the occupants after installation.

Scheme 131

Note. LH side shown, RH side similar.

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the nut from the lower retainer stud.
3. Separate the LH rear door weatherstrip at the seat backrest side bolster.
4. Between the pinch weld and the LH scuff plate, pry out and release the side bolster lower retainer.
5. Slide the LH side bolster up and out to remove.
6. To install, reverse the removal procedure. When installing the side bolster, install a M6 x 1.0 nut on the lower retainer stud and tighten to 8 Nm (71 lb-in).

Scheme 132

1. From under the front of the cushion assembly, push each of the 2 seat cushion floor latch release levers to the left of the vehicle. Lift up at the front and release the front of the cushion assembly.
2. Push the cushion assembly back as far as possible. Lift up at the rear outboard ends of the cushion assembly, clearing the retainer hooks from the cushion assembly wire, pull the cushion assembly forward and remove it.
3. To install, reverse the removal procedure. Make sure the safety belt buckles are accessible to the occupants after installation.

Seat - Exploded View, Second Row, Five Hundred, Montego

Five Hundred and Montego Rear Seat Backrest, Second Row, 60 Percent

Scheme 133

Five Hundred and Montego Rear Seat Backrest, Second Row, 40 Percent

Scheme 134

1. For additional information, refer to the procedures in this article.

Scheme 135

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 60 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Push in on the head restraint adjust button and remove the head restraint assembly.
4. Remove the screw and the armrest bracket outboard cover.
5. Remove the armrest-to-bracket bolt. To install, tighten to 23 Nm (17 lb-ft).
6. Slide the pin, on the inboard side of the armrest, out of the backrest and remove the armrest.
7. Fold the armrest pocket panel of the trim cover up and move aside.
8. Remove the pin-type retainers.
9. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook and loop strips at the back.
10. Release the hook and loop strips, invert the trim cover and remove the 3 rows of hog rings. Invert the trim cover to the headrest guide sleeves.
11. Pull the latch release strap through the trim cover.
12. Lift the backrest foam pad, pinch the head restraint guide together and remove the 2 head restraint guides.
13. Remove the backrest trim cover.
14. To install, reverse the removal procedure.

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Push in on the head restraint adjust button and remove the head restraint assembly.
4. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook and loop strips at the back.
5. Remove the bushing.
6. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings. Invert the trim cover to the head restraint guide.
7. Pull the latch release strap through the backrest trim cover.
8. Lift the backrest foam pad, pinch the head restraint guide together and remove the 2 head restraint guides.
9. Remove the backrest trim cover.
10. To install, reverse the removal procedure.

Scheme 136

Note. RH 40 percent seat shown, LH similar.

40 percent and 60 percent seat

1. Fold the affected 40 percent or 60 percent seat up to the E-Z entry position.
2. Remove the 2 riser/seat track-to-floor pan bolts and 2 riser/seat track-to-floor pan nuts for the 40 percent or 60 percent seat. To install, tighten to 48 Nm (35 lb-ft).
3. Remove the affected seat.
4. Remove the 2 screws and the console bracket cover.
5. Remove the 2 bolts and the inboard seat striker. To install, tighten to 80 Nm (59 lb-ft).
6. Remove the 2 bolts and the outboard striker. To install, tighten to 48 Nm (35 lb-ft).

Scheme 137

Note. Both seat riser and seat track are shown.

Scheme 138

Scheme 139

Scheme 140

1. For additional information, refer to the procedures in this article.

Note. With the seat out of the vehicle and the backrest in the fold-flat position, the inboard latch foot must be in the LATCHED position to pivot the backrest back to the UPRIGHT position.

Note. When installing the backrest, the retaining bolts must be tightened in the sequence shown.

Scheme 141

Scheme 142

1. Remove the 60 percent seat from the vehicle. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. From under the seat, release 3 sets of cushion trim cover J-clips.
3. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
4. From under the seat, release the J-clip at the RH side of the cushion frame.
5. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
6. Remove the cushion foam pad and cushion trim cover.
7. Remove the bolt and separate the safety belt buckle and safety belt anchor assembly from the RH recliner.
8. Release the 2 backrest trim cover lower J-clips.
9. Release the 4 backrest trim cover inside J-clips from the hard back panel.
10. Roll the trim cover up and remove the 2 LH recliner-to-backrest frame bolts.
11. Pull and remove the outboard pivot cover.
12. Remove the pivot bolt.
13. Lift the backrest foam pad and trim cover. Remove the 2 RH recliner-to-backrest frame bolts.
14. Remove the backrest.

Scheme 143

1. Position the backrest frame to the cushion frame.
2. Install the backrest frame bolts in the sequence shown. Install the 2 LH recliner-to-backrest frame bolts. Tighten to 50 Nm (37 lb-ft). Install the pivot bolt. Tighten to 23 Nm (17 lb-ft). Install the 2 RH recliner-to-backrest frame bolts. Tighten to 50 Nm (37 lb-ft).
3. Position and install the outboard pivot cover.
4. Reposition the backrest trim cover and attach the 4 backrest trim cover inside J-clips to the hard back panel.
5. Attach the 2 backrest trim cover lower J-clips.
6. Position the safety belt buckle and the safety belt anchor assembly to the RH recliner and install the bolt. Tighten to 48 Nm (35 lb-ft).
7. Reposition the cushion foam pad and cushion trim cover to the cushion frame.
8. Insert the cushion trim cover LH retainer back between the riser and the cushion frame.
9. From under the seat, attach the cushion trim cover J-clip at the RH side of the cushion frame.
10. From under the seat and at the back, between the cushion foam pad and frame, attach the cushion trim cover J-clip to the seat cushion frame.
11. From under the seat, attach 3 sets of cushion trim cover J-clips.
12. Install the 60 percent seat into the vehicle. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .

1. With the backrest folded down, release the backrest trim cover lower J-clip.
2. Release the 2 backrest trim cover inside J-clips from the hard back panel.
3. With the seat in the E-Z entry position, pull and remove the outboard pivot cover.
4. Remove the pivot bolt. To install, tighten to 23 Nm (17 lb-ft).
5. Roll the trim cover up and remove the 2 recliner-to-backrest frame bolts. Remove the backrest. To install, tighten to 50 Nm (37 lb-ft).
6. To install, reverse the removal procedure.

1. With the 60 percent seat in the E-Z entry position, release 3 sets of cushion trim cover J-clips from under the seat.
2. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
3. With the 60 percent seat positioned down, lift the cushion foam pad and cushion trim cover up. Remove the safety belt anchor and buckle bolt from the inboard recliner. To install, tighten to 50 Nm (37 lb-ft).
4. Release the 2 backrest trim cover lower J-clips.
5. Release the 4 backrest trim cover inside J-clips from the hard back panel.
6. Remove the LH and RH head restraints.
7. Squeeze the opening together and remove the outer safety belt trim guide.
8. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
9. Release the hook and loop strips and invert the backrest trim cover to the top of the backrest.
10. Squeeze the tabs in and remove the 4 head restraint guides.
11. Feed the safety belt through and remove the backrest trim cover.
12. To install, reverse the removal procedure. Make sure the safety belts and buckles are accessible to the occupants after installation. Verify the safety belt retractor operates without excessive effort or binding.

1. Remove the head restraint.
2. With the backrest folded down, release the backrest trim cover lower J-clip.
3. Release the 2 backrest trim cover inside J-clips to hard back panel.
4. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
5. Release the hook and loop strips and invert the backrest trim cover to the top of the backrest.
6. Lift the backrest foam pad, squeeze the tabs in and remove the 2 head restraint guides.
7. Remove the backrest trim cover.
8. To install, reverse the removal procedure.

1. Fold the 60 percent seat up to the E-Z entry position.
2. From under the seat, release 3 sets of cushion trim cover J-clips.
3. From under the seat and at the back, between the cushion foam pad and cushion frame, release the J-clip attached to the seat cushion frame.
4. From under the seat, release the J-clip at the RH side of the cushion frame.
5. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
6. Position the second row 60 percent seat down.
7. Remove the cushion trim cover from the cushion foam pad.
8. To install, reverse the removal procedure.

Scheme 144

1. With the seat in the E-Z entry position, release the cushion trim cover J-clip under the seat.
2. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
3. Pull the cushion trim cover retainers out from between the riser/seat track and the cushion frame.
4. Remove the hog rings and the cushion trim cover from the cushion foam pad.
5. To install, reverse the removal procedure.

1. Remove the 60 percent seat from the vehicle. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 60 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - SECOND ROW, 60 PERCENT, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Remove the pin-type retainer, screw and the RH recliner cover.
4. Remove the 3 RH recliner-to-riser bolts. To install, tighten to 50 Nm (37 lb-ft).
5. Remove the cushion frame yoke-to-RH recliner bolt, detach the cable and remove the RH recliner. To install, tighten to 50 Nm (37 lb-ft).
6. To install, reverse the removal procedure.

1. Release the backrest trim cover lower J-clip on the LH side.
2. Release the 2 backrest trim cover inside J-clips to hard back panel.
3. Roll the trim cover up and remove the 2 LH recliner-to-backrest frame bolts. To install, tighten to 50 Nm (37 lb-ft).
4. Remove 2 screws, pull and remove the riser LH inner cover.
5. Remove 3 screws and the riser LH outer cover.
6. Remove the screw and the manual recliner handle.
7. Remove 2 screws and the LH recliner outer cover. On assembly, make sure the release strap is through the cover opening.
8. From under the seat, release 3 sets of cushion trim cover J-clips.
9. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
10. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
11. Remove the pin-type retainer, release the locator pins and remove the LH recliner inner cover.
12. Remove the 3 cables from the LH recliner.
13. Remove the 4 bolts and the LH recliner. To install, tighten to 50 Nm (37 lb-ft).

1. With the backrest folded down, release the backrest trim cover lower J-clip.
2. Release the 2 backrest trim cover inside J-clips to hard back panel.
3. Roll the backrest trim cover up to access the 2 recliner-to-backrest frame bolts.
4. Pull the cushion trim cover outboard retainer out from between the riser/seat track and the cushion frame.
5. Remove 2 screws, pull and remove the riser/seat track LH inner cover.
6. Remove 3 screws and the riser/seat track LH outer cover.
7. Remove the screw and the recliner handle.
8. Remove 2 screws, pull and remove the recliner outer cover. On assembly, make sure the release strap is through the cover opening.
9. Remove the pin-type retainer, release the locator tabs and remove the recliner inner cover.
10. Remove the 2 cables from the recliner.
11. Remove the 4 bolts and the recliner. To install, tighten to 50 Nm (37 lb-ft).
12. To install, reverse the removal procedure.

Note. The seat riser is removed the same way.

1. Remove the 40 percent rear seat. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - SECOND ROW, 40 PERCENT, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Release the cushion trim cover J-clip under the seat.
4. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
5. Pull the cushion trim cover retainers out from between the seat track and the cushion frame.
6. Remove the cushion foam pad and cushion trim cover.
7. Remove 2 screws, pull and remove the seat track outboard inner cover.
8. Remove 3 screws and the seat track outboard outer cover.
9. Remove the screw and the manual recliner handle.
10. Remove 2 screws, pull and remove the recliner outer cover. On assembly, make sure the release strap is through the cover opening.
11. Remove the 2 cables from the recliner and route them out of the seat cushion frame.
12. Remove the 2 bolts and the recliner. To install, tighten to 50 Nm (37 lb-ft).
13. Remove the 6 cushion frame-to-seat track nuts and remove the seat track. To install, tighten to 23 Nm (17 lb-ft).
14. Remove 2 screws, pull and remove the seat track inboard inner cover.
15. Remove 3 screws and the seat track inboard outer cover.
16. Remove the 2 bolts, route out the cable and remove the outboard latch foot.
17. Remove the 2 bolts, route out the cable and remove the inboard latch foot.
18. To install, reverse the removal procedure.

Scheme 145

Scheme 146

1. Remove the left and right side rear quarter trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. Remove the 2 load floor supports (1 shown) from the load floor panel(s). Push the load floor support back and lift up on the load floor to disengage.
3. Remove the 4 bolts and remove the third row seat. To install, tighten to 80 Nm (59 lb-ft).
4. To install, reverse the removal procedure. Make sure the safety belt buckles are accessible to the occupants after installation.

Seat - Exploded View, Third Row

50 Percent Backrest

Scheme 147

Scheme 148

50 Percent Cushion

Scheme 149

Scheme 150

1. For additional information, refer to the procedures in this article.

1. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
2. Remove the head restraint(s).
3. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
4. Remove the head restraint guides. For bench seats, remove 4 head restraint guides. For 50/50 seats, remove 2 head restraint guides.
5. Remove the backrest trim cover. Pull the strap through the trim cover.
6. To install, reverse the removal procedure.

Scheme 151

Scheme 152

1. Remove the 2 rivets and pull the cushion handle out of the pocket. Using an appropriate tool, from under the rivet head, pry the rivet up. When removing the plastic rivet, make sure not to get under the insert or the rivet will not come out. Another method that can be used to remove the plastic rivets is to drive a screw partially into the rivet head and pull the screw and rivet head out. This will require new plastic rivets be installed.
2. Separate the pivot release cable and casing and remove the pivot release handle.
3. Remove the 2 screws on each side at the bottom of the load floor panel.
4. Pull out to release the retainers and remove the load floor panel. Use a suitable tool (pin-type retainer tool, etc.) to disengage the load floor from the seat.
5. Remove the screw, release the tab and remove the floor latch cover. For bench seats, remove 2 floor latch covers.
6. Release the cushion trim cover retainers from the cushion frame and remove the cushion trim cover. On assembly, the LATCH and child safety seat tether anchor must be accessible through the trim cover.
7. To install, reverse the removal procedure.

1. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
2. Roll the backrest trim cover up, remove the 4 backrest latch-to-backrest frame bolts and remove the backrest frame. To install, tighten to 50 Nm (37 lb-ft).
3. To install, reverse the removal procedure.

Note. LH 50 percent third row seat shown, RH similar.

Note. To remove the RH 50 percent third row seat backrest, the LH seat inboard trim cover must be removed before the RH seat inboard trim cover can be removed.

1. Remove the LH seat inboard-outer pivot cover.
2. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
3. Remove the pivot bolt. To install, tighten to 23 Nm (17 lb-ft).
4. Roll the backrest trim cover up, remove the 2 backrest latch-to-backrest frame bolts and remove the backrest frame. To install, tighten to 50 Nm (37 lb-ft).
5. To install, reverse the removal procedure.

SPECIAL TOOL(S) CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Disassembly

Note. Passenger seat shown, driver seat similar.

Scheme 153

Note. If a side air bag deployment took place, the seat back pad, trim cover and side air bag module must be replaced. The seat back frame should be replaced if necessary.

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the supplemental restraint system (SRS) must be depowered.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 154

Scheme 155

Scheme 156

1. Position the seat to access all the seat track-to-floor pan bolts and the safety belt anchor.
2. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. Remove the front seat. For additional information, refer to «SEAT - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
4. Remove the seat backrest. For additional information, refer to «SEAT BACKREST - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
5. Remove the head restraint.
6. Remove the clip and the lumbar adjust handle.
7. Release the backrest trim cover lower J-clips.
8. Place a hand between the backrest trim cover and backrest foam pad and carefully separate the hook and loop strips, then carefully roll up the backrest trim cover in an inside out fashion to the first row of hog rings in the front. On passenger seats, pull the backrest fold-flat release strap through the trim cover bezel opening.
9. Remove the first row of hog rings.
10. Release the hook and loop strips and carefully roll up the backrest trim cover and remove the second row of hog rings in the front.
11. Release the J-clips at the back of the backrest trim cover.
12. Release the side air bag module backrest trim cover chute J-clip from around the side air bag module cover.
13. Feed the side air bag module backrest trim cover chute and J-clip retainer out through the side air bag module backrest foam pad opening.
14. Release the hook and loop strip, and carefully roll up the backrest trim cover and remove the third row of hog rings in front.
15. Release the hook and loop strips in front, roll the backrest trim cover up and remove the hog rings at the back.
16. Release the tabs and remove the head restraint guides.
17. Remove the backrest trim cover.
18. Remove the hog rings attaching the lumbar basket (if equipped) or backrest support (if equipped) and backrest foam pad to the backrest frame.
19. Remove the backrest foam pad.
20. Release the 3 side air bag harness pin-type retainers and remove the nuts and the side air bag module with wire harness.
21. Remove the tie strap.
22. Remove the 2 screws and separate the lumbar adjuster.
23. Release the lumbar basket at the bottom and top and remove the assembly.
24. Separate the backrest latch cable pin-type retainer at the lower left corner of the backrest frame.
25. Remove the 4 bolts and remove the backrest latch assembly and cable.

Assembly

Scheme 157

Scheme 158

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered.

Note. The air bag warning lamp illuminates when the restraint control module (RCM) fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a SRS fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. Repair is made by installing a new part only. If the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Scheme 159

1. Position the seat to access all the seat track-to-floor pan bolts and the safety belt anchor.
2. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. Remove the front seat. For additional information, refer to «SEAT - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
4. Remove the front seat backrest. For additional information, refer to «SEAT BACKREST - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
5. Remove the seat track. For additional information, refer to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
6. Release the tab in the slot and slide the heated seat module off the bracket. Disconnect and remove the heated seat module.
7. Disconnect the power seat backrest adjust motor electrical connector.
8. Drive out the 2 large roll pins.
9. Remove the 3 bolts and the power seat backrest adjust assembly. To install, tighten to 10 Nm (89 lb-in).
10. Drive out the 2 large roll pins and remove the manual seat backrest adjuster.
11. Remove the 2 rivets, disconnect the 4 connectors and remove the driver seat module.
12. Remove the seat wire harness.
13. Remove the hog rings and the cushion trim cover from the cushion foam pad.
14. Remove the 2 nuts and the heated seat module mounting bracket.
15. To assemble, reverse the disassembly procedure.
16. Install the seat. For additional information, refer to «SEAT - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
17. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .

SPECIAL TOOL(S) CHART Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Scheme 160

Scheme 161

Note. OCS system components (seat cushion foam pad, bladder with pressure sensor and electronic control unit) are calibrated to each other and are serviced as an assembly. The OCS system components are not to be installed separately. If a new OCS system, OCS system component or seat cushion foam pad are needed, a new OCS system service kit (seat cushion foam pad, bladder with pressure sensor and electronic control unit) must be installed as an assembly.

Note. To identify between a production OCS system and a service OCS system (OCS service kit), inspect the electronic control unit (ECU) electrical connector. A production OCS system allows the disconnection of the ECU electrical connector. A service OCS system (OCS service kit) has the ECU electrical connector glued to the ECU, it cannot and should not be disconnected or altered. An OCS system service kit also has an in-line 10-pin connector between the OCS ECU and the seat wiring harness.

Note. The heated seat element on the front passenger seat cushion is not serviceable separately. If a new heated seat element is needed on the front passenger seat cushion, a new occupant classification sensor (OCS) service kit and a new heated seat element must be installed.

Note. If a seat equipped with a supplemental restraint system (SRS) component is being serviced, the SRS must be depowered.

Note. The air bag warning lamp illuminates when the restraint control module (RCM) fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a SRS fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. Repair is made by installing a new part only. If the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

1. Position the seat to access all the seat track-to-floor pan bolts and the safety belt anchor.
2. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(/ford/five-hundred/i-2004-2007/remont/airbag/#supplemental-inflatable-restraint-system) .
3. Remove the front seat. For additional information, refer to «SEAT - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
4. Remove the front seat backrest. For additional information, refer to «SEAT BACKREST - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
5. Remove the seat track. For additional information, refer to «SEAT TRACK - FRONT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
6. Disconnect the occupant classification sensor (OCS) pressure sensor electrical connector.
7. Remove the OCS bladder pin-type retainers.
8. Remove the OCS bladder, hose and pressure sensor from the seat cushion frame.
9. Disconnect the electronic control unit (ECU) electrical connector.
10. Disconnect the OCS service kit electrical connector.
11. Remove the tie strap retaining the unused pressure sensor electrical connector from the seat wiring harness.
12. Using a 5 mm (3/16 in) drill, remove the 2 rivets and the ECU from the seat cushion frame bracket.
13. Remove the OCS service kit from the seat cushion frame. Remove any tie straps securing wire harnesses or electrical connectors. Feed the hose, pressure sensor, wire harness, electrical connector and electronic control unit through the seat cushion frame support assembly.
14. Release the tab in the slot and slide the heated seat module off the bracket. Disconnect and remove the heated seat module.
15. Disconnect the power seat backrest adjust motor electrical connector.
16. Drive out the 2 large roll pins.
17. Remove the 3 bolts and the power seat backrest adjust motor assembly.
18. Drive out the 2 large roll pins and remove the manual seat backrest adjuster.
19. Remove the seat wire harness.
20. Remove the hog rings and cushion trim cover.

Scheme 167

1. Remove the head restraint assembly.
2. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
3. Release the hook and loop strips and invert the backrest trim cover to the top of the backrest.
4. Remove 4 screws and the backrest hard back panel.
5. Squeeze the tabs in and remove the 2 head restraint guides.
6. Remove the backrest trim cover.
7. Remove the backrest foam pad.
8. To assemble, reverse the disassembly procedure.

Scheme 168

Scheme 169

1. Remove the LH and RH head restraints.
2. Squeeze the opening together and remove the outer safety belt trim guide.
3. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
4. Release the hook and loop strips and invert the backrest trim cover to the top of the backrest.
5. Remove 5 screws and the backrest hard back panel.
6. Squeeze the tabs in and remove the 4 head restraint guides.
7. Feed the safety belt through and remove the backrest trim cover and backrest foam pad.
8. Remove 3 bolts and the safety belt retractor and safety belt buckle assembly. When installing the safety belt retractor and safety belt buckle assembly, position the safety belt retractor key through the backrest frame key way. To install, tighten the M10 bolt to 37 Nm (27 lb-ft). When installing the inner safety belt guide, position it into the backrest frame slot. To install, tighten the 2 M8 bolts to 23 Nm (17 lb-ft).
9. To assemble, reverse the disassembly procedure. Make sure the safety belts and buckles are accessible to the occupants after installation. Verify the safety belt retractor operates without excessive effort or binding.

Scheme 170

Scheme 171

1. Remove the 60 percent rear seat. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the rear seat backrest. For additional information, refer to «SEAT BACKREST - SECOND ROW, 60 PERCENT, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Remove 2 screws, pull and remove the riser RH inner cover.
4. Remove 3 screws and the riser RH outer cover.
5. Remove 2 screws, pull and remove the riser LH inner cover.
6. Remove 3 screws and the riser LH outer cover.
7. Remove the screw and the recliner handle.
8. Remove 2 screws and the LH recliner outer cover. On assembly, make sure the release strap is through the cover opening.
9. Remove the pin-type retainer, release the locator pins and remove the LH recliner inner cover.
10. Remove the 3 cables from the LH recliner and route them out of the seat cushion frame.
11. Remove the 2 bolts and the LH recliner. To install, tighten to 50 Nm (37 lb-ft).
12. Remove the 3 outboard cushion frame-to-riser nuts. To install, tighten to 23 Nm (17 lb-ft).
13. Remove the cushion frame-to-riser bolt in front of the RH recliner. To install, tighten to 50 Nm (37 lb-ft).
14. Remove the cushion frame yoke-to-riser bolt. To install, tighten to 50 Nm (37 lb-ft).
15. Remove the 3 RH recliner-to-riser bolts and separate the cushion frame from the riser. To install, tighten to 50 Nm (37 lb-ft).
16. Remove the 2 bolts, route out the cable and remove the LH latch foot. To install, tighten to 50 Nm (37 lb-ft).
17. Remove the 2 bolts, route out the cable and remove the RH latch foot. To install, tighten to 50 Nm (37 lb-ft).
18. Remove the bolt and the safety belt buckle. To install, tighten to 37 Nm (27 lb-ft).
19. Remove the screw and the inner pivot cover.
20. Remove the pivot grommet.
21. Remove the screw and the stationary foot cover.
22. Remove the pin-type retainer, screw and the RH recliner cover.
23. Remove the cushion frame yoke-to-RH recliner bolt, route out the cable and remove the RH recliner. To install, tighten to 50 Nm (37 lb-ft).
24. Remove the cushion trim cover from the cushion foam pad.
25. To assemble, reverse the disassembly procedure.

Scheme 172

Note. LH 40 percent seat shown, RH similar.

Note. With the seat out of the vehicle and the backrest in the fold-flat position, the inboard latch foot must be in the LATCHED position to pivot the backrest back to the UPRIGHT position.

1. Remove the 40 percent rear seat. For additional information, refer to «SEAT - REAR, SECOND ROW, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - SECOND ROW, 40 PERCENT, FREESTYLE»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) in this section.
3. Release the cushion trim cover J-clip under the seat.
4. From under the seat and at the back, between the cushion foam pad and cushion frame, release the J-clip attached to the cushion frame.
5. Pull the cushion trim cover retainers out from between the riser/seat track and the cushion frame.
6. Remove the cushion foam pan and cushion trim cover.
7. Remove 2 screws, pull and remove the riser/seat track outboard inner cover.
8. Remove 3 screws and the riser/seat track outboard outer cover.
9. Remove the screw and the manual recliner handle.
10. Remove 2 screws, pull and remove the recliner outer cover. On assembly, make sure the release strap is through the cover opening.
11. Remove the pin-type retainer, release the locator tabs and remove the recliner inner cover.
12. Remove the 2 cables from the recliner and route them out of the seat cushion frame.
13. Remove the 2 bolts and the recliner. To install, tighten to 50 Nm (37 lb-ft).
14. Remove the 6 cushion frame-to-riser/seat track nuts and remove the riser/seat track. To install, tighten to 23 Nm (17 lb-ft).
15. Remove the bolt and the safety belt buckle. To install, tighten to 37 Nm (27 lb-ft).
16. Remove the screw and the inboard pivot cover.
17. Remove the pivot grommet.
18. Remove 2 screws, pull and remove the riser inboard inner cover.
19. Remove 3 screws and the riser inboard outer cover.
20. Remove the cushion trim cover from the cushion foam pad.
21. To assemble, reverse the disassembly procedure.

Scheme 173

Bench Seat Backrest

Scheme 174

1. Remove the affected third row backrest. For additional information, refer to «SEAT BACKREST - THIRD ROW, BENCH»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) or «SEAT BACKREST - THIRD ROW, 50 PERCENT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the head restraint(s).
3. Release the hook and loop strips, invert the trim cover and remove the hog rings.
4. Remove the head restraint guides. For bench seats, remove 4 head restraint guides. For 50/50 seats, remove 2 head restraint guides.
5. Remove the backrest trim cover. Pull the strap through the trim cover.
6. Remove the backrest foam pad.
7. For 50 percent backrest, remove the bushing.
8. To assemble, reverse the disassembly procedure.

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

1. Remove the third row bench seat. For additional information, refer to «SEAT - THIRD ROW»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the third row bench backrest. For additional information, refer to «SEAT BACKREST - THIRD ROW, BENCH»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Pull to release and remove the LH backrest latch outboard cover. Pull the release strap through the trim cover.
4. Remove the 3 screws and remove the LH backrest latch inboard cover. Pull the release strap through the trim cover.
5. Pull to release and remove the RH backrest latch outboard cover.
6. Remove the 3 screws and remove the RH backrest latch inboard cover.
7. Remove the 2 rivets and pull the cushion handle out of the pocket. Using an appropriate tool, from under the rivet head, pry the rivet up. When removing the plastic rivet, make sure not to get under the insert or the rivet will not come out. Another method that can be used to remove the plastic rivets is to drive a screw partially into the rivet head and pull the screw and rivet head out. This will require new plastic rivets be installed.
8. Separate the pivot release cable and casing and remove the pivot release handle.
9. Remove the 2 screws on each side at the bottom of the load floor panel.
10. Pull out to release the retainers and remove the load floor panel.
11. Remove the screw, release the tab and remove the LH floor latch cover.
12. Remove the screw, release the tab and remove the RH floor latch cover.
13. Release the cushion trim cover retainers from the cushion frame and remove the trim cover and foam pad. On assembly, the LATCH and child safety seat tether anchor must be accessible through the trim cover.
14. Separate the floor latch cable from the LH backrest latch.
15. Separate the cable, remove 2 bolts and the LH backrest latch. To install, tighten to 50 Nm (37 lb-ft).
16. Remove 2 bolts, route the cable out of the cushion frame and remove the RH backrest latch. To install, tighten to 50 Nm (37 lb-ft).
17. Remove the 2 bolts from the LH floor latch. To install, tighten to 23 Nm (17 lb-ft).
18. Remove the 2 bolts from the RH floor latch and remove the floor latch assembly. To install, tighten to 23 Nm (17 lb-ft).
19. Separate the pivot release cable and casing from the pivot tube release lever and bracket. Remove the pivot release cable.
20. Remove 8 bolts and the cushion frame. To install, tighten to 50 Nm (37 lb-ft).
21. Remove the bolt and the LH safety belt buckle. To install, tighten to 37 Nm (27 lb-ft).
22. Remove the bolt and the RH safety belt buckle. To install, tighten to 37 Nm (27 lb-ft).
23. To assemble, reverse the disassembly procedure.

Scheme 182

Note. LH 50 percent seat shown, RH similar.

Scheme 183

Scheme 184

1. Remove the third row 50/50 seat. For additional information, refer to «SEAT - THIRD ROW»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the third row 50/50 backrest. For additional information, refer to «SEAT BACKREST - THIRD ROW, 50 PERCENT»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Pull to release and remove the backrest latch outer cover. Pull the release strap through the recliner outer cover.
4. Remove the 2 rivets and pull the pivot release handle out of the pocket. Using an appropriate tool, from under the rivet head, pry the rivet up. When removing the rivet, make sure not to get under the insert or the rivet will not come out. Another method that can be used to remove the plastic rivets is to drive a screw partially into the rivet head and pull the screw and rivet head out. This will require new plastic rivets be installed.
5. Separate the pivot release cable and casing and remove the pivot release handle.
6. Remove the 2 screws on each side at the bottom of the load floor panel.
7. Pull out to release the retainers and remove the load floor panel.
8. Remove the screw, release the tab and remove the floor latch cover.
9. Release the cushion trim cover retainers from the 50 percent cushion frame, and remove the cushion trim cover and cushion foam pad. On assembly, the LATCH and child safety seat tether anchor must be accessible through the cushion trim cover.
10. Remove the 2 screws, pin-type retainer and the inboard pivot cover.
11. Remove the bushing.
12. Remove the 2 screws and remove the backrest latch inboard cover. Pull the release strap through the trim cover.
13. Separate the floor latch cable from the backrest latch, remove 2 bolts and the floor latch assembly. To install, tighten to 23 Nm (17 lb-ft).
14. Remove 2 backrest latch-to-cushion frame bolts and the backrest latch. To install, tighten to 50 Nm (37 lb-ft).
15. Separate the pivot release cable and casing from the cushion pivot release lever and bracket. Remove the pivot release cable.
16. Remove 4 cushion frame-to-pivot tube assembly bolts and the cushion frame. To install, tighten to 50 Nm (37 lb-ft).
17. Remove the bolt and the safety belt buckle. To install, tighten to 37 Nm (27 lb-ft).
18. To assemble, reverse the disassembly procedure.

Scheme 185

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 60 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Push in on the head restraint adjust button and remove the head restraint assembly.
4. Remove the screw and the armrest bracket outboard cover.
5. Remove the armrest bolt and spacer. To install, tighten to 23 Nm (17 lb-ft).
6. Slide the pin, on the inboard side of the armrest, out of the backrest and remove the armrest.
7. Remove the armrest bracket inboard cover.
8. Fold the armrest pocket panel of the trim cover up and to the side.
9. Remove the pin-type retainers.
10. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook and loop strips at the back.
11. Release the hook and loop strips, invert the backrest trim cover and remove the 3 rows of hog rings. Invert the backrest trim cover to the head restraint guides.
12. Pull the backrest latch release strap through the trim cover.
13. Lift the backrest foam pad, pinch the head restraint guide together and remove the 2 head restraint guides.
14. Remove the backrest trim cover.
15. Remove the backrest foam pad.
16. Remove the cable and housing from the latch.
17. Remove the bolts and the latch. To install, tighten to 23 Nm (17 lb-ft).
18. Separate the release strap and cable end from the backrest bracket and remove the latch release assembly.
19. To assemble, reverse the disassembly procedure.

Scheme 186

1. Remove the rear seat cushion. For additional information, refer to «SEAT CUSHION - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «SEAT BACKREST - REAR, FIVE HUNDRED, MONTEGO»(/ford/five-hundred/i-2004-2007/remont/seats/#seat-system) .
3. Push in on the headrest adjust button and remove the headrest.
4. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook and loop strips at the back.
5. Remove the pivot grommet.
6. Release the hook and loop strips, invert the trim cover and remove the 3 rows of hog rings. Invert the trim cover to the headrest guide sleeves.
7. Pull the latch release strap through the trim cover.
8. Lift the foam pad, pinch the headrest guide sleeves together and remove them.
9. Remove the trim cover.
10. Remove the foam pad.
11. Remove the cable and housing from the latch.
12. Remove the bolts and the latch. To install, tighten to 23 Nm (17 lb-ft).
13. Separate the release strap and cable end from the backrest bracket and remove the latch release assembly.
14. To assemble, reverse the disassembly procedure.

See also:
• SUPPLEMENTAL RESTRAINT SYSTEM
• COMPONENT TESTING
• MODULE CONFIGURATION
• MODULE COMMUNICATIONS NETWORK
• CLIMATE CONTROL SYSTEM-GENERAL INFORMATION
• REAR VIEW MIRRORS
• CHARGING SYSTEM - GENERAL INFORMATION
• MULTIFUNCTION ELECTRONIC MODULES
• BRAKE SYSTEM-GENERAL INFORMATION
• INSTRUMENT CLUSTER
• CONTROL COMPONENTS
• INSTRUMENT PANEL AND CONSOLE
• INTERIOR TRIM AND ORNAMENTATION
• SEAT CALIBRATION
• SYMPTOM CHART
• DRIVER SEAT MODULE (DSM) DIAGNOSTIC TROUBLE CODE (DTC) INDEX
• PINPOINT TEST L
• PINPOINT TEST
• INSPECTION AND VERIFICATION
• OCCUPANT CLASSIFICATION SENSOR (OCS) SERVICE KIT
