Electronic Engine Control System Ford Five Hundred I

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Electronic Engine Controls

The electronic engine controls consist of the following

1. Power control module (PCM)
2. Engine coolant temperature (ECT) sensor
3. Camshaft position (CMP) sensor
4. Fuel rail pressure and temperature sensor
5. Crankshaft position (CKP) sensor
6. Mass air flow (MAF) sensor
7. Heated oxygen sensor (HO2S)
8. Catalyst monitor sensor
9. Knock sensor (KS)

The PCM

1. accepts input from various engine sensors to compute the fuel flow rate necessary to maintain a prescribed air/fuel ratio throughout the entire engine operational range.
2. outputs a command to the fuel injectors to meter the appropriate quantity of fuel.

The ECT sensor

1. sends the PCM a signal indicating engine temperature.
2. resistance decreases as coolant temperature increases.

The CMP sensor

1. provides camshaft position information which is used by the PCM for fuel synchronization.

The fuel rail pressure and temperature sensor

1. measures the pressure and temperature of the fuel in the fuel supply manifold and sends these signals to the PCM.
2. uses intake manifold vacuum as a pressure reference.

The CKP sensor

1. sends the PCM a signal indicating crankshaft position.
2. is essential for calculating spark timing.

The MAF sensor

1. uses a hot wire sensing element to measure the amount of air entering the engine. Air passing over the hot wire causes it to cool.

The HO2S

1. creates a voltage signal dependent on exhaust oxygen content.
2. provides feedback information to the PCM used to calculate fuel delivery.

The catalyst monitor sensor

1. monitors oxygen content after it flows through the catalytic converter.
2. provides a voltage to the PCM used to calculate catalytic converter integrity.

The KS

1. is used to detect engine detonation (spark knock).
2. sends a voltage signal to the PCM which retards the ignition timing as necessary.

Refer to the INTRODUCTION - GASOLINE article .

Scheme 3

Removal and Installation

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
2. Disconnect the CMP sensor electrical connector.
3. Remove the bolt and the CMP sensor. To install, tighten to 10 Nm (89 lb-in).
4. To install, reverse the removal procedure.

Scheme 4

1. With vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove the 7 pin-type retainers and the RH splash shield.
4. Disconnect the crankshaft position (CKP) sensor electrical connector.
5. Remove the bolt and the CKP sensor. To install, tighten to 10 Nm (89 lb-in).
6. To install, reverse the removal procedure.

Scheme 5

Removal

1. Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation procedure. For additional information, refer to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove the cowl panel grille. For additional information, refer to «FRONT END BODY PANELS»(/ford/five-hundred/i-2004-2007/remont/exterior-body-panels/#body-panel-system-front-end-body-panels) .
4. Disconnect the 3 PCM electrical connectors.
5. Remove the bolt and the PCM.

Installation

1. Install the PCM and the bolt. Tighten to 8 Nm (71 lb-in).
2. Connect the 3 PCM electrical connectors.
3. Install the cowl panel grille. For additional information, refer to «FRONT END BODY PANELS»(/ford/five-hundred/i-2004-2007/remont/exterior-body-panels/#body-panel-system-front-end-body-panels) .
4. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
5. Restore the module configuration. Carry out the module configuration restore steps of the Programmable Module Installation procedure. For additional information, refer to «MODULE CONFIGURATION»(/ford/five-hundred/i-2004-2007/remont/communication-devices/#module-configuration-system) .
6. Reprogram the passive anti-theft system (PATS). Carry out the Key Programming Using Two Programmed Keys procedure. For additional information, refer to «ANTI-THEFT - PATS»(/ford/five-hundred/i-2004-2007/remont/door-locks-anti-theft-systems/#anti-theft-system-pats) .
7. Carry out the Transaxle Drive Cycle Test. For additional information, refer to «AUTOMATIC TRANSAXLE - 6 SPEED»(/ford/five-hundred/i-2004-2007/remont/automatic-trans/#automatic-transaxle-6-speed) .

Material

MATERIAL CHART

Scheme 6

1. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/fuel-system/#fuel-system-general-information) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Disconnect the fuel rail pressure and temperature sensor electrical connector.
4. Disconnect the fuel rail pressure and temperature sensor vacuum connector.
5. Remove the 2 bolts and the fuel rail pressure and temperature sensor. To install, tighten to 3 Nm (27 lb-in).
6. To install, reverse the removal procedure. Lubricate the O-ring seal with clean engine oil.

MATERIAL CHART

Scheme 7

1. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(/ford/five-hundred/i-2004-2007/remont/cooling-system-mechanical/#engine-cooling-system) .
2. Disconnect the positive crankcase ventilation (PCV) and brake aspirator tubes from the air cleaner outlet pipe.
3. Disconnect the mass air flow (MAF) sensor electrical connector.
4. Loosen the air cleaner outlet tube clamp at the electronic throttle body. To install, tighten to 5 Nm (44 lb-in).
5. Remove the air cleaner housing cover and outlet tube assembly.
6. Disconnect the engine coolant temperature (ECT) sensor electrical connector.
7. Remove the hairpin clip and the ECT sensor.
8. To install, reverse the removal procedure. Use the alignment notches to correctly align the air cleaner housing cover to the air cleaner tray. Lubricate the O-ring seal with clean engine coolant.

Scheme 8

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
2. Disconnect the mass air flow (MAF) sensor electrical connector.
3. Remove the 2 screws and the MAF sensor. To install, tighten to 2 Nm (18 lb-in).
4. To install, reverse the removal procedure.

Scheme 9

1. For additional information, refer to the procedures below.

Special Tool(s)

SPECIAL TOOL CHART Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

Scheme 10

MATERIAL CHART

Scheme 11

1. With vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Disconnect the heated oxygen sensor (HO2S) electrical connector.
4. Remove the HO2S from the exhaust manifold using the special tool and discard. To install, tighten to 48 Nm (35 lb-ft).
5. To install, reverse the removal procedure. Apply a light coat of anti-seize lubricant to the threads of the HO2S.

SPECIAL TOOL CHART Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL CHART

1. With vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Disconnect the catalyst monitor sensor (CMS) electrical connector.
4. Using the special tool, remove the CMS from the exhaust and discard. To install, tighten to 48 Nm (35 lb-ft).
5. To install, reverse the removal procedure. Apply a light coat of anti-seize lubricant to the threads of the CMS.

Scheme 12

Scheme 13

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Position the knock sensor (KS) heat shield aside.
4. Disconnect the KS electrical connector.
5. Remove the bolt and the KS. To install, tighten to 20 Nm (15 lb-ft).
6. To install, reverse the removal procedure.
