HVAC System - Air Conditioning Ford Five Hundred I

SPECIFICATION ITEM

SPECIFICATION ITEM

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

The system components include the following

1. A/C compressor
2. A/C clutch assembly
3. A/C condenser core
4. A/C evaporator core
5. Receiver/drier
6. Connecting refrigerant lines
7. Thermostatic expansion valve

The refrigerant system incorporates an A/C compressor controlled by the powertrain control module (PCM) through an A/C clutch relay. The climate control assembly sends an A/C request signal to the instrument cluster module which relays the request to the PCM. An evaporator discharge air temperature sensor is used to disengage the A/C compressor clutch when the evaporator core temperature falls below 4°C (39°F).

The A/C compressor clutch will only be engaged by the PCM if all of the following conditions are met

1. The climate control assembly is set to a mode which provides an A/C request to the PCM via the instrument cluster module (ICM).
2. The evaporator discharge air temperature sensor is reading a temperature above 4°C (39°F).
3. The A/C pressure transducer is not reading a pressure above 2841 kpa (412 PSI) in the high side of the refrigerant system.
4. The A/C compressor relay is switched to the CLOSED position by the PCM.
5. The engine coolant temperature is not excessively high.
6. The PCM has not detected a wide open throttle (WOT) condition.

An A/C pressure relief valve is installed in the A/C manifold and tube to protect the refrigerant system against excessively high refrigerant pressures.

Refrigerant flow into the evaporator core is metered by a thermostatic expansion valve (TXV).

A/C Compressor and Clutch Assembly

Note. Internal A/C compressor components are not serviced separately. The variable scroll compressor is serviced only as an assembly. The A/C clutch, A/C clutch pulley and the A/C clutch field coil are serviceable.

The variable scroll A/C compressor has the following characteristics

1. A variable capacity function controlled by a suction pressure sensing device.
2. A fixed and orbiting scroll to provide refrigerant compression.
3. A non-serviceable shaft seal.
4. The A/C compressor uses PAG Refrigerant Compressor Oil. This oil contains special additives necessary for the A/C compressor.

The A/C compressor contains a thermal cutout switch which senses the compressor housing temperature. The switch will disengage the A/C compressor clutch if the housing temperature exceeds 120°C (247°F).

Scheme 1

The magnetic A/C clutch has the following characteristics

1. It drives the compressor shaft.
2. When battery positive voltage (B+) is applied to the A/C clutch field coil, the clutch disc and hub assembly is drawn toward the A/C clutch pulley.
3. The magnetic force locks the clutch disc and hub assembly and the A/C clutch pulley together as one unit, causing the compressor shaft to rotate.
4. When B+ is removed from the A/C clutch field coil, springs in the clutch disc and hub assembly move the clutch disc away from the A/C clutch pulley.

Condenser Core

Note. Installation of a new receiver/drier is not required when repairing the refrigerant system except when there is physical evidence of contamination from a failed A/C compressor or damage to the receiver/drier.

The condenser is an aluminum fin and tube design heat exchanger, located in front of the vehicle radiator. It cools compressed refrigerant gas by allowing air to pass over fins and tubes to extract heat and by condensing gas to liquid refrigerant as it is cooled.

Evaporator Core

Note. Installation of a new receiver/drier is not required when repairing the refrigerant system except when there is physical evidence of contamination from a failed A/C compressor or damage to the receiver/drier.

The evaporator core is an aluminum plate/fin type and is located in the heater core and evaporator core housing. A mixture of refrigerant and oil enters the bottom of the evaporator core through the evaporator core inlet tube and continues out of the evaporator core through the evaporator core outlet tube. Air from the blower motor is cooled and dehumidified as it flows through the evaporator core fins.

Thermostatic Expansion Valve

The thermostatic expansion valve (TXV) is located between the evaporator core lines and the thermostatic expansion valve manifold and tube assembly at the rear of the engine compartment. The TXV provides a restriction to the flow of refrigerant from the high-pressure side of the refrigerant system and separates the low-pressure and high-pressure sides of the refrigerant system. Refrigerant entering and exiting the evaporator core passes through the TXV through 2 separate flow paths. An internal temperature sensing bulb senses the temperature of the refrigerant flowing out of the evaporator core and adjusts an internal pin-type valve to meter the refrigerant flow into the evaporator core. The internal pin-type valve decreases the amount of refrigerant entering the evaporator core at lower temperatures and increases the amount of refrigerant entering the evaporator core at higher temperatures.

Receiver Drier

Note. Installation of a new receiver/drier is not required when repairing the refrigerant system except when there is physical evidence of contamination from a failed A/C compressor or damage to the receiver/drier.

The receiver/drier is mounted to the right of the radiator support. It stores high-pressure liquid after it leaves the condenser core. A desiccant bag mounted inside the receiver/drier removes any retained moisture from the refrigerant.

Evaporator Discharge Air Temperature Sensor

The evaporator discharge air temperature sensor contains a thermistor which receives a reference voltage from the PCM. The thermistor then varies the resistance to the reference voltage based on the evaporator discharge air temperature. The resulting voltage is returned to the PCM where it is interpreted as an evaporator air discharge temperature reading.

The PCM maintains evaporator core temperature and prevents icing of the evaporator core, by disengaging the A/C compressor clutch when the evaporator discharge air temperature sensor reading falls below 4°C (39°F), and by engaging the A/C compressor clutch when the discharge air temperature rises above 5°C (41°F).

The evaporator discharge air temperature sensor is located on the heater core and evaporator core housing in the air-stream leaving the evaporator core.

A/C Pressure Transducer

The A/C pressure transducer monitors the compressor discharge pressure and communicates with the powertrain control module (PCM). The PCM will interrupt A/C compressor operation in the event that the A/C pressure transducer indicates high system discharge pressures. It is also used to sense low charge conditions. If the pressure is below a predetermined value for a given ambient temperature, the PCM will not allow the clutch to engage.

Scheme 2

When disconnecting or connecting peanut fittings, observe the following.

1. The male and female blocks of the peanut fitting are retained with a nut.
2. Support the female fitting with a wrench to prevent twisting of the tubes.
3. An O-ring seal is installed around the tube on the male block.
4. When correctly assembled, the male and female fittings should be flush.
5. Use only the O-ring seal listed in the Ford Master Parts Catalog.

Service Gauge Port Valves

The high-pressure service gauge port valve is located on the compressor manifold and tube assembly near the condenser fitting.

The low-pressure service gauge port valve is located on the evaporator-to-suction accumulator line near the evaporator fitting.

Scheme 3

The fitting is an integral part of the refrigeration line or component.

1. Special couplings are required for both the high-side and low-side service gauge ports.
2. A very small amount of leakage will always be detectable around the Schrader-type valve with the service gauge port valve cap removed, and is considered normal. A new Schrader-type valve core can be installed if the seal leaks excessively.
3. The service gauge port valve caps are used as primary seals in the refrigerant system to prevent leakage through the Schrader-type valves from reaching the atmosphere. Always install and tighten the A/C service gauge port valve caps to the correct torque after they are removed.

Refrigerant System Dye

Fluorescent refrigerant system dye is added to the refrigerant system at the factory to assist in refrigerant system leak diagnosis using a Rotunda approved ultraviolet blacklight. It is not necessary to add additional dye to the refrigerant system before diagnosing leaks, even if a significant amount of refrigerant has been removed from the system. Replacement receiver/driers are shipped with a fluorescent dye "wafer" included in the desiccant bag, which will dissolve after approximately 30 minutes of continued A/C operation. It is not necessary to add dye after flushing or filtering the refrigerant system because a new receiver/drier is installed as part of the flushing or filtering procedure. Additional refrigerant system dye should only be added if more than 50% of the refrigerant system lubricant capacity has been lost due to a fitting separation, hose rupture, etc. For additional information, refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

Refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

Material

SPECIFICATION ITEM

Scheme 4

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

Note. If installing a new A/C compressor, the A/C clutch disc and hub (19D786), A/C compressor pulley (19D784) and A/C clutch field coil (19D798) must be inspected and transferred from the old unit to the new unit if suitable for reuse.

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
2. If flushing of the air conditioning system has not been carried out, recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
3. Remove the 3 A/C compressor pulley shield bolts and the A/C compressor pulley shield (if equipped).
4. Remove the drive belt. For additional information, refer to «ACCESSORY DRIVE»(/ford/five-hundred/i-2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
5. Remove the cooling fan assembly. For additional information, refer to «ENGINE COOLING»(/ford/five-hundred/i-2004-2007/remont/cooling-system-mechanical/#engine-cooling-system) .
6. Remove the lower radiator splash shield.
7. Remove the lower compressor nut. To install, tighten to 25 Nm (18 lb-ft).
8. Completely loosen the lower compressor stud. To install, tighten to 9 Nm (80 lb-in).
9. Completely loosen the lower compressor bolt. To install, tighten to 25 Nm (18 lb-ft).
10. Disconnect the A/C pressure transducer electrical connector.
11. Disconnect the field coil electrical connector.
12. Loosen the compressor manifold bolt and position the compressor manifold aside. Discard the O-ring seals. To install, tighten to 21 Nm (15 lb-ft).
13. Remove the upper compressor nut. To install, tighten to 25 Nm (18 lb-ft).
14. Completely loosen the upper compressor stud. To install, tighten to 9 Nm (80 lb-in).
15. Completely loosen the upper compressor bolt. To install, tighten to 25 Nm (18 lb-ft).
16. Remove the 2 compressor studs and the 2 compressor bolts.
17. Remove the A/C compressor.
18. To install, reverse the removal procedure. If a new A/C compressor is to be installed, the clutch assembly must be transferred from the old unit to the new unit. For additional information, refer to «CLUTCH AND CLUTCH FIELD COIL»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-air-conditioning) . Install new O-ring seals. If filtering of the refrigerant system is not to be carried out, lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
19. If filtering of the refrigerant system is not to be carried out, evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

Special Tool(s)

SPECIAL TOOL CHART Remover, Compressor Pulley 412-001 (T71P-19703-B) Holding Fixture, Compressor Clutch 412-103 (T95L-19703-AH) Installer, A/C Compressor Pulley 412-109 (T97P-19D786-A)

Scheme 5

Scheme 6

Scheme 7

MATERIAL CHART

Scheme 8

Scheme 9

Scheme 10

1. Remove the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-air-conditioning) .
2. Remove the A/C clutch disc and hub nut. Hold the A/C clutch disc and hub with the special tool. Remove the nut.
3. Remove the A/C clutch disc and hub.
4. Remove the A/C compressor pulley snap ring.
5. Using the special tool, remove the A/C clutch pulley.
6. Remove the A/C clutch field coil snap ring.
7. Remove the A/C clutch field coil. Remove the bolt. Remove the thermal limiter and A/C clutch field coil.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Visually inspect the A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil for damage. Inspect for physical damage including cracked or melted components or discoloration due to excessive heat. Inspect for excessive wear including grooving in the A/C clutch disc and hub or A/C compressor pulley that is more than fingernail depth. Inspect for roughness in the A/C compressor pulley bearing.
2. Clean the A/C clutch disc and hub, A/C compressor pulley and A/C clutch field coil mounting surfaces.
3. Apply a pea-sized drop of silicone sealant to the thermal limiter socket.
4. Install the A/C clutch field coil. Install the A/C clutch field coil. Install the thermal limiter. Tighten to 6 Nm (53 lb-in).
5. Install the A/C clutch field coil snap ring.
6. Install the A/C compressor pulley. Install the special tool. Install the A/C compressor pulley.
7. Install the A/C compressor pulley snap ring with the bevel side out.
8. Place one nominal thickness A/C clutch disc and hub spacer inside the clutch hub spline opening.
9. Install the A/C clutch disc and hub.
10. Install the A/C clutch disc and hub nut. Hold the A/C clutch disc and hub with the special tool. Tighten to 26 Nm (19 lb-ft).
11. Measure and adjust the clutch air gap by removing or adding A/C clutch disc and hub spacers.
12. Install the A/C compressor. For additional information, refer to «AIR CONDITIONING (A/C) COMPRESSOR»(/ford/five-hundred/i-2004-2007/remont/ac-compressor/#hvac-system-air-conditioning) .

MATERIAL CHART

Scheme 15

Scheme 16

Note. If an evaporator core leak is suspected, the evaporator core must be leak tested before it is removed from the vehicle.

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Remove the air inlet duct. For additional information, refer to «AIR DISTRIBUTION & FILTERING»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-system-air-distribution-system-filtering-system) .
2. Remove the heater core. For additional information, refer to «HEATING & VENTILATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-system-heating-ventilation) .
3. Remove the 8 upper evaporator core cover screws.
4. Disconnect the blower motor speed control (if equipped) or blower motor resistor (if equipped) electrical connector and detach the wire harness from the evaporator core cover.
5. Remove the 2 floor duct screws and the floor duct.
6. Remove the 13 lower evaporator core cover screws.
7. Remove the evaporator core cover.
8. Remove the evaporator core.
9. To install, reverse the removal procedure. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

MATERIAL CHART

Scheme 17

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
2. With the vehicle in NEUTRAL position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
3. Remove the radiator grille. For additional information, refer to «EXTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
4. Remove the bolt and position the horn assembly aside.
5. Remove the condenser outlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
6. Remove the condenser inlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
7. Remove the 4 radiator air deflector pin-type retainers.
8. Remove the 2 radiator air deflector stud retainers.
9. Remove the 2 condenser mounting studs. To install, tighten to 6 Nm (53 lb-in).
10. Remove the condenser core.
11. To install, reverse the removal procedure. Install new O-ring seals. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
12. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

MATERIAL CHART

Scheme 18

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
2. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
3. Detach the 2 coolant reservoir hose retainers from the cooling fan shroud.
4. Disconnect the A/C pressure transducer electrical connector.
5. Loosen the bolt and detach the compressor manifold. Discard the O-ring seals. To install, tighten to 21 Nm (15 lb-ft).
6. Remove the compressor manifold and tube suction fitting nut and disconnect the fitting. Discard the O-ring seals. To install, tighten to 8 Nm (71 lb-in).
7. Remove the condenser inlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
8. Remove the compressor manifold and tube assembly.
9. To install, reverse the removal procedure. Install new O-ring seals. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
10. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

MATERIAL CHART

Scheme 19

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
2. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
3. Remove the condenser outlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
4. Remove the receiver/drier outlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
5. Remove the 2 receiver/drier bracket bolts. To install, tighten to 9 Nm (80 lb-in).
6. Remove the receiver/drier.
7. To install, reverse the removal procedure. Install new O-ring seals. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
8. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

MATERIAL CHART

Scheme 20

Scheme 21

Scheme 22

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
2. Remove the 4 roll restrictor cross beam bolts. To install, tighten to 55 Nm (41 lb-ft).
3. Remove the roll restrictor bracket bolt. To install, tighten to 48 Nm (35 lb-ft).
4. Remove the cowl grille. For additional information, refer to «FRONT END BODY PANELS»(/ford/five-hundred/i-2004-2007/remont/exterior-body-panels/#body-panel-system-front-end-body-panels) .
5. Disconnect the 2 outer PCM electrical connectors.
6. Detach the wire harness bracket from the dash panel.
7. Disconnect the 2 VMV fittings.
8. Disconnect the VMV electrical connector.
9. Remove the VMV.
10. Remove the 2 coolant reservoir bolts. To install, tighten to 9 Nm (80 lb-in).
11. Disconnect the coolant sensor electrical connector.
12. Disconnect the washer pump electrical connector.
13. Disconnect the washer fluid sensor electrical connector.
14. Remove the ground strap bolt.
15. Remove the ground harness bolt.
16. Remove the auxiliary evaporator outlet line fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
17. Remove the auxiliary evaporator inlet line fitting nut and disconnect the fitting (if equipped). Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
18. Remove the TXV manifold bolt and disconnect the manifold. Discard the O-ring seals. To install, tighten to 8 Nm (71 lb-in).
19. Unclip the high-pressure charge port from the washer bottle clip.
20. Unclip the coolant hose from the high-pressure charge port clip.
21. Remove the TXV manifold and tube bracket bolt. To install, tighten to 8 Nm (71 lb-in).
22. Remove the compressor manifold and tube suction fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
23. Remove the receiver/drier outlet fitting nut and disconnect the fitting. Discard the O-ring seal. To install, tighten to 8 Nm (71 lb-in).
24. Remove the TXV manifold and tube assembly.
25. To install, reverse the removal procedure. Install new O-ring seals. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
26. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

MATERIAL CHART

Scheme 23

Scheme 24

Note. Installation of a new receiver/drier is not required when repairing the air conditioning system except when there is physical evidence of system contamination from a failed A/C compressor or damage to the receiver/drier.

1. Recover the refrigerant. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
2. Remove the 4 roll restrictor cross beam bolts. To install, tighten to 55 Nm (41 lb-ft).
3. Remove the roll restrictor bracket bolt. To install, tighten to 48 Nm (35 lb-ft).
4. Remove the TXV manifold bolt. Discard the O-ring seals. To install, tighten to 8 Nm (71 lb-in).
5. Remove the 2 TXV bolts. To install, tighten to 8 Nm (71 lb-in).
6. Remove the TXV. Discard the O-ring seals.
7. To install, reverse the removal procedure. Install new O-ring seals. Lubricate the refrigerant system with the correct amount of clean PAG oil. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .
8. Evacuate, leak test and charge the refrigerant system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/five-hundred/i-2004-2007/remont/automatic-hvac-system/#hvac-control-system-general-information) .

See also:
• CLIMATE CONTROL SYSTEM-GENERAL INFORMATION
• JACKING & LIFTING
• ACCESSORY DRIVE
• ENGINE COOLING
• AIR DISTRIBUTION & FILTERING
• HEATING & VENTILATION
• EXTERIOR TRIM AND ORNAMENTATION
• FRONT END BODY PANELS
• CLUTCH AND CLUTCH FIELD COIL
