Special Tool(s)
SPECIAL TOOL REFERENCE CHART Adapter for 303-224 (Handle) 205-153 (T80T-4000-W) Puller, Bearing 205-D064 (D84L-1123-A) or equivalent Puller, Bearing 204-023 (T73T-1217-A) or equivalent Remover/Installer, Bushing 204-180 (T93P-5493-A)
Scheme 16
Scheme 17
| Item | Part Number | Description |
|---|---|---|
| 1 | 1104 | Wheel hub |
| 2 | 3K186 LH/3K185 RH | Wheel knuckle |
| 3 | 1215 | Wheel bearing |
| 4 | 7059 | Snap ring |
ITEM DESCRIPTION CHART
SPECIAL TOOL REFERENCE CHART C-Frame and Screw Assembly 211-023 (T74P-3044-A1)
Scheme 18
Scheme 19
| Item | Part Number | Description |
|---|---|---|
| 1 | 1107 | Wheel stud |
ITEM DESCRIPTION CHART
Scheme 20
- Remove the brake disc. For additional information, refer to «FRONT DISC BRAKE»(ref-382384) .
- Using the C-Frame and Screw Assembly, remove the wheel stud.
SPECIAL TOOL REFERENCE CHART Installer, Halfshaft 204-161 (T97P-1175-A) Remover, Front Wheel Hub 205-D070 (D93P-1175-B) or equivalent Remover, Tie-Rod End 211-001 (TOOL-3290-D)
Scheme 21
Scheme 22
Scheme 23
Note. Left side shown in illustration; right side similar.
Scheme 24
| Item | Part Number | Description |
|---|---|---|
| 1 | W709618 | Ball joint bolt |
| 2 | W520203 | Ball joint nut (install new) |
| 3 | 3K186 LH/3K185 RH | Wheel knuckle and hub assembly |
| 4 | W713640 | Wheel hub nut (install new) |
| 5 | 2C204 | Wheel speed sensor |
| 6 | W520204 | Tie-rod end nut |
| 7 | W500011 | Wheel speed sensor bolt |
| 8 | W500742 | Wheel knuckle-to-strut bolt (2 required) (install new) |
| 9 | W520214 | Wheel knuckle-to-strut nut (2 required) (install new) |
ITEM DESCRIPTION CHART
