Starting/charging — Charging circuit Ford F-150 XIII facelift
All systems — 41 systems
- Air conditioning 2
- Anti-lock brakes 3
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension
- Engine performance 2.7l turbo
- Engine performance 3.0l turbo diesel
- Engine performance 3.3l flex fuel
- Engine performance 3.5l turbo
- Engine performance 5.0l flex fuel
- Exterior lights 4
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 4
- Navigation 10
- Power distribution
- Power door locks
- Power mirrors 5
- Power seats 8
- Power top/sunroof
- Power windows 4
- Radio 3
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2.7l turbo 3
- Transmission 3.0l turbo diesel 3
- Transmission 3.3l flex fuel 3
- Transmission 3.5l turbo 3
- Transmission 5.0l flex fuel 3
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 20
Click a component to highlight it on every diagram it appears on.
