Wiring diagram
Wiring diagram: Shift interlock — Shift interlock circuit
Ford Explorer VI facelift · 2022-2024
All systems
- Active bodyworks 2
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.3l turbo
- Engine performance 3.0l turbo
- Engine performance 3.3l hybrid
- Exterior lights 3
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 3
- Navigation 10
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 11
- Power top/sunroof
- Power windows
- Radio 4
- Shift interlock 3
- Starting/charging 2.3l turbo 2
- Starting/charging 3.0l turbo 2
- Starting/charging 3.3l hybrid
- Supplemental restraints
- Transmission 2.3l turbo 2
- Transmission 3.0l turbo 2
- Transmission 3.3l hybrid 2
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer
