Special Tool(s)

Illustration Name Number TKIT Number Gauge, Digital Tire Pressure 204-354 TKIT-2004C-FLM

Illustration Name Number TKIT Number Gauge, Digital Tire Pressure 204-354 TKIT-2004C-FLM

Scheme 3

Scheme 3: Special Tool(s)

Illustration Name Number TKIT Number Gauge, Digital Tire Pressure 204-354 TKIT-2004C-FLM

Scheme 4

Scheme 4: General Procedure

Scheme 5

Scheme 5
  1. Position the wheel and tire assembly on a tire machine and put a reference mark on the tire sidewall at the valve stem position. Item Description 1 Valve stem 2 Reference mark
  2. Using a suitable tire machine, separate the tire beads from the wheel. Lubricate the tire beads using a suitable fast drying, corrosion inhibiting tire bead lubricant. Position the tire 180 degrees (half-way around) on the rim so the valve stem reference mark is now opposite the valve stem.
  3. Re-inflate the wheel and tire assembly to the specified air pressure and measure the assembly again using a suitable dial indicator or Hunter Road Force® 9700 Series Wheel Balancer. Mark the second high spot on the tire. If the runout or Road Force® is reduced to within specifications, the concern has been resolved. Balance the assembly and install on the vehicle using the REFER to «Wheel-to-Hub Optimization»(ref-517542-S00350797582012121200000) .
  4. If the second runout or Road Force® measurement is still not within specification and both high spots are close to each other (within 101.6 mm (4 in)), the root cause is probably the tire (the high spot followed the tire). To be SURE that the tire is causing the high runout, it is necessary to have 2 runout or Road Force® measurements that are not within specification and the high spots must be in approximately the same location on the tire's sidewall. If the tire is the cause, install a new tire, balance the assembly and install on the vehicle using the Wheel-to-Hub Optimization procedure. REFER to «Wheel-to-Hub Optimization»(ref-517542-S00350797582012121200000) . If the second high spot is not within 101.6 mm (4 in) of the first high spot, proceed to the next step. Item Description 1 First high spot on the tire 2 Second high spot on the tire
  5. If the second high spot is still above specification and is within 101.6 mm (4 in) of being opposite the first high spot on the wheel, the root cause is probably the wheel (the high spot followed the wheel). Dismount the tire from the wheel, mount the wheel on a balancer and check the wheel runout. If the wheel runout exceeds 1.14 mm (0.0449 in), install a new wheel, balance the assembly and install on the vehicle using the Wheel-to-Hub Optimization procedure. REFER to «Wheel-to-Hub Optimization»(ref-517542-S00350797582012121200000) . Item Description 1 First high spot on the tire 2 Second high spot on the tire
  6. Draw an arrow on the tire sidewall from the second high spot towards the first high spot (in the shortest direction). Separate the tire beads from the wheel and rotate the tire 90 degrees (one-fourth turn) in the direction of the arrow. Item Description 1 First high spot on the tire 2 Second high spot on the tire

Illustration Name Number TKIT Number Gauge, Digital Tire Pressure 204-354 TKIT-2004C-FLM

Scheme 6

Scheme 6: Exploded View
ItemService Part NumberDescriptionTorqueMaterial NameNotes
11508Tire
21007Wheel
31700Valve stem and screw (also part of 1A189 )
41A189TPMS sensor (a new sensor assembly includes and 1700 valve stem screw and cap)
5Valve stem-to-TPMS sensor screw (part of 1700 or 1A189 )2 Nm (13 lb-in)
61A163Valve stem cap (also part of 1A189 )
