Parking Aid System: Removal & Installation Ford Explorer V

Warning System 10 illustrations ~272 words

Installation

  1. To install, reverse the removal procedure.
  2. Download the PAM configuration information from the scan tool to the new PAM by following the instructions on the scan tool.

Scheme 4

Scheme 4: Exploded View
ItemService Part NumberDescription
115K868Rear parking aid sensor electrical connector
215K859Rear parking aid sensor

Scheme 5

Scheme 5: Removal
  1. Remove the rear bumper cover. REFER to «BUMPER COVER - REAR»(ref-517604-S41186539882012121200000) .
  2. Release the retaining tabs and remove the parking aid sensor(s). Disconnect the electrical connector(s).
  1. To install, reverse the removal procedure.

Scheme 6

Scheme 6: Exploded View
ItemService Part NumberDescription
113B482Liftgate body moulding
2Rear view video camera screw (1 required)
3Rear view video camera retainer
419G490Rear view video camera
514A1412Rear view video camera electrical connector

Scheme 7

Scheme 7: Removal

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Remove the liftgate trim panel. REFER to «LIFTGATE TRIM PANEL»(ref-517611-S15636657292012121200000) .
  2. NOTE: LH side shown in illustration, RH side similar. Open the rear liftgate and remove the LH and RH liftgate body moulding nuts. To install, tighten to 3 Nm (27 lb-in).
  3. Remove the 4 liftgate body moulding bolts and remove the liftgate body moulding. Disconnect the electrical connector. To install, tighten to 3 Nm (27 lb-in).
  4. Remove the rear video camera screw and retainer, remove the rear video camera. Disconnect the electrical connector.
  1. NOTE: The rear video camera guidelines will not display if the rear video camera is not configured. Carry out the video camera configuration using a scan tool under Body > RVC Configuration.
  2. To install, reverse the removal procedure.

Scheme 10

Scheme 10: Exploded View
ItemService Part NumberDescription
1W705635Parking aid speaker bolts
215K864Parking aid speaker
314401Parking aid speaker electrical connector

Scheme 11

Scheme 11: Removal

Scheme 12

Scheme 12

Scheme 13

Scheme 13
  1. Remove the 2 bolts and remove the steering column cover trim panel. Pull outward to release the retainers. To install, tighten to 3 Nm (27 lb-in).
  2. Remove the 4 bolts and remove steering column cover assembly. To install, tighten to 5 Nm (44 lb-in).
  3. Remove the 2 bolts, disconnect the electrical connector and remove the parking aid speaker.
  1. To install, reverse the removal procedure.
