Engine Emission Control System: Other Ford Explorer V

Removal & Installation 2 illustrations ~312 words

Material(s)

NamePart NumberFord SpecificationFill Capacity/Quantity
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil (Canada)XO-5W20-QSP (US); CXO-5W20-LSP12 (Canada)WSS-M2C945-A

MATERIAL(S)

PCV

Note. Do not permanently remove or render inoperative any part of the vehicle emission control system including related hardware. Failure to comply may violate applicable state and federal laws.

Note. The vehicle emission vacuum routing diagrams are contained in the Description and Operation subsection of the Evaporative Emissions information. REFER to VEHICLE EMISSION VACUUM ROUTING - 2.0L GTDI - System Diagram.

The engine emission control system consists of the PCV system.

The PCV system

  1. uses intake manifold vacuum to ventilate blow-by vapors from the crankcase.
  2. returns the vapors to the intake manifold for combustion.

The PCV system consists of the

  1. crankcase ventilation tube.
  2. PCV valve.

The crankcase ventilation tube

  1. is connected to the PCV valve and the intake manifold fitting.

The PCV valve

  1. varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum.
  2. serviced as part of the crankcase vent oil separator.

Note. Do not permanently remove or render inoperative any part of the vehicle emission control system including related hardware. Failure to comply may violate applicable state and federal laws.

Note. The vehicle emission vacuum routing diagrams are contained in the Description and Operation subsection of the Evaporative Emissions information. REFER to VEHICLE EMISSION VACUUM ROUTING - 3.5L TI-VCT - SYSTEM DIAGRAM.

The engine emission control system consists of the PCV system.

The PCV System

  1. uses intake manifold vacuum to ventilate blow-by vapors from the crankcase.
  2. returns the vapors to the intake manifold for combustion.

The PCV System consists of the

  1. crankcase ventilation tube.
  2. PCV valve.

The crankcase ventilation tube

  1. is connected to the PCV valve and the intake manifold fitting.

The PCV valve

  1. varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum.
  2. mounted into the RH valve cover.
NamePart NumberFord SpecificationFill Capacity/Quantity
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil (Canada)XO-5W20-QSP (US); CXO-5W20-LSP12 (Canada)WSS-M2C945-A

Scheme 3

Scheme 3: Exploded View
ItemService Part NumberDescriptionTool NumberMaterial NameNotes
16C658Crankcase ventilation tube.
26A666PCV valveMotorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil (Canada)

Crankcase Vent Oil Separator - 2.0L GTDI

WARNINGBefore beginning any service procedure in this information, REFER to SAFETY WARNINGS . Failure to follow this instruction may result in serious personal injury.

Scheme 4

Scheme 4: Exploded View
ItemService Part NumberDescriptionTorqueMaterial NameNotes
1W500214Crankcase vent oil separator bolt (8 required)10 Nm (89 lb-in)
26A785Crankcase vent oil separator
36B752Crankcase vent oil separator gasket
