Adjustable Pedals: Removal & Installation Ford Explorer V

Mechanical - Hydraulic 1 illustration

Removal And Installation

  1. REFER to «BRAKE PEDAL AND BRACKET»(ref-517554-S35530581122012121200000) .

Scheme 24

Scheme 24: Exploded View
Scheme 24: Exploded View
ItemService Part NumberDescriptionTool NumberMaterial NameNotes
1Pedal adjust switch screw3 Nm (27 lb-in)
29G604Pedal adjust switch

Removal

  1. Remove the steering column shrouds. REFER to «STEERING COLUMN SHROUD»(ref-517558-S19607757902012121200000) .
  2. Turn the steering wheel 90 degrees to the left.
  3. Remove the screw and the pedal adjust switch.

Installation

  1. Position the pedal adjust switch and install the screw. Tighten to 3 Nm (27 lb-in).
  2. Install the steering column shrouds. REFER to «STEERING COLUMN SHROUD»(ref-517558-S19607757902012121200000) .
